Washing Machine Instruction Manual
DWD-FD1441/1442/1443/1444/1445
INSTRUCTION MANUAL
Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water lever and washing time.
Low noise system
The washer minimizes the washing and spinning noises by sensing the amount
of laundry.
Child-Lock
The Child-Lock system has been used to prevent children from pressing any
button to change the program during operation.
Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the washer
sterilizes up to 99.9% as is done by boiling wash.
Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence,
and the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
CONTENTS
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS ....................................................................................................4
INLET HOSE CONNECTION ...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER ........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................19
HOW TO CLEAN THE FILTER ......................................................................................................20
REMOVING STAINS ......................................................................................................................21
TROUBLE SHOOTING ..................................................................................................................22
SPECIFICATION ............................................................................................................................23
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
Page
Advertisement
Table of Contents
Related Manuals for Daewoo DWD-FD1441
Summary of Contents for Daewoo DWD-FD1441
-
Page 1: Table Of Contents
A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer properly and safely. -
Page 2: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book, Your model may not include all features. -
Page 3: Washer Safety
WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, Please ... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the 2. Unscrew the 3 bolts with the 10mm hex transit bolts(3ea) along with the rubber. wrench or spanner or cross-tip screwdriver. Keep the 3 bolts for a later time. •... -
Page 5: Inlet Hose Connection
INLET HOSE CONNECTION The washer should be connected to the water mains using new hose sets and old hose sets should not be reused. In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in WARNING death or serious injury. • Electrical earth is required on this washer • Don’t earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •... -
Page 7: Operating Your Washer
2 Adjust the level of washer using adjustable legs. • Please check if there is any gap between the four adjustable legs and the floor. • Adjust the level of washer by turning adjustable legs. And make it sure that there is Fixing Nut no swaying of washer. - Page 8 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colors from light colors, colorfast items from non-colorfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soil. Color (White, Lignts, Darks) Separate white clothes from colored clothes.
-
Page 9: The Functions Of The Control Panel
THE FUNCTIONS OF THE CONTROL PANEL Press this switch to turn the power on or off. Operation and temporary stop is repeated as it is pressed. When you want to change program in operating; press the “Start/Pause” button Select the program that you want to change press the “Start/Pause”... -
Page 10: Washing Procedure And Program Selection
WASHING PROCEDURE AND PROGRAM SELECTION 1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON • Press the Power button to start. • Press the Start/Hold button • Initial condition - Program : Cotton - Wash : main wash - Rinse : 3 times - Spin : 800 rpm - Water temperature : 40˚C 2. - Page 11 4. FUNCTION • Recommended programs according to the laundry type Fabirc Proper Maximum Program Option Type Temp. Load First check if laundry is machine Pre Wash 60˚C washable.(white cotton, linen Rinse+ Rating (95˚C) towel and sheets..) Crease Care Cotton Colorfast garments 40˚C Pre Wash (shirts, night dresses, pajamas..)
- Page 12 * COTTON PROGRAM Put the laundry in to the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 13 * ECO PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 14 * SYNTHETIC PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 15 * DELICATE PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 16 * WOOL PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 17 * HAND WASH Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 18 * QUICK 30 Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
-
Page 19: Maintenance
MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur. -
Page 20: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter when water leaks from the water inlet. 1 Pull the power 2 Turn off the water 3 Pull the inlet filter 4 Remove the dirt plug out before supply to the out. -
Page 21: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 22: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If the error mode such as IE, OE, UE were displayed on the control part, in order to solve these problem, first turn off the power of the washing machine and then turn on the power pressing Power button. -
Page 23: Specification
SPECIFICATION MODEL DWD-FD1441/1442/1443/1444/1445 Dimension (mm) 595 x 540 x 850 (W x D x H) Maximum mass of textile (kg) Unit Weight (kg) 58(Net) / 62(Gross) Standard Water Consumption 56.1 Spin Speed (RPM) 400/800/1000/1400 Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm... - Page 24 ABOUT THIS MANUAL ABOUT THIS MANUAL VISION CREATIVE, INC.
