Service Manual

Washing Machine

Model: DWD-FD1411/1412/1413
DWD-FD1421/1422/1423
DWD-FD1431/1432/1433
DWD-FD1441/1442/1443
DWD-FD1451/1452/1453
DWD-FD1461/1462/1463
DWD-FD1471/1472/1473
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. :
Sep. 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-FD1411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWD-FD1411

Summary of Contents for Daewoo DWD-FD1411

  • Page 1: Service Manual

    S/M No. : Service Manual Washing Machine Model: DWD-FD1411/1412/1413 DWD-FD1421/1422/1423 DWD-FD1431/1432/1433 DWD-FD1441/1442/1443 DWD-FD1451/1452/1453 DWD-FD1461/1462/1463 DWD-FD1471/1472/1473 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    DWD-FD141X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER COLD DWD-FD142X SERIES (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG SPECIFICATIONS...
  • Page 4 (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG MODEL DWD-FD1411/1412/1413, DWD-FD1421/1422/1423, DWD-FD1431/1432/1433 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1ℓ POWER CONSUMPTION 2200W...
  • Page 5 DWD-FD144X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG MODEL DWD-FD1441/1442/1443/1444/1445 POWER SOURCE 127V/60Hz , 220-240V/50-60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH...
  • Page 6 DWD-FD145X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FD1451/1452/1453/1454/1455 POWER SOURCE 220-240V/50-60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH 7 kg...
  • Page 7 DWD-FD146X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FD1461/1462/1463/1464/1465 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH...
  • Page 8 DWD-FD147X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FD1471/1472/1473/1474/1475 POWER SOURCE 220-240V/50-60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH 8 kg...

  • Page 9: Installation

    2. INSTALLATION Transit bolts Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts Removing transit bolts 1. To prevent internal damage during transport, the 2.

  • Page 10: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1°. Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 11: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 12: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 13: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: The wooden floor may cause excessive vibration.

  • Page 14: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 15: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 16: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 17: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove five screws on the COVER B and separate 2) Remove the connectors of the HEATER.
  • Page 18 3) Remove the nut using the 10mm hex wrench and 4) Loose the nut of the HEATER and pull out the remove the earth terminal from the HEATER. HEATER. BLDC MOTOR 1) Remove the nut using the 17mm hex wrench. 2) Pull out the ROTOR.

