- Page 1 HP Pavilion tx1000 Entertainment PC Maintenance and Service Guide...
- Page 2 Hewlett-Packard Company under license. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
-
Page 3: Table Of Contents
Table of contents 1 Product description 2 External component identification Top components ... 4 Pointing devices ... 4 Keys ... 5 Display components ... 6 Front components ... 8 Right-side components ... 9 Left-side components ... 10 Rear components ... 11 Bottom components ... - Page 4 Battery ... 36 Pen ... 37 Hard drive ... 38 WWAN module ... 40 Computer feet ... 41 Optical drive ... 42 Memory module ... 43 WLAN module ... 44 Keyboard ... 47 Switch cover ... 50 Display assembly ... 52 Top cover ...
- Page 5 Phillips PM2.0×4.0 screw ... 93 Phillips PM2.0×4.0 captive screw ... 97 Phillips PM2.0×11.0 screw ... 98 Black Phillips PM2.0×7.0 screw ... 99 Phillips PM2.5×6.0 screw ... 100 Phillips PM2.0×5.0 screw ... 101 Silver Phillips PM2.0×7.0 screw ... 103 Phillips PM2.0×3.0 screw ... 104 9 Backup and Recovery Recovering system information ...
-
Page 6: Product Description
Graphics Panels Memory Hard drives ENWW Description HP Pavilion tx1000 Entertainment PC AMD Turion™ 64 Mobile Technology TL-60 (2.0-GHz, 1-MB L2 cache) TL-56 (1.8-GHz, 1-MB L2 cache) TL-52 (1.6-GHz, 1-MB L2 cache) TL-50 (1.6-GHz, 512-KB L2 cache) MK-36 (2.0-GHz, 512-KB L2 cache) - Page 7 Category Description 60-GB, 5400-rpm Optical drives ● ● DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe DVD±RW and CD-RW Super Multi Double-Layer Combo Drive Web camera 1.3-megapixel camera - fixed (no tilt) Diskette drive Supports external USB drive only Audio ●...
- Page 8 Category Docking Keyboard/ pointing devices Power requirements Security Operating system Serviceability ENWW Description S-Video-out USB (3) VGA (Dsub 15-pin) 2-pin AC power Docking support 12.1-inch keyboard with embedded numeric keypad TouchPad with 2 buttons and two-way scroll Touchscreen pen 4-cell 2.55-Ah Li-ion battery 6-cell 2.55-Ah Li-ion battery 65-W AC adapter with localized cable plug support (2-wire plug with ground pin, supports 2-pin DC connector)
-
Page 9: External Component Identification
External component identification Top components Pointing devices Item Component TouchPad on/off button TouchPad* Left and right TouchPad buttons* TouchPad light TouchPad scroll zone* *This table describes factory settings. To view and change pointing device preferences, select Start > Control Panel > Hardware and Sound >... -
Page 10: Keys
Keys Item Component Windows logo key Windows applications key Embedded numeric keypad keys Function keys ENWW Function Displays system information when pressed in combination with the key. Executes frequently used system functions when pressed in combination with a function key or the Displays the Windows®... -
Page 11: Display Components
Display components Item Component Internal microphones Integrated camera (select models only) Display release latch DVD button Media button Chapter 2 External component identification Function Record sound. Records video and captures still photographs. Opens the computer. Opens DVD software. ● When the computer is on, press the button to open the default DVD program and start a DVD in the optical drive. - Page 12 ● ● Off: The computer is off or in Hibernation. Receives a signal from the HP Remote Control. Turns off the display and initiates Sleep if the display is closed while the power is on. Allows a fingerprint logon to Windows instead of a password logon.
-
Page 13: Front Components
Blinking: The computer is in the Sleep state. ● Off: The computer is off or in Hibernation. ● Receives a signal from the HP Remote Control. Provides enhanced audio performance, including surround sound and other high-end audio output. Produces sound when connected to optional powered stereo speakers, headphones, ear buds, a headset, or television audio. -
Page 14: Right-Side Components
Item Component Wireless light *This table describes factory settings. For information about changing factory settings, refer to the user guides located in Help and Support. Right-side components Item Component Previous/rewind button Play/pause button Next/fast forward button Stop button Pen holder (select models only) USB port Pen tether hole (select models only) RJ-45 (network) jack... -
Page 15: Left-Side Components
Item Component (11) S-Video-out jack (12) Vent Left-side components Item Component WWAN external antenna connector Power connector ExpressCard slot Digital Media Slot Digital Media Slot light Optical drive Optical drive release button Chapter 2 External component identification Function Connects an optional S-Video device such as a television, VCR, camcorder, overhead projector, or video capture card. -
Page 16: Rear Components
Rear components Item Component Vent RJ-11 (modem) jack USB ports (2) Security cable slot ENWW Function Enables airflow to cool internal components. CAUTION: To prevent overheating, do not obstruct vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or thick rugs or clothing, to block airflow. -
Page 17: Bottom Components
Bottom components Item Component Vents (6) Battery lock latch Hard drive, SIM card, and WWAN bay Optical drive release latch Memory module compartment WLAN module compartment Chapter 2 External component identification Function Enable airflow to cool internal components. CAUTION: To prevent overheating, do not obstruct vents. - Page 18 Item Component Battery release latch Battery bay ENWW Function NOTE: To prevent an unresponsive system and the display of a warning message, replace with only a wireless module device authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region.
