Service Manual

Washing Machine

Model:
DWD-FT1011/FT1012/FT1013/FT1211/FT1212/FT1213
DWD-FT1021/FT1022/FT1023/FT1221/FT1222/FT1223
DWD-FT1031/FT1032/FT1033/FT1231/FT1232/FT1233
DWD-FT1041/FT1042/FT1043/FT1241/FT1242/FT1243
DWD-FT1051/FT1052/FT1053/FT1251/FT1252/FT1253
DWD-FT1061/FT1062/FT1063/FT1261/FT1262/FT1263
DWD-FT1071/FT1072/FT1073/FT1271/FT1272/FT1273
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. :
Jul. 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-FT1011 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DWD-FT1011

Summary of Contents for Daewoo DWD-FT1011

  • Page 1: Service Manual

    : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CORP. http : //svc.dwe.co.kr Jul. 2011...

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    1. SPECIFICATIONS DWD-FT1X1X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-FT1X2X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER SPECIFICATIONS...
  • Page 4 DWD-FT1X3X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG DWD-FT1011/FT1012/FT1013/FT1211/FT1212/FT1213 MODEL DWD-FT1021/FT1022/FT1023/FT1221/FT1222/FT1223 DWD-FT1031/FT1032/FT1033/FT1231/FT1232/FT1233 POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 50Kg(NET) / 54Kg(GROSS) WATER CONSUMPTION 47~59ℓ...
  • Page 5 DWD-FT1X4X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG MODEL DWD-FT1041/1042/1043/1241/1242/1243 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 50Kg(NET) / 54Kg(GROSS) WATER CONSUMPTION 47~59ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH...
  • Page 6 DWD-FT1X5X SERIES COLD (OPTION) POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FT1051/1052/1053/1251/1252/1253 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 50Kg(NET) / 54Kg(GROSS) WATER CONSUMPTION 47~59ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH 6 / 6.5 / 7 kg OF TEXTILE...
  • Page 7 DWD-FT1X6X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FT1061/1062/1063/1261/1262/1263 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 50Kg(NET) / 54Kg(GROSS) WATER CONSUMPTION 47~59ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH...
  • Page 8 DWD-FT1X7X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FT1071/1072/1073/1271/1272/1273 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 50Kg(NET) / 54Kg(GROSS) WATER CONSUMPTION 47~59ℓ POWER CONSUMPTION 2200W MAXIMUM MASS WASH...

  • Page 9: Installation

    2. INSTALLATION Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts 1. To prevent internal damage during transport, the 2. Unscrew the 3 bolts with the spanner supplied, special 3 bolts are locked. Before operating the and take out the 3 bolts with the rubber bungs.

  • Page 10: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1°. Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 11: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 12: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 13: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: The wooden floor may cause excessive vibration.

  • Page 14: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 15: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 16: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 17: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and 2) Remove connectors and the earth terminal.
  • Page 18 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) Remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.