  • Page 19: Drain Pump

    DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 20: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS DWD-F1X6X SERIES DWD-F1X7X SERIES EXPLODE VIEW AND PARTS LIST...
  • Page 21 PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608700 DWD-F1X11(2) 3612608710 ABS + SPRAY DWD-F1X13 3612608900 DWD-F1X21(2) 3612608910 ABS + SPRAY DWD-F1X23 3612609700 DWD-F1X31(2) 3612609710 ABS + SPRAY DWD-F1X33 HANDLE CASE 3611148000 HIPS, D-FU124'S DWD-F1X41(2) (CASE HANDLE) DWD-F1X51(2) 3611148001 ABS + SPRAY DWD-F1X43 DWD-F1X53 3611149500...
  • Page 22 PANEL FRONT AS (DWD-FD141X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3814282702 HIPS DWD-FD1411(2) PANEL *F 3814282710 SILVER SPRAY DWD-FD1413 3616603600 DWD-FD1411 BUTTON POWER 3616603620 ABS + AL COATING DWD-FD1412(3) WINDOW DIAL 3615503100 ABS-TR BUTTON SELECT 3616603500 DWD-FD1411 3616603520...
  • Page 23 PANEL FRONT AS (DWD-FD142X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614284502 HIPS DWD-FD1421(2) PANEL *F 3614284510 SILVER SPRAY DWD-FD1423 3616604200 DWD-FD1421 BUTTON POWER 3616604210 ABS+AL COATING DWD-FD1422(3) WINDOW DIAL 3615503400 BUTTON SELECT 3616604100 DWD-FD1421 3616604110 ABS+AL COATING DWD-FD1422(3) WINDOW LED 3615503300 PRPSSWFJ--...
  • Page 24 PANEL FRONT AS (DWD-FD143X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614285802 HIPS DWD-FD1431(2) PANEL *F 3614285810 ABS + SPRAY DWD-FD1433 3616635300 DWD-FD1431 BUTTON POWER 3616635310 ABS + SPRAY DWD-FD1432(3) WINDOW DIAL 3615504200 ABS-TR 3616635400 DWD-FD1431 BUTTON SELECT 3616635410 ABS + SPRAY DWD-FD1432(3) WINDOW DISPLAY...
  • Page 25 PANEL FRONT AS (DWD-FD144X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T1500 HIPS DWD-FD1441(2) PANEL *F 36142T1501 ABS + SPRAY DWD-FD1443 3616639100 DWD-FD1441 BUTTON POWER 3616639110 ABS + SPRAY DWD-FD1442(3) WINDOW COURSE 3615507000 ABS-TR 3616639000 DWD-FD1441 BUTTON SELECTION 3616639010 ABS + SPRAY DWD-FD1442(3) WINDOW DISPLAY...
  • Page 26 PANEL FRONT AS (DWD-FD145X SERIES) Time Save Door Lock Child Lock PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614290100 HIPS, D-FU125'S DWD-FD1451(2) PANEL F 3614290110 ABS D-FU1253'S DWD-FD1453 3616644900 DWD-FD1451(2) BUTTON POWER 3616644910 ABS + SPRAY DWD-FD1453 WINDOW COURSE 3615509500 ABS-TR DWD-FD145X 3616645100...
  • Page 27 PANEL FRONT AS (DWD-F146X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T3000 D-F'SERIES 6TH , ABS DWD-FD1461(2) PANEL F 36142T3010 D-F'SERIES 6TH , ABS+ SPRAY DWD-FD1463 3616645800 D-F'SERIES 6TH , ABS DWD-FD1461(2) BUTTON SELECT 3616645810 D-F'SERIES 6TH , ABS+ SPRAY DWD-FD1463 3616645900 D-F'SERIES 6TH , ABS...
  • Page 28 PANEL FRONT AS (DWD-F147X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T3100 D-F'SERIES 7TH , ABS DWD-FD1471(2) PANEL F 36142T3110 D-F'SERIES 7TH , ABS+ SPRAY DWD-FD1473 BUTTON SELECT 3616646100 D-F'SERIES 7TH , ABS(SPRAY) DWD-FD147X WINDOW DISPLAY 3615510500 D-F'SERIES 7TH , TR ABS DWD-FD147X HOLDER LED(FUNCTION) 3613062200...
  • Page 29 Detailed Part Code of PCB AS (DONGSUH) PART CODE SPECIFICATION Q'TY REMARK PRPSSWFJA1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJA2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, D/M PRPSSWFJA3 RENE, INFI, NON-EC, COLD, BUBBLE, 1W, D/M PRPSSWFJA4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, D/M PRPSSWFJA5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJA6...
  • Page 30 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFJD1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJD2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, D/M PRPSSWFJD3 RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, 1W, D/M PRPSSWFJD4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, D/M PRPSSWFJD5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJD6...
  • Page 31 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFKGB RENE, INFI, NON-EC, HOT,COLD, BUBBLE, NON-1W, D/M PRPSSWFKGC RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, NON-1W, D/M, ISLAMIC RINSE PRPSSWFKGD RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, NON-1W, D/M PRPSSWFKGE RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, NON-1W, D/M, ISLAMIC RINSE PRPSSWFKGF RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, NON-1W, D/M PRPSSWFKGG...
  • Page 32 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFJE1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJE2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, D/M PRPSSWFJE3 RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, 1W, D/M PRPSSWFJE4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, D/M PRPSSWFJE5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, D/M PRPSSWFJE6...
  • Page 33 Detailed Part Code of PCB AS (NEWMOTECH) PART CODE SPECIFICATION Q'TY REMARK PRPSSWFLA1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLA2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, N/M PRPSSWFLA3 RENE, INFI, NON-EC, COLD, BUBBLE, 1W, N/M PRPSSWFLA4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, N/M PRPSSWFLA5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLA6...
  • Page 34 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFLD1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLD2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, N/M PRPSSWFLD3 RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, 1W, N/M PRPSSWFLD4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, N/M PRPSSWFLD5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLD6...
  • Page 35 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFKJB RENE, INFI, NON-EC, HOT,COLD, BUBBLE, NON-1W, N/M PRPSSWFKJC RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, NON-1W, N/M, ISLAMIC RINSE PRPSSWFKJD RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, NON-1W, N/M PRPSSWFKJE RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, NON-1W, N/M, ISLAMIC RINSE PRPSSWFKJF RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, NON-1W, N/M PRPSSWFKJG...
  • Page 36 PART CODE SPECIFICATION Q'TY REMARK PRPSSWFLE1 RENE, INFI, NON-EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLE2 RENE, INFI, NON-EC, HOT,COLD, NON-BUBBLE, 1W, N/M PRPSSWFLE3 RENE, INFI, NON-EC OPTION, COLD OPTION, BUBBLE OPTION, 1W, N/M PRPSSWFLE4 RENE, INFI, NON-EC, COLD, NON-BUBBLE, 1W, N/M PRPSSWFLE5 RENE, INFI, EC, HOT,COLD, BUBBLE, 1W, N/M PRPSSWFLE6...
  • Page 37 CABINET FRONT AS • 2 pcs Type PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811220 SECD 0.7T DWD-FD14X1(2) CABINET *F 3610811210 PCM, SGCC 0.8T, SILVER DWD-FD14X3 SWITCH DOOR LOCK 3619047100 DL-LC BITRON_3P 250V 16A BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6...
  • Page 38 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 39 PART NAME PART CODE SPECIFICATION Q'TY REMARK BALANCER WEIGHT F L/R 3616106320 FRONT, 5.5kg SPECIAL SCREW(BALANCER) 3616029400 SWCH 8.5X30 GASKET 3612321400 EPDM CLAMP GASKET AS 3611204520 HSW3,GS TUB *F 3618821010 FRPP FH7304GM SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 FIXTURE HEATER 3612007300 SUS 0.7T 440°ø45 DRUM SUB AS 3617004002...
  • Page 40 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 41 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 DWD-FD'S SPECIAL SCREW 3616029100 M4x12.5, MACHINE FRAME UPPER 3612205801 SGCC T1.0 55X580 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 FRAME TOP *L 3612205601 SGCC T1.4 52x500 FRAME TOP *R 3612205701 SGCC T1.4 52x500 STOPPER SPRING...
  • Page 42 PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532900 DWD-800W(HIPS, MFC, WH) DWD-F1411(2) 3614532910 ABS+UV SPRAY, MFC, SILVER DWD-F1413 3614532920 DWD-F142X(HIPS, MFC, WH) DWD-F1421(2) 3614532930 ABS+UV SPRAY, MFC, SILVER DWD-F1423 3614533300 FX1X31~2, 41~2(HIPS, MFC, WH) DWD-F1431(2) DWD-F1441(2) DWD-F1451(2)