-
Page 19: Unknown User Password
Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password. NOTE: These steps also clear CMOS. Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. -
Page 20: Illustrated Parts Catalog
Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. ENWW Serial number location... -
Page 21: Computer Major Components
Computer major components Item Description (1a) Display assemblies 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera, fingerprint reader, and WWAN and WLAN antenna cables Chapter 4 Illustrated parts catalog Spare part number 441114-001 ENWW... -
Page 22: Spare Part Number
Item Description 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera and WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, touch screen display assembly with fingerprint reader and WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, touch screen display assembly with WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, display assembly with Web camera, fingerprint reader, and WWAN and WLAN antenna cables... - Page 23 Item Description Italy Japan Korea Latin America Saudi Arabia Spain Taiwan The United Kingdom The United States Windows XP keyboards for use in the following countries or regions: Brazil Canada Europe French Canada Latin America The United States Top cover (includes TouchPad and TouchPad cable, caps lock light board and cable, and top cover bumper pads) Power switch assembly (includes power switch board cable and power switch board actuator)
- Page 24 Item Description AMD Turion 64 Mobile Technology TL-60 (2.0-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-56 (1.8-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-52 (1.6-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-50 (1.6-GHz, 512-KB L2 cache) AMD Turion 64 Mobile Technology MK-36 (2.0-GHz, 512-KB L2 cache) (12) Fan/heat sink assembly (includes thermal paste and thermal pads)
-
Page 25: Display Assembly Components
Item Description 802.11a/b/g WLAN module for use in the following countries or regions. These countries or regions are categorized as the rest of the world (ROW): China, Ecuador, Haiti, Honduras, Pakistan, Peru, Qatar, South Korea, Uruguay, Venezuela 802.11a/b/g WLAN module for use in Japan. 802.11b/g WLAN module for use in the following countries or regions. - Page 26 Item Description Web camera module Display inverter (includes Mylar shield Display panels (include display panel cable, Web camera cable, and fingerprint reader cable) For use only with computer models equipped with touch screen display assemblies 441759-001 For use only with computer models not equipped with touch screen display assemblies Display LED board Display QuickPlay board...
-
Page 27: Plastics Kit
Plastics Kit Item Description Plastics Kit ExpressCard slot bezel Display connector cover (includes 1 captive screw, secured by a C-clip) WLAN module compartment cover (includes 1 captive screw, secured by a C- clip) Memory module compartment cover (includes 2 captive screws, secured by C- clips) Hard drive cover (includes 1 rubber foot and 2 captive screws, secured by C- clips) -
Page 28: Mass Storage Devices
Mass storage devices Item Description Hard drives (all 5400-rpm, include frame and hard drive connector) 160-GB 120-GB 80-GB 60-GB Optical drives (include bezel and bracket) DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe DVD±RW and CD-RW Super Multi Double-Layer Combo Drive ENWW Spare part number 441128-001... -
Page 29: Miscellaneous Parts
Miscellaneous parts Description 65-watt AC adapter ATSC/NTSC TV tuner antenna ATSC/NTSC/PAL TV tuner DVB-T antenna adapter DVB-T tuner HP backpack HP carrying case HP Remote Control III Infrared emitter with cable Optical wired mouse Power cords: Australia Denmark Europe India Israel... -
Page 30: Sequential Part Number Listing
394279-D61 Power cord for use in India 402018-001 65-watt AC adapter 405527-001 HP backpack 407159-001 802.11b/g WLAN module for use in the MOW countries or regions listed below: Argentina, Brazil, Canada, Chile, Mexico, Taiwan, the United States 407159-002 802.11b/g WLAN module for use in the ROW countries or regions listed below:... - Page 31 AMD Turion 64 Mobile Technology TL-52 processor (1.6-GHz, 1-MB L2 cache) 431373-001 AMD Turion 64 Mobile Technology TL-56 processor (1.8-GHz, 1-MB L2 cache) 435675-001 HP remote control III 436238-001 Optical wired mouse 436257-001 AMD Turion 64 Mobile Technology TL-60 processor (2.0-GHz, 1-MB L2 cache) 437803-001 AMD Turion 64 Mobile Technology MK-36 processor (2.0-GHz, 512-KB L2 cache)
- Page 32 Spare part Description number 441111-001 12.1-inch, WXGA, BrightView, touch screen display assembly with WWAN and WLAN antenna cables 441112-001 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera and WWAN and WLAN antenna cables 441113-001 12.1-inch, WXGA, BrightView, touch screen display assembly with fingerprint reader and WWAN and WLAN antenna cables 441114-001 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera, fingerprint reader, and...
