Daewoo DWD-F1011 Service Manual

Daewoo DWD-F1011 Service Manual

Front-loading washing machine
Hide thumbs Also See for DWD-F1011:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Instruction Manual
S/M No. : WDF1011001

Service Manual

Washing Machine

Model: DWD-F1011/1012/1013/1014
DWD-F1211/1212/1213/1214
NFL-1065/1265
DWD-F1021/1022/1023
DWD-F1221/1222/1223
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center
DAEWOO ELECTRONICS CORP.
Mar. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-F1011 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DWD-F1011

Summary of Contents for Daewoo DWD-F1011

  • Page 1: Service Manual

    S/M No. : WDF1011001 Service Manual Washing Machine Model: DWD-F1011/1012/1013/1014 DWD-F1211/1212/1213/1214 NFL-1065/1265 DWD-F1021/1022/1023 DWD-F1221/1222/1223 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center DAEWOO ELECTRONICS CORP.

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-F1011(S) / 1012(S) / 1013(S) / 1014(S) MODEL DWD-F1211(S) / 1212(S) / 1213(S) / 1214(S) NFL-1065 / NFL-1265 POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm...
  • Page 4 DWD-F1X2X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-F1021(S) / F1021(S) / F1023(S) MODEL DWD-F1221(S) / F1221(S) / F1223(S) POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64kg WATER CONSUMPTION...

  • Page 5: Installation

    2. INSTALLATION Transit bolts Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts Removing transit bolts 1. To prevent internal damage during trnasport, the 2.

  • Page 6: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1° Power outlet : Must be with 1,5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 7: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 8: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 9: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine pre- vents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: the wooden floor may cause excessive vibration.

  • Page 10: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive houshold detergent. Immediately wipe off any spills.

  • Page 11: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 12: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 13: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gaske clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and 2) Remove connectors and the earth terminal.
  • Page 14 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.

  • Page 15: Drain Pump

    DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 16: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS (DWD-F1X1X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608700 HANDLE CASE 3612608710 SILVER SPRAY DWD-F1X13 CASE DETERGENT 3611140300 CAP SOFTENER 3610916600 BOX INLET 3610526500 3618103500 COLD+HOT NOZZLE AS NOZZLE TOP + NOZZLE UNDER 3618103510 COLD ONLY SCREW TAPPING...
  • Page 17 BOX INLET AS (DWD-F1X2X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608900 HANDLE CASE 3612608910 SILVER SPRAY DWD-F1X23 CASE DETERGENT 3611140300 CAP SOFTENER 3610916600 BOX INLET 3610526500 3618103500 COLD+HOT NOZZLE AS NOZZLE TOP + UNDER 3618103510 COLD ONLY SCREW TAPPING 7122402011 T2S TRS 4X20 MFZN CLAMP AS...
  • Page 18 PANEL FRONT AS (DWD-F1X1X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614282700 PANEL F 3614282710 SILVER SPRAY DWD-F1X13 3616603600 DWD-F1X11/DWD-F1X14 BUTTON POWER 3616603620 ABS+AL COATING WINDOW DIAL 3615503100 3616603500 DWD-F1X11/DWD-F1X14 BUTTON SELECT 3616605320 ABS+AL COATING WINDOW LED 3615503000 PRPSSW5D50 DWD-F101's, TRIAC, EC 1000rpm PRPSSW5D60...
  • Page 19 PANEL FRONT AS (DWD-F1X2X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614284500 PANEL F 3614284510 SILVER SPRAY DWD-F1X23 3616604200 DWD-F1X21 BUTTON POWER 3616604210 ABS+AL COATING WINDOW DIAL 3615503400 3616604100 DWD-F1X21 BUTTON SELECT 3616604110 ABS+AL COATING WINDOW LED 3615503300 PRPSSW6D50 DWD-F102's, TRIAC, EC 1000rpm PRPSSW6D60...
  • Page 20 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811210 PCM, SGCC 0.8T, SILVER DWD-F1XX3 CABINET FRONT 3610811220 SECD 0.7T SWITCH DOOR LOCK 3619046800 250V16A, ROLD, BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6 HINGE DOOR 3612902800 ZNDC...
  • Page 21 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 22 PART NAME PART CODE SPECIFICATION Q'TY REMARK BALANCER WEIGHT F L/R 3616106300 FRONT, 6.0kg SPECIAL SCREW(BALANCER) 3616029400 SWCH 8.5X30 GASKET 3612321400 EPDM CLAMP GASKET AS 3611204500 HSWR D=1.8 TUB FRONT 3618821001 FRPP FH7300GM SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 FIXTURE HEATER 3612007300 SUS 0.7T 440x45 DRUM SUB AS...
  • Page 23 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 24 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610811100 SGCC, T0.8, PAINTING SPECIAL SCREW 3616029100 M4x12.5, MACHINE FRAME UPPER 3612205800 SGCC T1.2 55X580 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 FRAME TOP-L 3612205600 SGCC T1.6 52x500 FRAME TOP-R 3612205700 SGCC T1.6 52x500 STOPPER SPRING 3615202200 COVER BACK AS...
  • Page 25 PLATE T AS + PANEL LOWER AS (DWD-F1X1X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532900 HIPS, MFC, WH PLATE T AS 3614532910 ABS+UV SPRAY, MFC, SILVER DWD-F1X13 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN PANEL LOWER 3614282801 HIPS COVER PUMP FILTER 3611425801 HIPS...
  • Page 26 PLATE T AS + PANEL LOWER AS PLATE T AS + PANEL LOWER AS (DWD-F1X2X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532920 HIPS, MFC, WH PLATE T AS 3614532930 ABS+UV SPRAY, MFC, SILVER DWD-F1X23 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN PANEL LOWER 3614282801 HIPS...

  • Page 27: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL DWD-F1X1X SERIES DWD-F1X2X SERIES Power Switch Press this buton to turn the power ON or OFF. Start/Hold This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 28 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...

  • Page 29: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER SEQUENCE CHART Cotton Synthetic Division Progress Time Sensing 20sec. Water Supply 2min. 10min. Pre Wash 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. 70min. 60min. Wash 1 35min. (Heating) 30min. 20min.
  • Page 30 Wool Delicate Hand Wash Quick 30 Rinse+Spin Division Progress Time Soak 30min. 2min. Water Supply 1min. 15min. Wash 1 10min. (Heating) 5min. 20min. Wash 2 10min. 5min. Drain 1min. B-Spin 1min. Middle Spin 4min. 2min. Water Supply 1min. Rinse 1 3min.

  • Page 31: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the load movement You can check the PCB ASS'Y and the condition of each load movement simply. • The method to enter 1 Press the Power switch button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Each load makes a movement as follows, whenever the Time Delay button is pressed a time.

  • Page 32: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 33 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 34 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 35 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45°C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 36: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 37 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” PRINTED DATE: Mar. 2005 S/M No. : WDF1011001...