  • Page 43: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL DWD-FD141X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 44 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 45 DWD-FD142X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 46 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 47 DWD-FD143X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 48 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 49 DWD-FD144X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 50 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 51 DWD-FD145X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 52 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 53 DWD-F146X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 54 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 55 DWD-F147X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 56 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.

  • Page 57: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER ■ Sequence Chart Cotton Sythetic Division Progress Time Small Small Small Sensing 20sec. Water Supply 2min. Pre Wash 10min. 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. Wash 1 90min. (Heating) 35min.
  • Page 58 Delicate Sports wear Wool Hand wash Quick 30 Rinse + Spin Division Progress Time 1X~5X 6X,7X Small Small Small Small Small Soak 30min. Water Supply 2min. (1min.) Wash 1 60min. (Heating) 50min. 35min. 30min. 5min. (13min.) Wash 2 20min. 10min. 5min.
  • Page 59 ■ Sequence Chart (for apply 'Islamic Rinse' option) Example) Apply 'Islamic Rinse' option with Cotton/Normal course. Cotton/Normal Islamic Rinse Option Division Progress Time S (A) L (B) S (a) L (b) Sensing 20sec. Water Supply 2min. Wash 1 30min. Same as Same as MAIN (Heating)

  • Page 60: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the operation You can check the PCB AS and the operation of the washing machine simply. • The method to test and operate 1 Press the Power button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Whenever the Time Delay button is pressed, the washing machine is operated as following.
  • Page 61 The spinning test mode You can continually spin the washing machine with constant speed. • The method to test and operate 1 Press the Power button. 2 Press the Time Save button 3 times while press Temp button. 3 '400' displays on '18:88 LED'. 400 means the spinning rpm. You can adjust the spinning rpm by pressing Spin button.

  • Page 62: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 63 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 64 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 65 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45˚C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 66: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 67 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Sep. 2010...
  • Page 68 V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울 종로구 통의동 6번지 이룸빌딩 4층 담 당 황의근 님 B U Y E R 세탁기 S/M (6Kg,7Kg 드럼세탁기) M O D E L DWD-FD1411/1412/1413 DWD-FD1421/1422/1423 DWD-FD1431/1432/1433 DWD-FD1441/1442/1443 DWD-FD1451/1452/1453 DWD-FD1461/1462/1463 DWD-FD1471/1472/1473 (S/M) 접 수...