- Page 33 Spare part Description number 441137-001 Base enclosure for use only with computer models not equipped with WWAN 441138-001 Plastics Kit (includes ExpressCard slot bezel, display connector cover, WLAN module compartment cover, memory module compartment cover, and hard drive cover) 441139-001 Rubber Feet Kit (includes 3 base enclosure rubber feet, 2 top cover bumper pads, 8 display bezel screw covers, pen cover, and WWAN external antenna cover) 441140-001...
- Page 34 Spare part Description number 441406-001 PC2-5300, 667-MHz, 1024-MB, 1-DIMM memory module 441758-001 Display panel for use only with computer models not equipped with touch screen display assemblies (includes display panel cable, Web camera cable, and fingerprint reader cable) 441759-001 Display panel for use only with computer models equipped with touch screen display assemblies (includes display panel cable, Web camera cable, and fingerprint reader cable) 442023-001 WWAN module...
-
Page 35: Removal And Replacement Procedures
Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Flat-bladed screwdriver ● Service considerations The following sections include some of the considerations that you should keep in mind during disassembly and assembly procedures. -
Page 36: Cables And Connectors
Cables and connectors CAUTION: locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. -
Page 37: Grounding Guidelines
Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry. -
Page 38: Packaging And Transporting Guidelines
Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations. ●... -
Page 39: Equipment Guidelines
Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps ● with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times. -
Page 40: Component Replacement Procedures
Make special note of each screw size and location during removal and replacement. Serial number Report the computer serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the computer. ENWW... -
Page 41: Battery
Battery Description 6-cell, 2.55-Ah battery 4-cell, 2.55-Ah battery Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 42: Pen
Description Before removing the pen, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power cord. -
Page 43: Hard Drive
Hard drive Description 5400-rpm, 160-GB 5400-rpm, 120-GB 5400-rpm, 80-GB 5400-rpm, 60-GB Before removing the hard drive, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. - Page 44 Remove the hard drive (2) from the hard drive bay. If it is necessary to remove the hard drive bracket and connector, remove the four Phillips PM3.0×3.0 hard drive bracket screws (1) from each side of the hard drive. Lift the bracket (2) straight up to remove it from the hard drive. Remove the connector (3) from of the hard drive.
-
Page 45: Wwan Module
WWAN module Description WWAN module Before removing the WWAN module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 46: Computer Feet
Computer feet Description Rubber Feet Kit (includes 3 base enclosure rubber feet, 2 top cover bumper pads, 8 display bezel screw covers, pen cover, and WWAN antenna cover) The computer feet are adhesive-backed rubber pads. ENWW Spare part number 441139-001 Component replacement procedures... -
Page 47: Optical Drive
Optical drive NOTE: All optical drive spare part kits include an optical drive bezel. Description DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe DVD±RW and CD-RW Super Multi Double-Layer Combo Drive Before removing the optical drive, follow these steps: Shut down the computer. -
Page 48: Memory Module
Memory module Description 1-DIMM, PC2-5300, 667 MHz, 1024-MB 1-DIMM, PC2-5300, 667 MHz, 512-MB Before removing the memory module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 49: Wlan Module
Pull the module (2) away from the socket at an angle and remove it. NOTE: the memory module socket. Reverse this procedure to install a memory module. WLAN module Description 802.11a/b/g WLAN module for use in Canada and the United States 802.11a/b/g WLAN module for use in the ROW countries or regions listed below: China, Ecuador, Haiti, Honduras, Pakistan, Peru, Qatar, South Korea, Uruguay, Venezuela 802.11a/b/g WLAN module for use in Japan... - Page 50 Remove the WLAN module: Position the computer with the front toward you. Loosen the Phillips PM2.0×4.0 screw (1) that secures the WLAN module compartment cover to the computer. Lift the right side of the WLAN module compartment cover (2) and swing it to the left. Remove the WLAN module compartment cover.
