Washing M achine Instruction M anual
DWD-FU1081 / FU1082 / FU1083
INSTRUCTION MANUAL
∀ Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water level and washing time.
∀ Low noise system
The washer minimizes the washing and spinning noises by sensing the
amount of laundry.
∀ Child-Lock
The Child-Lock system has been used to prevent children from pressing any
button to change the program during operation.
∀ Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the washer
sterilizes up to 99.9% as is done by boiling wash.
∀ Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence,
and the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
CONTENTS
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS ....................................................................................................4
INLET HOSE CONNECTION ...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER ........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................21
HOW TO CLEAN THE FILTER ......................................................................................................22
REMOVING STAINS ......................................................................................................................23
TROUBLE SHOOTING ..................................................................................................................24
SPECIFICATION & WIRING DIAGRAM ........................................................................................25
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo DWD-FU1081
Summary of Contents for Daewoo DWD-FU1081
-
Page 1: Table Of Contents
A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer properly and safely. -
Page 2: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book, Your model may not include all features. -
Page 3: Washer Safety
WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, Please ... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the 2. Unscrew the 3 bolts with the 10mm hex transit bolts(3ea) along with the rubber. wrench or spanner or cross-tip screwdriver. Keep the 3 bolts for a later time. •... -
Page 5: Inlet Hose Connection
INLET HOSE CONNECTION The washer should be connected to the water mains using new hose sets and old hose sets should not be reused. In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in WARNING death or serious injury. • Electrical earth is required on this washer. • Don’t earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •... -
Page 7: Operating Your Washer
2 Adjust the level of washer using adjustable legs. • Please check if there is any gap between the four adjustable legs and the floor. • Adjust the level of washer by turning adjustable legs. And make it sure that there is Fixing Nut no swaying of washer. - Page 8 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colors from light colors, colorfast items from non-colorfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soil. Color (White, Lights, Darks) Separate white clothes from colored clothes.
-
Page 9: The Functions Of The Control Panel
THE FUNCTIONS OF THE CONTROL PANEL Program selector For switching the washing machine on and off and for selecting the programs. You can select the course you want by rotating program selector. For the more detailed information, please refer to the page 11~20. Can be rotated in both direction. -
Page 10: Washing Procedure And Program Selection
WASHING PROCEDURE AND PROGRAM SELECTION 1. PROGRAM SELECTION • Select the program which you want to use by turning right or left the Program selector. • If required, press the buttons for options(Rinse+, Rinse Hold, or Time Delay). • Press the Start/Hold button. 2. - Page 11 4. FUNCTION • Recommended programs according to the laundry type Maximum Program Fabric Type Proper Temp. Option Load First check if laundry is machine 60˚C Rinse+ Rating washerble. (white cotton, linen towel (60˚C/Pre, Rinse Hold 95˚C) and sheets, …) Colorfast garments (shirts, night 40˚C (Cold, Rinse+ Rating...
- Page 12 * COTTON PROGRAMS Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 13 * SYNTHETICS PROGRAMS Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 14 * WOOL / HAND WASH PROGRAMS Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. Select the ‘WOOL / Hand Wash’...
- Page 15 * QUICK 15 PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 16 * SILENT WASH PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 17 * BULKY PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 18 * INTENSIVE PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 19 * BABY CARE PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 20 * SPORTS WEAR PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. Select the ‘Sports Wear’...
-
Page 21: Maintenance
MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur. -
Page 22: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter when water leaks from the water inlet. 1 Pull the power 2 Turn off the water 3 Pull the inlet filter 4 Remove the dirt plug out before supply to the out. -
Page 23: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 24: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If the error mode such as IE, OE, UE were displayed on the control part, in order to solve these problem, first turn off the power of the washing machine and then turn on the power by rotating the program selector. -
Page 25: Specification & Wiring Diagram
SPECIFICATION & WIRING DIAGRAM ∀ SPECIFICATION MODEL DWD-FU1081/FU1082/FU1083 Dimension (mm) 595 x 610 x 850 (W x D x H) Maximum mass of texile (kg) Unit Weight (kg) 50(Net) / 54(Gross) Standard Water Consumption 55∀ Spin Speed (RPM) 400 / 800 / 1000 Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm... - Page 26 ABOUT THIS MANUAL ABOUT THIS MANUAL ∃ ∃ % % & & % % ∋ ∋ ( ( ! ! ) ) ∗ ∗ + + , , − − % % ∃ ∃ + + . . ! ! % % ( ( ) ) / / 01 234 567 89: ;<=>...
