Hardware Installation and Reference Guide
(Rear panel)
BMC indicator (Rear
Panel)
Fan indicator (Rear
panel)
Power indicator (Rear
panel)
ID indicator
(Rear panel)
MGMT port indicator
QSFP28 port indicator
(Front panel)
Power Supply
The RG-S6920-4C series switches support power supply the RG-PA1200I-F. The smart power supply module supports
power management, and the host can read input power, input current, and temperature in real time. The power supply
module supports hot swapping.
Solid red
Blinking green.
Solid green
Solid yellow
Off
BMC Solid green
Blinking green
Off
Blinking green
Solid green
FAN
Solid yellow
Solid red
Off
Blinking green
PWR Solid green
Solid yellow
Solid red
Off
ID
Solid blue
LINK Off
LINK Solid Green
LINK Solid Yellow
LINK/ACT
ACT Off
ACT Blinking
Green
Off
Solid green
1F-32F
Blinking green
1) One of the modules of the system fails.
2) There are less than 3 fans.
3) The internal or partial temperature exceeds the
warning working temperature, and the switching
service resets.
The system is being initialized.
The system is operational.
1) The temperature exceeds the warning threshold.
2) Only 3 fans are in the position.
3) One of the power module is not plugged in with a
power cable in 1+1 power redundancy mode.
The BMC module is not in place or does not work.
The BMC module works properly.
The BMC module is being initialized.
The system is not powered on.
The fan modules are being initialized.
The fan modules work properly.
One fan module does not work.
The fan module is not in place or more than one fan
module do not work.
The system is not powered on.
The power modules are being initialized.
The power modules work properly.
One power module does not work.
More than one fan module do not work.
Locator is disabled.
Locator is enabled.
The port is not connected.
The port is connected at 1000Mbps.
The port is connected at 100Mbps.
The port is not transmitting or receiving data.
The port is transmitting or receiving data.
The port is not connected.
The port is connected at 40G/100Gbps.
The port is transmitting or receiving data at
40G/100Gbps.
Product Overview