- Page 51 Pull the WLAN module (3) away from the socket at an angle and remove it. NOTE: the WLAN module socket. Reverse this procedure to install a WLAN module. Chapter 5 Removal and replacement procedures WLAN modules are designed with a notch (4) to prevent incorrect installation into ENWW...
-
Page 52: Keyboard
Keyboard Description Windows Vista keyboards Country or region Brazil Denmark, Norway, and Sweden Europe France French Canada Germany Italy Japan Windows XP keyboards Country or region Brazil Canada Europe Before removing the keyboard, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. - Page 53 Remove the four Phillips PM2.0×11.0 screws that secure the keyboard to the computer. Turn the computer display-side up, with the front toward you. Open the computer. Lift the rear edge of the keyboard and swing it toward you until it rests on the palm rest. Chapter 5 Removal and replacement procedures ENWW...
- Page 54 Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached and disconnect the keyboard cable (2). Remove the keyboard. Reverse this procedure to install the keyboard. ENWW Component replacement procedures...
-
Page 55: Switch Cover
Switch cover Description Switch cover (includes display convertible hinge base cover) Before removing the switch cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. - Page 56 Rotate the display clockwise approximately 45 degrees. Lift the left and right front corners of the switch cover (1) until it disengages from the computer. Rotate the switch cover (2) counterclockwise and remove it from the computer. Reverse this procedure to install the switch cover. ENWW Component replacement procedures...
-
Page 57: Display Assembly
Display assembly Description 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera, fingerprint reader, and WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, touch screen display assembly with Web camera and WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, touch screen display assembly with fingerprint reader and WWAN and WLAN antenna cables 12.1-inch, WXGA, BrightView, touch screen display assembly with WWAN and WLAN antenna cables... - Page 58 Remove the WLAN module compartment cover and disconnect the wireless antenna cables from the WLAN module (see Remove the following components:. Keyboard (see Switch cover (see Remove the display assembly: Close the computer and turn it upside down, with the front toward you. Loosen the Phillips PM2.0×4.0 screw (1) that secures the display connector cover to the computer.
- Page 59 Disconnect the display assembly cables (2) and (3) from the system board. Turn the computer display-side up, with the front toward you. Open the computer. Remove the display convertible hinge cover (1). Remove the two Phillips PM2.5×6.0 screws (2) that secure the display assembly to the computer. Disconnect the display panel cable (3) from the system board.
- Page 60 Lift the display (2) straight up and remove it. If it is necessary to replace any of the display assembly internal components, remove the four round rubber screw covers (1) and the four rectangular rubber screw covers (2). NOTE: part number 441139-001. ENWW The display bezel rubber screw covers are available in the Rubber Feet Kit, spare Component replacement procedures...
- Page 61 Remove the eight Phillips PM2.0×7.0 screws that secure the display bezel to the display assembly. NOTE: in the Display Screw Kit, spare part number 441124-001. Flex the inside edges of the right side (1) of the display bezel and the inside edges of the top and bottom sides (2) of the display bezel until the bezel disengages from the display assembly.
- Page 62 Disconnect the fingerprint reader board cable (1) from the fingerprint reader board. If it is necessary to replace the fingerprint reader board, remove the Phillips PM2.0×4.0 screw (2) that secures the fingerprint reader board and bracket to the display bezel. Remove the fingerprint reader board bracket (3).
- Page 63 If it is necessary to replace the Web camera, disconnect the camera cable (1) from the camera module. Remove the camera module (2) from the display enclosure. NOTE: If it is necessary to replace the display LED board, remove the two Phillips PM2.0×4.0 screws (1) that secure the display LED board to the to the display enclosure.
-
Page 64: Top Cover
Release the display QuickPlay board (2) as far as the display QuickPlay board cable will allow. Disconnect the display QuickPlay board cable (3) from the display QuickPlay board. NOTE: 441122-001. Remove the display QuickPlay board from the display enclosure. Reverse this procedure to reassemble and install the display assembly. Top cover Description Top cover (includes TouchPad and TouchPad cable, caps lock light board and cable, and... - Page 65 Switch cover (see Display assembly (see Remove the top cover: Turn the computer upside down, with the front toward you. Remove the five Phillips PM2.0×7.0 screws (1) and the three Phillips PM2.0×4.0 screws (2) that secure the top cover to the computer. Turn the computer right-side up, with the front toward you.
