product description

Enware Touch-Free Wall Sensor Tap is a sensor operated, hands-free tap that is installed onto walls
above sinks, basins or wash troughs. It operates by sensing a hand in front of the sensor unit. Once
the sensor is activated, the solenoid valve will remain open and water will flow as long as the hand
is within the sensor range. If hand is moved away from the sensor range, the valve is closed after 6
seconds.
If the solenoid valve remains open for more that 45 seconds, the unit will time-out and close the
valve automatically. This is intended to conserve water and prevent overflows.
COMPONENTS
The wall sensor tap kit comes
standard with a fixed aerated
spout with sensor panel and
bracket, a 1/2" solenoid valve,
and a 24 volt DC transformer.
dimensions
SENSOR & SPOUT
190
200
IR SENSOR
All measurements are in millimetres unless otherwise stated.
2 Call 1300 369 273
TR20 TORX BIT
SPOUT
SENSOR
13 MAX.
IN-WALL
ADJUSTMENT
48 78
SENSOR CONNECTOR SOLENOID CABLE 3m
CABLE
SOLENOID
SOLENOID
91
TRANSFORMER
TRANSFORMER
WITH 4.5m CABLE
91
55
