Washing Machine Instruction Manual
DWD-F1011/1012/1013'S/F1211/1212/1213'S

INSTRUCTION MANUAL

Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water lever and washing time.
Low noise system
The washer minimizes the washing and spinning noises by sensing the amount
of laundry.
Child-Lock
The Child-Lock system has been used to prevent children from pressing any
button to change the program during operation.
Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the washer
sterilizes up to 99.9% as is done by boiling wash.
Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing sequence,
and the bubbles dissolve the detergent particles completely and cleanse all the soil in clothes gently and neatly.
CONTENTS
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS ....................................................................................................4
INLET HOSE CONNECTION ...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER ........................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................19
HOW TO CLEAN THE FILTER ......................................................................................................20
REMOVING STAINS ......................................................................................................................21
TROUBLE SHOOTING ..................................................................................................................22
SPECIFICATION ............................................................................................................................23
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer property and safely.
Please read it carefully.
Downloaded From WashingMachine-Manual.com Manuals
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-F1011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWD-F1011

Summary of Contents for Daewoo DWD-F1011

  • Page 1: Table Of Contents

    A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer property and safely.

  • Page 2: Parts And Features

    PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book, Your model may not include all features.

  • Page 3: Washer Safety

    WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, Please ...

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the 2. Unscrew the 3 bolts with the spanner transit bolts(3ea) along with the rubber. supplied. Keep the 3 bolts and spanner for future use. • If the bolts are not removed, it may cause heavy vibration, noise and malfunction.

  • Page 5: Inlet Hose Connection

    INLET HOSE CONNECTION In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. For Ordinary Tap 1 Pull down the collar of the 2 Loosen the four screws...

  • Page 6: Electrical Requirements

    ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in WARNING death or serious injury. • Electrical earth is required on this washer • Don’t earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •...

  • Page 7: Operating Your Washer

    2 Adjust the level of washer using adjustable legs. • Please check if there is any gap between the four adjustable legs and the floor. • Turning adjustable legs by the enclosed spanner, adjust the level of washer and make Fixing Nut it sure that there is no swaying of washer.
  • Page 8 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colors from light colors, colorfast items from non-colorfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soil. Color (White, Lignts, Darks) Separate white clothes from colored clothes.

  • Page 9: The Functions Of The Control Panel

    THE FUNCTIONS OF THE CONTROL PANEL WASHING MA ASHING MACHINE CHINE DWD-F1011 WD-F1011 Press this switch to turn the power on or off. Operation and temporary stop is repeated as it is pressed. When you want to change program in operating;...

  • Page 10: Washing Procedure And Program Selection

    WASHING PROCEDURE AND PROGRAM SELECTION 1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON • Press the Power button to start. • Press the Start/Hold button • Initial condition - Program : Cotton - Wash : main wash - Rinse : 3 times - Spin : 800 rpm - Water temperature : 40˚C 2.
  • Page 11 4. FUNCTION • Recommended programs according to the laundry type Fabirc Proper Maximum Program Option Type Temp. Load First check if laundry is machine Pre Wash 60˚C washable.(white cotton, linen Rinse+ Rating (95˚C) towel and sheets..) Crease Care Cotton Colorfast garments Pre Wash (shirts, night dresses, pajamas..) 40˚C...
  • Page 12 * COTTON PROGRAM Put the laundry in to the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 13 * ECO PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 14 * SYNTHETIC PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 15 * DELICATE PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 16 * WOOL PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 17 * HAND WASH Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...
  • Page 18 * QUICK 30 Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. •...

  • Page 19: Maintenance

    MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur.

  • Page 20: How To Clean The Filter

    HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter when water leaks from the water inlet. 1 Pull the power 2 Turn off the water 3 Pull the inlet filter 4 Remove the dirt plug out before supply to the out.

  • Page 21: Removing Stains

    REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •...

  • Page 22: Trouble Shooting

    TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If error mode such as IE, OE, UE were displayed on the control part, in this case, how to solve these problem is first open and close the door, and then press START/HOLD button.

  • Page 23: Specification

    SPECIFICATION MODEL DWD-F1011/F1012/F1013 DWD-F1211/F1212/F1213 Dimension (mm) 595 x 540 x 850 (WxHxD) Unit Weight (kg) 64(Net) / 68(Gross) Standard Water Consumption Spin Speed (RPM) No Spin/400/800/1000 No Spin/400/800/1200 Operating Water Pressure 29kPa ~ 784kPa (0.3kgf/cm ~ 8kgf/cm WIRING DIAGRAM Downloaded From WashingMachine-Manual.com Manuals...