- Page 66 Lift the top cover straight up and remove it. Reverse this procedure to install the top cover. ENWW Component replacement procedures...
-
Page 67: Rtc Battery
RTC battery Description RTC battery Before removing the RTC battery, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 68: Power Switch Assembly
Power switch assembly Description Power switch assembly (includes power switch board cable and actuator switch) Before removing the power switch assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. - Page 69 Remove the display release hook assembly (3). NOTE: part kits. Disconnect the power switch board cable (1) from the system board. Remove the power switch board (2) and power switch actuator (3) from the base enclosure. Reverse this procedure to install the power switch assembly. Chapter 5 Removal and replacement procedures The display release hook assemblies are included with the base enclosure spare ENWW...
-
Page 70: Bluetooth Module
Bluetooth module Description Bluetooth module (includes Bluetooth module cable) Before removing the Bluetooth module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 71: System Board
System board Description For use only with computer models equipped with WWAN For use only with computer models not equipped with WWAN When replacing the system board, be sure that the following components are removed from the defective system board and installed on the replacement system board: Memory module (see ●... - Page 72 Remove the ExpressCard slot bezel (4) from the ExpressCard slot. NOTE: 441138-001. Use the optical drive connector (1) to lift the left side of the system board (2) until the power connector (3) is clear of the base enclosure. Pull the system board (4) away from the top cover at an angle and remove it. Reverse this procedure to install the system board.
-
Page 73: Pen Holder
Pen holder Description Pen holder Pen eject assembly Before removing the pen holder, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. -
Page 74: Audio/Infrared Board
Remove the pen holder (4). Reverse this procedure to install the pen holder. Audio/infrared board Description Audio/infrared board (includes audio/infrared board cable) Before removing the audio/infrared board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. -
Page 75: Wwan External Antenna Board
System board (see Pen holder (see Remove the audio/infrared board: Remove the two Phillips PM2.0×5.0 screws (1) that secure the audio/infrared board to the system board. Release the audio/infrared board (2) by sliding it away from you until the connectors on the front of the board disengage from the openings in the base enclosure. -
Page 76: Fan/Heat Sink Assembly
Keyboard (see Switch cover (see Display assembly (see Top cover (see Power switch assembly (see System board (see Remove the WWAN antenna board: Remove the two Phillips PM2.0×4.0 screws (1) that secure the WWAN external antenna board to the base enclosure. Remove the WWAN external antenna board and cable (2). - Page 77 Before removing the fan/heat sink assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power cord.
- Page 78 Remove the fan/heat sink assembly (3). NOTE: the fan/heat sink assembly and system board components, it may be necessary to move the fan/heat sink assembly from side to side to detach the assembly. NOTE: The thermal paste and thermal pads should be thoroughly cleaned from the surfaces of the fan/heat sink assembly (1) and the system board components (2) each time the fan/heat sink assembly is removed.
-
Page 79: Processor
Processor NOTE: All processor spare part kits include thermal paste. Desription AMD Turion 64 Mobile Technology TL-60 processor (2.0-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-56 processor (1.8-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-52 processor (1.6-GHz, 1-MB L2 cache) AMD Turion 64 Mobile Technology TL-50 processor (1.6-GHz, 512-KB L2 cache) AMD Turion 64 Mobile Technology MK-36 processor (2.0-GHz, 512-KB L2 cache) Before removing the processor, follow these steps:... - Page 80 Lift the processor (2) straight up and remove it. NOTE: embossed on the processor socket when you install the processor. Reverse this procedure to install the processor. ENWW The gold triangle (3) on the processor should be aligned with the triangle (4) Component replacement procedures...
