Washing Machine Instruction Manual
■ Dear Customer,
Firstly, many thanks for your preference in the purchasing of Daewoo
product. The product is made in ITALY with the nest materials,
comply with RoHs and REACH regulations with a particular focus on
human health and the environment.
Fundamental issues such as quality and safety are supported by strict
controls on our products, which are certi ed according international
standards - EN 60456:2011, EN 60335:2009, EN 62233:2010:
EN 61770:2009 and, EN ISO3741: 2010 by excellent certifying institute
VDE - IMQ.
This manual contains instructions for use, maintenance and warranty.
Before using the machine, carefully read this manual. It contains important instructions for safety, use
and maintenance of the washing machine. In this way self injury and damage to the machine is avoided.
CONTENTS
DWD-M_DWD-FI.indd 1
DWD-MI*/DWD-FI*
4
6
7
7
7
7
8
8
9
9
11
11
11
11
11
11
11
12
12
12
12
13
Page
15
15
16
16
16
17
17
17
17
18
18
19
19
19
19
19
19
20
20
20
20
20
22
24
2015-05-27 오전 10:39:06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-MI Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWD-MI Series

Summary of Contents for Daewoo DWD-MI Series

  • Page 1: Table Of Contents

    Washing Machine Instruction Manual DWD-MI*/DWD-FI* ■ Dear Customer, Firstly, many thanks for your preference in the purchasing of Daewoo product. The product is made in ITALY with the nest materials, comply with RoHs and REACH regulations with a particular focus on human health and the environment.
  • Page 2 DWD-M_DWD-FI.indd 2 2015-05-27 오전 10:39:06...

  • Page 3: Your Contribution To Environmental Protection

    YOUR CONTRIBUTION TO ENVIRONMENTAL PROTECTION DISPOSAL OF PACKAGING The manufacturer Ltd has always been care- ful to develop technologies and products which are environmentally friendly. It is also constantly The packaging has the purpose to protect ap- pliance from damage that might occur during the transportation.

  • Page 4: Safety Instructions And Warnings

    SAFETY INSTRUCTIONS AND WARNINGS TECHNICAL SAFETY This washing machine complies with current safety standards. However, improper use can cause damage Before connecting the appliance to the electric to persons and/or property. power line compare technical data (voltage, frequency) on the rating plate with that of the Before using the machine for the first time, carefully mains.
  • Page 5 • To connect the washing machine to the Be careful not to wash, with the laundry, foreign water supply using only new hoses. Do bodies (e.g. nails, needles, coins, paper clips). not use old water inlet hoses. These foreign bodies can damage the washing machine (e.g.

  • Page 6: Description Of Machine

    DESCRIPTION OF MACHINE This appliance meets all modern requirements for effective treatment of laundry with reduced consumption of water, electricity and detergent. Its innovative system permits full use of detergent and reduces water consumption, resulting in energy savings. This machine complies with ECC directives ECC: - 2005/32/EC (Eco design);...

  • Page 7: Installation

    INSTALLATION GENERAL INFORMATION Once unscrewed the screws pull out the locking screws including a bushing and spacer as shown in Figure 2. The washing machine can be installed in any place on condition that: Figure 2 • is protected from the bad weather; •...

  • Page 8: Installation Under A Work Top

    Figure 4 WATER SUPPLY CONNECTION vibrations, they should tighten by the ring nut and/or nut on the foot until it locks as shown in The water inlet hose must be connected to a tap of cold water with a 3/4” threaded mouth. Use only the supplied water inlet hose, avoiding the use of old hoses, or hoses used previously.

  • Page 9: Water Drainage

    Figure 5b shows the connection to the hot water Example of installation tap, this option is only available on request. Figure 7 Figure 5b hot water cold water on the drain hose. LIQUID DETERGENT BULKHEAD PAN Make sure that the domestic hot water supply temperature does not exceed 55°C to avoid Inside the kit supplied, there is a bulkhead pan damage to the laundry and washing machine.
  • Page 10 Make sure the plug is always accessible to unplug the machine from the mains. IMPORTANT! The electrical power system must be designed according to VDE 0100. • AFTER HAVING INSTALLED THE APPLIANCE, THE POWER CORD MUST BE ACCESSIBLE It is recommend to not connect in any case the machine with extension cords multiple •...