  • Page 19: Drain Pump

    DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 20: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS DWD-F1X6X SERIES DWD-F1X7X SERIES EXPLODE VIEW AND PARTS LIST...
  • Page 21 PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608700 DWD-F1X11(2) 3612608710 ABS + SPRAY DWD-F1X13 3612608900 DWD-F1X21(2) 3612608910 ABS + SPRAY DWD-F1X23 3612609700 DWD-F1X31(2) 3612609710 ABS + SPRAY DWD-F1X33 HANDLE CASE 3611148000 HIPS, D-FU124'S DWD-F1X41(2) (CASE HANDLE) DWD-F1X51(2) 3611148001 ABS + SPRAY DWD-F1X43 DWD-F1X53 3611149500...
  • Page 22 PANEL FRONT AS (DWD-FT @ X @ X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614282702 HIPS PANEL F 3614282710 SILVER SPRAY DWD-FT1X13 3616603600 DWD-FT1X11/DWD-FT1X14 BUTTON POWER 3616603620 ABS+AL COATING WINDOW DIAL 3615503100 3616603500 DWD-FT1X11/DWD-FT1X14 BUTTON SELECT 3616603520 ABS+AL COATING WINDOW LED 3615503000 Refer to...
  • Page 23 PANEL FRONT AS (DWD-FT1X2X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614284502 HIPS PANEL F 3614284510 SILVER SPRAY DWD-FT1X23 3616604200 DWD-FT1X21 BUTTON POWER 3616604210 ABS+AL COATING WINDOW DIAL 3615503400 3616604100 DWD-FT1X21 BUTTON SELECT 3616604110 ABS+AL COATING WINDOW LED 3615503300 Refer to PCB AS PRPSSWB---...
  • Page 24 PANEL FRONT AS (DWD-FT1X3X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614285802 HIPS DWD-FT1X31(2) PANEL F 3614285810 ABS+SPRAY DWD-FT1X33 3616635300 DWD-FT1X31 BUTTON POWER 3616635310 ABS+SPRAY DWD-FT1X32(3) WINDOW DIAL 3615504200 ABS-TR 3616635400 DWD-FT1X31 BUTTON SELECT 3616635410 ABS+SPRAY DWD-FT1X32(3) WINDOW DISPLAY 3615504300 ABS-TR Refer to...
  • Page 25 PANEL FRONT AS (DWD-FT1X4X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T1502 HIPS DWD-FT1X41(2) PANEL F 36142T1510 ABS + SPRAY DWD-FT1X43 3616639100 DWD-FT1X41 BUTTON POWER 3616639110 ABS + SPRAY DWD-FT1X42(3) WINDOW COURSE 3615507000 ABS-TR 3616639000 DWD-FT1X41 BUTTON SELECTION 3616639010 ABS + SPRAY DWD-FT1X42(3) WINDOW DISPLAY...
  • Page 26 PANEL FRONT AS (DWD-FT1X5X SERIES) Time Save Door Lock Child Lock PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614290100 HIPS, D-FU125'S DWD-FT1X51(2) PANEL F 3614290110 ABS D-FU1253'S DWD-FT1X53 3616644900 DWD-FT1X51(2) BUTTON POWER 3616644910 ABS + SPRAY DWD-FT1X53 WINDOW COURSE 3615509500 ABS-TR DWD-FT1X5X 3616645100...
  • Page 27 PANEL FRONT AS (DWD-FT1X6X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T3000 D-F'SERIES 6TH , ABS DWD-FT1X61(2) PANEL F 36142T3010 D-F'SERIES 6TH , ABS+ SPRAY DWD-FT1X63 3616645800 D-F'SERIES 6TH , ABS DWD-FT1X61(2) BUTTON SELECT 3616645810 D-F'SERIES 6TH , ABS+ SPRAY DWD-FT1X63 3616645900 D-F'SERIES 6TH , ABS...
  • Page 28 PANEL FRONT AS (DWD-FT1X7X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T3100 D-F'SERIES 7TH , ABS DWD-FT1X71(2) PANEL F 36142T3110 D-F'SERIES 7TH , ABS+ SPRAY DWD-FT1X73 BUTTON SELECT 3616646100 D-F'SERIES 7TH , ABS(SPRAY) DWD-FT1X7X WINDOW DISPLAY 3615510500 D-F'SERIES 7TH , TR ABS DWD-FT1X7X HOLDER LED(FUNCTION) 3613062200...
  • Page 29 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB100 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB PRPSSWB101 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB PRPSSWB102 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB PRPSSWB103 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB 1st PANEL...
  • Page 30 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB420 DWD-FU102, PANA, EC,1000RPM, HOT VV, BB, VDE+1W PRPSSWB421 DWD-FU102, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W PRPSSWB422 DWD-FU102, PANA, EC,1000RPM, COLD VV, BB, VDE+1W PRPSSWB423 DWD-FU102, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W PRPSSWB424 DWD-FU122, PANA, EC,1200RPM, HOT VV, BB, VDE+1W PRPSSWB425...
  • Page 31 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB200 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, BB PRPSSWB201 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB PRPSSWB202 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, BB PRPSSWB203 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB PRPSSWB204...
  • Page 32 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB500 DWD-FU106, PANA, EC,1000RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE PRPSSWB501 DWD-FU106, PANA, EC,1000RPM, HOT VV, BB, VDE+1W PRPSSWB502 DWD-FU106, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE PRPSSWB503 DWD-FU106, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W PRPSSWB504...
  • Page 33 Detailed Part Code of PCB AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB532 DWD-FU107, PANA, EC,1000RPM, HOT VV, BB, VDE+1W, ISLAMIC RINSE PRPSSWB533 DWD-FU107, PANA, EC,1000RPM, HOT VV, BB, VDE+1W PRPSSWB534 DWD-FU107, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W, ISLAMIC RINSE PRPSSWB535 DWD-FU107, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W PRPSSWB536...
  • Page 34 CABINET FRONT AS • 2 pcs Type PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811210 PCM, SGCC 0.8T, SILVER DWD-FT1XX3 CABINET FRONT 3610811220 SECD 0.7T DWD-FT1XX1(2) SWITCH DOOR LOCK 3619047100 DL-LC.BITRON_3P.250V16A.BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6 No use...
  • Page 35 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 36 PART NAME PART CODE SPECIFICATION Q'TY REMARK T01 BALANCER WEIGHT F AS 3616111800 D-FT1081's, 8kg T02 SPECIAL SCREW 3616029400 SWCH 8.5X30 T03 GASKET 3612327300 EPDM, D-FT1081 T04 CLAMP GASKET AS 3611204520 HSW3, GS T05 TUB *F 3618831000 FRPP, FT1081 T06 SPECIAL SCREW 3616062700 SWRCH 18A 5.6X30 T07 DAMPER FRICTION...
  • Page 37 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 38 PART NAME PART CODE SPECIFICATION Q'TY REMARK E01 CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 E02 FRAME LOWER 3612205501 SGCC T1.0 160X580 1 piece E03 FRAME TOP *L 36122UDY00 SGCC T=1.2, FT1081 SVC part E04 FRAME TOP *R 36122UDZ00 SGCC T=1.2, FT1081 E05 BASE UNDER *L 3610392201 SGCC T1.4 100x500 E06 BASE UNDER *R...
  • Page 39 PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532900 DWD-800W(HIPS, MFC, WH) DWD-F1X11(2) 3614532910 ABS+UV SPRAY, MFC, SILVER DWD-F1X13 3614532920 DWD-F1X2X(HIPS, MFC, WH) DWD-F1X21(2) 3614532930 ABS+UV SPRAY, MFC, SILVER DWD-F1X23 3614533300 FX1X31~2, 41~2(HIPS, MFC, WH) DWD-F1X31(2) DWD-F1X41(2) DWD-F1X51(2)