-
Page 81: Setup Utility
Turn on or restart the computer. Before Windows opens and while “Press <F10> to enter setup” is displayed in the lower-left corner of the screen, press f10. Chapter 6 Setup Utility Only authorized technicians trained by HP should repair this equipment. All ENWW... -
Page 82: Changing The Language Of The Setup Utility
Changing the language of the Setup Utility The following procedure explains how to change the language of the Setup Utility. If the Setup Utility is not already running, begin at step 1. If the Setup Utility is already running, begin at step 2. To start the Setup Utility, turn on or restart the computer, and then press enter setup”... -
Page 83: Restoring Default Settings In The Setup Utility
Restoring default settings in the Setup Utility The following procedure explains how to restore the Setup Utility default settings. If the Setup Utility is not already running, begin at step 1. If the Setup Utility is already running, begin at step 2. To start the Setup Utility, turn on or restart the computer, and then press enter setup”... -
Page 84: Closing The Setup Utility
Closing the Setup Utility You can close the Setup Utility with or without saving changes. To close the Setup Utility and save your changes from the current session, use either of the following ● procedures: Press f10, and then follow the instructions on the screen. ●... -
Page 85: System Configuration Menu
System Configuration menu Select Language Support Enhanced SATA support (select models only) Boot Options Button Sound (select models only) Video memory up to (select models only) Diagnostics menu Select Hard Disk Self Test Secondary Hard Disk Self Test (select models only) Chapter 6 Setup Utility To do this Change the Setup Utility language. -
Page 86: Specifications
Specifications Computer specifications Dimensions Height (front to back) Width Depth Weight (with optical drive, hard drive, and battery) Input power Operating voltage Operating current Temperature Operating (not writing to optical disc) Operating (writing to optical disc) Nonoperating Relative humidity Operating Nonoperating Maximum altitude (unpressurized) Operating (14.7 to 10.1 psia) -
Page 87: 12.1-Inch, Wxga Brightview Display Specifications
Nonoperating NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures. 12.1-inch, WXGA BrightView display specifications Dimensions Height Width Diagonal Number of colors Contrast ratio Brightness Pixel resolution Pitch Format Configuration Backlight Refresh rate... -
Page 88: Hard Drive Specifications
Hard drive specifications Dimensions Height Width Weight Interface type Transfer rate Synchronous (maximum) Security Seek times (typical read, including setting) Single track Average Maximum Logical blocks Disc rotational speed Operating temperature *1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. †... -
Page 89: Dvd±Rw And Cd-Rw Super Multi Double-Layer Combo Drive Specifications
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive specifications Applicable disc Center hole diameter Disc diameter Standard disc Mini disc Disc thickness Track pitch Access time Random Full stroke Audio output level Cache buffer Data transfer rate 24X CD-ROM 8X DVD 24X CD-R 16X CD-RW 8X DVD+R... -
Page 90: System Dma Specifications
System DMA specifications Hardware DMA DMA0 DMA1* DMA2* DMA3 DMA4 DMA5* DMA6 DMA7 *PC Card controller can use DMA 1, 2, or 5. ENWW System function Not applicable Not applicable Not applicable Not applicable Direct memory access controller Available for PC Card Not assigned Not assigned System DMA specifications... -
Page 91: System Interrupt Specifications
System interrupt specifications Hardware IRQ IRQ0 IRQ1 IRQ2 IRQ3 IRQ4 IRQ5* IRQ6 IRQ7* IRQ8 IRQ9* IRQ10* IRQ11 IRQ12 IRQ13 IRQ14 IRQ15 *Default configuration; audio possible configurations are IRQ5, IRQ7, IRQ9, IRQ10, or none. NOTE: PC Cards may assert IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, or IRQ15. Either the infrared or the serial port may assert IRQ3 or IRQ4. -
Page 92: System I/O Address Specifications
System I/O address specifications I/O address (hex) 000 - 00F 010 - 01F 020 - 021 022 - 024 025 - 03F 02E - 02F 040 - 05F 044 - 05F 062 - 063 065 - 06F 070 - 071 072 - 07F 080 - 08F 090 - 091... -
Page 93: Chapter 7 Specifications
I/O address (hex) 220 - 22F 230 - 26D 26E - 26 278 - 27F 280 - 2AB 2A0 - 2A7 2A8 - 2E7 2E8 - 2EF 2F0 - 2F7 2F8 - 2FF 300 - 31F 320 - 36F 370 - 377 378 - 37F 380 - 387 388 - 38B... -
Page 94: System Memory Map Specifications
System memory map specifications Size 640 KB 128 KB 48 KB 160 KB 64 KB 15 MB 58 MB 58 MB 2 MB 4 GB 64 KB ENWW Memory address 00000000-0009FFFF 000A0000-000BFFFF 000C0000-000CBFFF 000C8000-000E7FFF 000E8000-000FFFFF 00100000-00FFFFFF 04800000-07FFFFFF 04800000-07FFFFFF 08000000-080FFFFF 08200000-FFFEFFFF FFFF0000-FFFFFFFF System memory map specifications System function... -
Page 95: Screw Listing
Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws and screw locks listed in this section are available in the Screw Kit, spare part number 441140-001, and the Display Screw Kit, spare part number 441124-001. Chapter 8 Screw listing ENWW... -
Page 96: Phillips Pm2.0×5.0 Captive Screw
Phillips PM2.0×5.0 captive screw Color Black Where used: (1) Two screws (secured by C-clips) that secure the hard drive cover to the computer (see on page (2) Two screws (secured by C-clips) that secure the memory module compartment cover to the computer (see Memory module on page ENWW... -
Page 97: Phillips Pm3.0×3.0 Screw
Phillips PM3.0×3.0 screw Color Silver Where used: 4 screws that secure the hard drive bracket to the hard drive (see on page Chapter 8 Screw listing Quantity Length 3.0 mm Thread Head width 3.0 mm 5.0 mm Hard drive ENWW... -
Page 98: Phillips Pm2.0×4.0 Screw
Phillips PM2.0×4.0 screw Color Black Where used: (1) Two screws that secure the WWAN module to the computer (see (2) Two screws that secure the WLAN module to the computer (see Where used: One screw that secures the fingerprint reader board to the display bezel (see assembly on page ENWW Quantity... - Page 99 Where used: (1) One screw that secures the display inverter to the display assembly (see on page (2) Two screws that secure the display LED board to the display assembly (see on page (3) Two screws that secure the display QuickPlay board to the display assembly (see on page Where used: 3 screws that secure the top cover to the computer (see Chapter 8 Screw listing...
