Service Manual
Washing Machine
Model: DWD-G1081S/G1082S/FT1083
DWD-G1281S/G1282S/FT1283
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. :
May. 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-G1081S and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DWD-G1081S

Summary of Contents for Daewoo DWD-G1081S

  • Page 1 S/M No. : Service Manual Washing Machine Model: DWD-G1081S/G1082S/FT1083 DWD-G1281S/G1282S/FT1283 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    1. SPECIFICATIONS COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FT1081/FT1082/FT1083 DWD-FT1281/FT1282/FT1283 Dimension (mm) 595 x 590 x 850 (W x D x H) Maximum mass of texile (kg) 7.0 / 8.0 Unit Weight (kg) 49(Net) / 52(Gross) Standard Water Consumption...

  • Page 4: Installation

    2. INSTALLATION Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts 1. To prevent internal damage during transport, the 2. Unscrew the 3 bolts with the spanner supplied, special 3 bolts are locked. Before operating the and take out the 3 bolts with the rubber bungs.

  • Page 5: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1°. Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 6: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 7: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 8: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: The wooden floor may cause excessive vibration.

  • Page 9: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 10: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 11: Cleaning The Detergent Case

    Cleaning the detergent case • In case of residual detergents or fabric softeners have accumulated ; - It should be cleaned with a jet of running water. - If necessary, it can be removed completely from the washing machine. Push point 1 Pull-out 2 Push and pull again •...

  • Page 12: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and 2) Remove connectors and the earth terminal.
  • Page 13 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) Remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.
  • Page 14 DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 15: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS PART NAME PART CODE SPECIFICATION Q'TY REMARK A01 CASE HANDLE 36111T2W00 HIPS, FT1081 ABS + SPRAY, FT1081 A02 CASE DETERGENT 3611145800 A03 CAP SOFTENER 3610907800 A04 INLET BOX 3617511800 PP, D-FU1081 A05 NOZZLE UNDER 3618103410 M’S...
  • Page 16 PANEL FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK F01 PANEL F 36142T3A00 HIPS, FT1081 F02 BUTTON P.S 3616647600 ABS, FT1081 F03 WINDOW DISPLAY 3615511700 ABS(TR), FT1081 F04 DECO DIAL 36166DGQ00 ABS, FT1081 F05 KNOB DIAL 3616647700 ABS, FT1081 F06 SHAFT KNOB 3614905700 POM, MU802'S...
  • Page 17 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB700 D-FT1081 MAIN PCB AS, VE+NON-VDE, BB, HOT+COLD, 1000RPM PRPSSWB701 D-FT1081 MAIN PCB AS, VE+NON-VDE, NON-BB, COLD, 1000RPM PRPSSWB702 D-FT1081 MAIN PCB AS, VE+NON-VDE, BB, COLD, 1000RPM 8th PANEL PRPSSWB703 D-FT1081 MAIN PCB AS, VE+NON-VDE, NON-BB, HOT+COLD, 1000RPM...
  • Page 18 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK C01 CABINET FRONT 3610811210 PCM, SGCC 0.8T, SILVER DWD-F1XX3 3610811220 SECD 0.7T DWD-F1XX1(2) C02 SWITCH DOOR LOCK 3619047100 DL-LC.BITRON_3P.250V16A.BI-METAL C03 SCREW TAPPING 7122401208 T2S TRS 4X12 SUS C04 PLATE HINGE SUPPORT 3614531900 SGCC T1.6 No use C05 HINGE DOOR...
  • Page 19 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 20 PART NAME PART CODE SPECIFICATION Q'TY REMARK T01 BALANCER WEIGHT F AS 3616111800 D-FT1081's, 8kg T02 SPECIAL SCREW 3616029400 SWCH 8.5X30 T03 GASKET 3612327300 EPDM, D-FT1081 T04 CLAMP GASKET AS 3611204520 HSW3, GS T05 TUB *F 3618831000 FRPP, FT1081 T06 SPECIAL SCREW 3616062700 SWRCH 18A 5.6X30 T07 DAMPER FRICTION...
  • Page 21 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 22 PART NAME PART CODE SPECIFICATION Q'TY REMARK E01 CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 E02 FRAME LOWER 3612205501 SGCC T1.0 160X580 1 piece E03 FRAME TOP *L 36122UDY00 SGCC T=1.2, FT1081 SVC part E04 FRAME TOP *R 36122UDZ00 SGCC T=1.2, FT1081 E05 BASE UNDER *L 3610392201 SGCC T1.4 100x500 E06 BASE UNDER *R...
  • Page 23 PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK F01 PLATE TOP AS 3614533300 FX1X31~2, 41~2(HIPS, MFC, WH) 3614533310 F3~F4'S, SPRAY(ABS, MFC, SILVER) F02 SCREW TAPPING 7122401411 T2S TRS 4x14 MFZN F03 PANEL LOWER 3614282801 HIPS F04 COVER PUMP FILTER 3611425801...

  • Page 24: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL Program selector For switching the washing machine on and off and for selecting the programs. You can select the course you want by rotating program selector. For the more detailed information, please refer to the page 11~20. Can be rotated in both direction.

  • Page 25: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER SEQUENCE CHART Cotton COLD 40 °C 60 °C 60 °C PRE 95 °C Division Progress Time small small small small small ■ ■ Sensing 20sec. ■ ■ Water Supply 2min. Pre Wash 10min. ■ ■ 8min.
  • Page 26 Synthetic Wool & Handwash Silent Division Progress Time Quick15 Bulky Wash Cold 40°C 60°C 60°C PRE Cold 30°C ■ Sensing 20sec. ■ Water Supply 2min. Pre Wash 10min. ■ 8min. ■ Drain 1min. ■ B-Spin 2min. ■ Middle Spin 3min. Sensing 20sec.
  • Page 27 Spin Baby Sports Rinse+ Division Progress Time Intensive Rinse Drain Care Wear Spin 1000 Sensing 20sec. ■ ■ Water Supply 2min. Pre Wash 10min. ■ ■ 8min. ■ ■ Drain 1min. ■ ■ B-Spin 2min. ■ ■ Middle Spin 3min. Sensing 20sec.

  • Page 28: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the operation You can check the PCB ASSY and the operation of the washing machine simply. • The method to test and operate 1 Turning right or left the Program selector. 2 Press the 'Rinse Hold' button 3 times while press 'Rinse +' button.

  • Page 29: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 30 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 31 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 32 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45˚C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 33: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 34 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: AEWOOELEC” S/M NO. : PRINTED DATE: May. 2011...
  • Page 35 ABOUT THIS MANUAL ABOUT THIS MANUAL V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울...