  • Page 11: Control Panel

    CONTROL PANEL *Available exclusively on the version of DWD-MI*/DWD-FI* model DESCRIPTION OF COMMANDS 1. PROGRAMME SELECTION DIAL 3. SPIN REGULATION DWD-MI*/DWD-FI* MODEL The dial is used to select a desired programme and to turn the machine OFF. It can be rotated This button is used to adjustment the spin in clockwise and counterclockwise for a fast speed.

  • Page 12: 5. Prewash And Soak

    5. PREWASH AND SOAK FIRST USE This key allows for the selection of prewash Before the regular use it is necessary to or soak function. Upon each press of the but- make a wash cycle with detergent, no laun- ton the LED indicator changes state There are dry and setting the temperature to 60°C with three possible combinations which are: cotton programme.

  • Page 13: Washing Programmes Duration And Options

    WASHING PROGRAMMES DURATION AND OPTIONS The programme intensive 60 °C and 40 ° C are the program <cotton standard 60°C> and <cotton standard 40°C>, used for the evaluation of the product performance, is the most of cotton laundries The actual values may differ from those indicated depending on the water pressure, its the power voltage and of the additional functions selected.
  • Page 14 Programme Programme Consented duration (*) Loading temperatures Maximum load Minimum load capacity marked Washing option Spin speed (kg) (kg) on control panel 30°C Max °C Laundry. 7-Intensive 5 Kg 1 hour 1 hour from cold 6 Kg 40 min 46 min Prewash or soak.

  • Page 15: Eco-Design Reference

    ECO-DESIGN REFERENCE Residual Total Energy Total water Water Standby Watt Programme time (min.) Humidity (%) Consumoption (kWh) Consumption (lt) ITWASH DAWOO suply type model pressure 40°C 60°C 60°C 40°C 60°C 60°C 40°C 60°C 60°C 40°C 60°C 60°C (kPa) Partial Partial Full Partial Partial...

  • Page 16: Precautions And Advice

    PRECAUTIONS AND ADVICE WASHING RECOMMENDATIONS SELECTION OF LAUNDRY • Do not allow children or disabled to use the For proper washing, laundry has to belong to washing machine without supervision. only one of the following types: • Do not allow children to play with the washing machine.

  • Page 17: Door Gasket

    DOOR GASKET Where there will be prewash, detergent must be deposited in the compartment on the left side (marked I). When washing some objects from over-folded clothes, or not removed from the laundry (paper The basin on the right is used for fabric softener. clips, buttons, nails, pins) can break off and The dose of the latter should not exceed the settle in the folds of the door gasket.

  • Page 18: Detergent Powder

    For the amount of detergent, always check the DETERGENT POWDER make sure that the detergent can be poured Detergent powder is more aggressive than into the basin. the liquid and undoubtedly less advanced in some respects. It is prepared usually with DOWN - components rather strong;...

  • Page 19: Softener

    PAUSING WASHING only at temperatures above 50°C, as in the liquid detergent there is no sodium perborate, It is possible to stop the wash cycle by pressing but the optical bleaching agent that works well the Start/Pause button. The machine will go to only beyond a certain temperature.

  • Page 20: Maintenance

    MAINTENANCE CABINET N.B If the drain pump is clogged, substantial quantity of water could be in the machine (max. To maintain the shininess of the washing 25l). machine cabinet over time it must be cleaned with warm water. Cleaning is recommended with soft cloth without using any detergent.
  • Page 21 DETERGENT DRAWER CLEANING To stop the flow: Having removed the detergent drawer, take Tighten the drain filter. away the vent steam plate as shown in photo below. When no more water comes out: Unscrew the entire filter. Clean the filter. Verify that the drain propeller rotates easily.

  • Page 22: Possible Remedies

    POSSIBLE REMEDIES The vast majority of failures and faults that occur in daily use of the machine can be eliminated . y l y l i The manufacturer srl authorized technical service centre. The following table will aid to identify and possibly eliminate the causes of failure/malfunction. However, note that: Repairs executed incorrectly can seriously threaten the safety of user.
  • Page 23 Problem Possible Solution Alarm Alarm ● LED number 2 and 4 flash • Switch off and then switch on the wash- (LED model) or F5 is dis- ing machine. If the fault persists contact ● played (Display model). an authorised service centre. ●...

  • Page 24: Spare Parts And Service

    SPARE PARTS AND SERVICE REPAIR For any repairs, contact authorised The manufacturer Ltd technical support service centre. Always communicate model and serial number of the appliance printed on the rating label. The data plate is also visible on the door opening, in the upper part. SERVICE MODEL:DWD-MI*/DWD-FI* 04300025...