- Page 100 Where used: 3 screws that secure the power switch assembly and the display release hook to the base enclosure (see Power switch assembly on page Where used: 3 screws that secure the pen eject assembly and the pen holder to the base enclosure (see Pen holder on page ENWW Phillips PM2.0×4.0 screw...
- Page 101 Where used: 2 screws that secure the audio/infrared board to the base enclosure (see Audio/infrared board on page Where used: 2 screws that secure the WWAN external antenna board to the base enclosure (see WWAN external antenna board on page Chapter 8 Screw listing ENWW...
-
Page 102: Phillips Pm2.0×4.0 Captive Screw
Phillips PM2.0×4.0 captive screw Color Black Where used: (1) One screw (secured by a C-clip) that secures the WLAN module cover to the computer (see module on page (2) One screw (secured by a C-clip) that secures the display connector cover to the computer (see assembly on page ENWW Quantity... -
Page 103: Phillips Pm2.0×11.0 Screw
Phillips PM2.0×11.0 screw Color Black Where used: 4 screws that secure the keyboard to the computer (see Chapter 8 Screw listing Quantity Length 11.0 mm Thread Head width 2.0 mm 4.0 mm Keyboard on page ENWW... -
Page 104: Black Phillips Pm2.0×7.0 Screw
Black Phillips PM2.0×7.0 screw Color Black Where used: 4 screws that secure the switch cover to the computer (see Where used: 5 screws that secure the top cover to the computer (see ENWW Quantity Length 7.0 mm Thread Head width 2.0 mm 5.0 mm Switch cover on page... -
Page 105: Phillips Pm2.5×6.0 Screw
Phillips PM2.5×6.0 screw Color Silver Where used: 2 screws that secure the display assembly to the computer (see on page Where used: 2 screws that secure the display assembly to the computer (see on page 100 Chapter 8 Screw listing Quantity Length 6.0 mm... -
Page 106: Phillips Pm2.0×5.0 Screw
Phillips PM2.0×5.0 screw Color Silver Where used: 2 screws that secure the top cover to the computer (see Where used: 4 screws that secure the fan/heat sink assembly to the system board (see assembly on page ENWW Quantity Length 5.0 mm Thread Head width 2.0 mm... -
Page 107: Silver Phillips Pm2.0×7.0 Screw
Silver Phillips PM2.0×7.0 screw Color Silver Where used: 8 screws that secure the display bezel to the display assembly (see on page ENWW Quantity Length 7.0 mm Thread Head width 2.0 mm 5.0 mm Display assembly Silver Phillips PM2.0×7.0 screw 103... -
Page 108: Phillips Pm2.0×3.0 Screw
Phillips PM2.0×3.0 screw Color Silver Where used: One screw that secures the Bluetooth module to the system board (see on page 104 Chapter 8 Screw listing Quantity Length 3.0 mm Thread Head width 2.0 mm 4.0 mm Bluetooth module ENWW... -
Page 109: Backup And Recovery
Backup and Recovery Recovering system information Tools provided by the operating system and Recovery Manager software are designed to help you with the following tasks for safeguarding your information and restoring it in case of a system failure: Back up your information regularly to protect your important system files. ●... -
Page 110: Using System Restore Points
To copy the screen and paste it into a word-processing document: Display the screen. Copy the screen: To copy only the active window, press To copy the entire screen, press Open a word-processing document, and then select Edit > Paste. Using system restore points When you back up your system, you are creating a system restore point. -
Page 111: Creating Recovery Discs
Click the System Restore button, and then click Next. The System Restore window opens. Follow the on-screen instructions. Creating recovery discs Recovery Manager creates a set of recovery CDs or DVDs for the computer. Use recovery discs to restore the operating system and software programs to factory settings, in case of system failure or instability. NOTE: Handle these discs carefully and keep them in a safe place. -
Page 112: Reinstalling Preinstalled Programs And Drivers
Recovery Manager replaces corrupted system files and reinstalls deleted system files within the program. In most cases, if the program you are reinstalling is still on your computer, the reinstallation process ● does not affect your personal settings. In all cases, if a program has been deleted from your computer, the reinstallation process reinstalls ●... -
Page 113: Recovering From The Recovery Discs