  • Page 40: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL DWD-FT1X1X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 41 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 42 DWD-FT1X2X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 43 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 44 DWD-FT1X3X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 45 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 46 DWD-FT1X4X SERIES 1000/1200 Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 47 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 48 DWD-FT1X5X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 49 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 50 DWD-FT1X6X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 51 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.
  • Page 52 DWD-FT1X7X SERIES Power Button Press this button to turn the power ON or OFF. Start/Pause Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 53 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, '2:00' is displayed.

  • Page 54: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER ■ Sequence Chart Cotton Sythetic Division Progress Time Small Small Small Sensing 20sec. Water Supply 2min. Pre Wash 10min. 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. Wash 1 90min. (Heating) 35min.
  • Page 55 Delicate Sports wear Wool Hand wash Quick 30 Rinse + Spin Division Progress Time 1X~5X 6X,7X Small Small Small Small Small Soak 30min. Water Supply 2min. (1min.) Wash 1 60min. (Heating) 50min. 35min. 30min. 5min. (13min.) Wash 2 20min. 10min. 5min.
  • Page 56 ■ Sequence Chart (for apply 'Islamic Rinse' option) Example) Apply 'Islamic Rinse' option with Cotton/Normal course. Cotton/Normal Islamic Rinse Option Division Progress Time S (A) L (B) S (a) L (b) Sensing 20sec. Water Supply 2min. Wash 1 30min. Same as Same as MAIN (Heating)

  • Page 57: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the operation You can check the PCB AS and the operation of the washing machine simply. • The method to test and operate 1 Press the Power button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Whenever the Time Delay button is pressed, the washing machine is operated as following.
  • Page 58 The spinning test mode You can continually spin the washing machine with constant speed. • The method to test and operate 1 Press the Power button. 2 Press the Time Save button 3 times while press Temp button. 3 '400' displays on '18:88 LED'. 400 means the spinning rpm. You can adjust the spinning rpm by pressing Spin button.

  • Page 59: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 60 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 61 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 62 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45˚C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 63: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 64 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: AEWOOELEC” S/M NO. : PRINTED DATE: Jul. 2011...
  • Page 65 V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울 종로구 통의동 6번지 이룸빌딩 4층 담 당 김용욱 님 M O D E L DWD-FT1011/FT1012/FT1013/FT1211/FT1212/FT1213 DWD-FT1021/FT1022/FT1023/FT1221/FT1222/FT1223 DWD-FT1031/FT1032/FT1033/FT1231/FT1232/FT1233 DWD-FT1041/FT1042/FT1043/FT1241/FT1242/FT1243 DWD-FT1051/FT1052/FT1053/FT1251/FT1252/FT1253 DWD-FT1061/FT1062/FT1063/FT1261/FT1262/FT1263 DWD-FT1071/FT1072/FT1073/FT1271/FT1272/FT1273 NFL-1065/NFL-1265 (S/M) 접...
