Hardware Installation and Reference Guide
1 Product Overview
RG-S6920-4C switches are data center oriented high density 100G aggregation switches, providing 100G access, low
latency, and complete data center features. RG-S6920-4C switches provide 128 100G ports and can be used with
RG-N18000-X switches to compose a high-performance and high-reliability data center network.
400G QSFPDD
Model
Ethernet Port
RG-S6920-4C
32
A QSFP28 port supports 100G/40G mode.
A QSFPDD port supports 400G/100G mode.
Specifications
Model
RG-S6920-4C
CPU
Quad-core eight-thread CPU processer, 2.2 GHz
16 MB
L2 Cache
eMMC
64 GB
SDRAM
DDR4 8GB (Compatible: 16 GB)
Expansion
4
Module Slot
Expansion
32-Port QSFP28 Module
Module
8-Port 400G Line Card
Fan Slot
6 (support 5+1 redundancy, configure at least 3 fan modules in one switch)
Fan Module
M2EFAN I-F
Power Supply
4 (support 2+2 redundancy)
Slot
Power Module
RG-PA1200I-F
AC input
Rated voltage range: 100 VAC to 240 VAC
Power Supply
Maximum voltage range: 90 VAC to 26VAC
Input
Frequency: 50 Hz to 60 Hz
Rated current: 5.2 A to 14 A
Power
Less than 2400 W
Consumption
Refer to Appendix B
Optical Module
SFP+ Port
Supported
QSFP28 Port
Supported
FC Port
Unsupported
10GBASE-T Port
Unsupported
100G QSFP28
Ethernet Port
128
The supported modules update at any time, contact Ruijie Networks for details.
10G
SFP+
Expansion
Ethernet Port
Module Slot
-
-
High voltage direct current (HVDC) input:
Input voltage range: 192 VDC to 288 VDC
Input current range: 6 A
Product Overview
Redundant
Redundant
Fan
Power Supply
5+1
2+2
- 3 -