Recovering from the recovery discs To restore the system from the recovery discs: Back up all personal files. Insert the first recovery disc into the optical drive and restart the computer. Follow the on-screen instructions. Recovering from the partition on the hard drive You can perform a recovery from the partition on the hard drive from either the Start button or f11. -
Page 114: Updating Reinstalled Software
Updating reinstalled software After you perform a system recovery, connect to the Internet to update all reinstalled software. To access update links for the operating system and other software provided on your computer: Select Start > Help and Support. ▲ To update optional software, follow the instructions provided by the software manufacturer. -
Page 115: 10 Connector Pin Assignments
10 Connector pin assignments Audio-out (headphone) Audio-in (microphone) ENWW Signal Audio out, left channel Audio out, right channel Ground Signal Audio signal in Audio signal in Ground Audio-out (headphone) 111... -
Page 116: External Monitor
External monitor 112 Chapter 10 Connector pin assignments Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock ENWW... -
Page 117: Modem)
RJ-11 (modem) RJ-45 (network) ENWW Signal Unused Ring Unused Unused Unused Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused RJ-11 (modem) 113... -
Page 118: S-Video-Out
S-Video-out Universal Serial Bus 114 Chapter 10 Connector pin assignments Signal S-VHS color (C) signal Composite video signal S-VHS intensity (Y) signal S-VHS color ground TV-CD S-VHS intensity ground Composite video ground Signal +5 VDC Data - Data + Ground ENWW... -
Page 119: 11 Power Cord Set Requirements
11 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased. -
Page 120: Requirements For Specific Countries Or Regions
Requirements for specific countries or regions Region Australia Austria Belgium Canada Denmark Finland France Germany Italy Japan Korea The Netherlands Norway The People's Republic of China Sweden Switzerland Taiwan The United Kingdom The United States The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used. -
Page 121: 12 Recycling
12 Recycling Battery When a battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for computer battery disposal. ENWW Battery 117... -
Page 122: Display
Careful handling should be exercised when removing these components. NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display assembly that might require special handling at end-of-life. Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, contact your local authorities, or see the Electronic Industries Alliance (EIA) Web site at http://www.eiae.org. - Page 123 Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.
- Page 124 Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.
- Page 125 Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.
- Page 126 Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. Remove the backlight frame from the display panel. WARNING! handling the backlight to avoid damaging this component and causing exposure to the mercury.
- Page 127 Remove the backlight from the backlight frame. Disconnect the display cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.
-
Page 128: Index
Index AC adapter, spare part number 24, 25 administrator password 79 advanced Setup Utility features 78 applications key, Windows 5 audio, product description 2 audio-in jack location 8 pin assignments 111 audio-out jack location 8 pin assignments 111 audio-out S/PDIF jack 8 audio/infrared board removal 69 spare part number 18, 28,... - Page 129 display assembly removal 52 spare part numbers 16, 26, display bezel illustrated 20 removal 55 spare part numbers 20, 27, display components identifying 6 recycling 118 display connector cover illustrated 22 removal 53 display convertible hinge 7 display enclosure illustrated 20 spare part numbers 21, 28 display inverter illustrated 20...
- Page 130 removal 47 spare part numbers 17, 27, 28, 47 keyboard components 5 keypad keys 5 keys esc 5 fn 5 function 5 Windows applications 5 Windows logo 5 language support 77, 80 left-side components 10 lights battery 7 Digital Media Slot 10 drive 7 power 7, 8 wireless 9...
- Page 131 serviceability 3 wireless 2 product name 1 rear components 11 recovery discs 107 recovery partition, deleting 109 recovery, system 108 remote control, spare part numbers 24, 25, 26 removal/replacement preliminaries 30 procedures 35 restore points 106 right-side components 9 RJ-11 jack location 11 pin assignments 113 RJ-45 jack...
