FALCON RIDGE PO-10MIDRANGER-RW01 Instructions For Installation And Care

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before opening and installing the Polaris
Ranger Cab Enclosure. The installation is best done when the temperature is 70 degrees
F. or warmer. This is to allow the Velcro to stick to the roll cage better, if you must
install outside in the cold it will help to warm the Velcro inside at room temp. until ready
to install.
2. Carefully open the carton and remove the rolled up Cab Enclosure on a large flat surface
that is clean and free of dirt or other material that may soil or scratch the windows of the
Cab.
3. It will help to raise the bed prior to installing the cab enclosure.
4. Check over the parts included in the carton with the parts list shown below:
Velcro Hook strips:
" "
" "
" "
Cab Enclosure
5. Begin by raising the bed of the Ranger and cleaning the metal piece that runs along the
bottom. After cleaning it off affix the 52" adhesive Velcro strip centered along the back
at the bottom. Then clean the area along the top of the roll cage that runs from side to
side and place the 30" adhesive Velcro tab centered and facing the front of the Ranger.
Now place the rear window up and attach the top to the Velcro there and pull the bottom
down and attach the Velcro centered along the bottom.
6. The sides are attached using double-sided Velcro strips sewn along the edges of the rear
window. At each of the straps use one of the supplied 3" adhesive strips and place it on
the inside of the roll cage so that the double-sided pieces hold on to it when wrapped
around the bar. The following diagrams show how this works.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Polaris Ranger 400/500
Soft Rear Window
PO-10MIDRANGER-RW01
12 each
1 each
1 each
1 each
3" long
30" long
52" long
