ENWARE-ORAS
ELECTRONIC TAPWARE
Installation and Maintenance Instructions
CUBISTA
ENM6420
ENM6450
VEGA
ENM6222
ENM6250
ELECTRA GOOSE NECK
ENM6320
ENM6323
ENM6350
ENM6353
VIVA
ENM6120
ENM6150
I00397_Nov 21
1300 369 273 | info@enware.com.
enware.com.au
au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUBISTA ENM6420 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for enware CUBISTA ENM6420

  • Page 1 ENWARE-ORAS ELECTRONIC TAPWARE Installation and Maintenance Instructions CUBISTA ENM6420 ENM6450 VEGA ENM6222 ENM6250 ELECTRA GOOSE NECK ENM6320 ENM6323 ENM6350 ENM6353 VIVA ENM6120 ENM6150 I00397_Nov 21 1300 369 273 | info@enware.com. enware.com.au...
  • Page 2: Table Of Contents

    Product Descriptions Technical Data Installation Compliance CUBISTA ENM6450 CUBISTA ENM6420 VEGA ENM6222 VEGA ENM6250 ELECTRA GOOSENECK ENM6320 Components & Spare Parts ELECTRA GOOSENECK ENM6323 ELECTRA GOOSENECK ENM6350 ELECTRA GOOSENECK ENM6353 VIVA ENM6120 VIVA ENM6150 General Instructions Installation Mixer Modification...
  • Page 3: Product Descriptions

    ENM6353 - 170mm Reach Spout - Battery ENM6320 - 170mm Reach Spout - Mains Powered ENM6323 - 170mm Reach Spout - Mains Powered VIVA SERIES SENSOR TAP WITH OPTIONAL TEMPERATURE ADJUSTER ENM6150 - BATTERY ENM6120 - MAINS POWERED www.enware.com.au Call 1300 369 27...
  • Page 4: Technical Data

    IP 67 installation compliance Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA), AS/NZS3500 and the manufacturer’s instructions. Installations not complying with PCA, AS/NZS 3500 and the manufacturer’s instructions may void the product and performance warranty provisions.
  • Page 5: Cubista Enm6450

    SLMS611 Strainer/ Check Valve (1 set) SPEX - Flexi Hoses (pair) SLMS612 Battery Casing (includes ENMS206 battery) Fixing Plate and Nut SLMS644 CUBISTA ENM6420 DESCRIPTION SALES CODE Temperature Control handle ENMS216 Solenoid Membrane ENMS212 Support Solenoid valve ENMS207 Sensor 1001424V...
  • Page 6: Vega Enm6222

    ENMS220 6 lpm aerator only STD 672444 G3/8 - G1/2 Adaptor/Mesh SLMS611 Strainer/Check Valve (1 set) 10 Mesh Strainers x 2 ENMS214 11 SPEX - Flexi Hoses (pair) SLMS612 12 Fixing Plate and Nuts SLMS605 Call 1300 369 273 www.enware.com.au...
  • Page 7: Electra Gooseneck Enm6320

    G3/8 - G1/2 Adaptor/Mesh SLMS611 Strainer/Check Valve (1 set) 170mm spout ENMS235 SPEX - Flexi Hoses (pair) SLMS612 10 Fixing Plate and Nut SLMS644 Transformer ENMS231 Extended Transformer 4.5M ENMS230 Extension cable 3m 673841 Extension cable 8m 673840 www.enware.com.au Call 1300 369 27...
  • Page 8: Electra Gooseneck Enm6350

    Aerator 6L/min TJ ENMS221 Mesh Strainers x 2 ENMS214 G3/8 - G1/2 Adaptor/Mesh SLMS611 Strainer/Check Valve (1 set) 10 170mm spout ENMS235 11 SPEX - Flexi Hoses (pair) SLMS612 12 Fixing Plate and Nut SLMS644 Call 1300 369 273 www.enware.com.au...
  • Page 9: Viva Enm6120

    Mesh Strainers x 2 ENMS214 G3/8-G1/2 Adaptor /Mesh SLMS611 Strainer/Check Valve (1 set) SPEX - Hoses (pair) SLMS612 10 Fixing Plate and Nuts SLMS605 11 Battery Casing (includes battery) ENMS206 12 Lithium 6V Battery 2CR5 ENMS204 www.enware.com.au Call 1300 369 27...
  • Page 10: General Instructions

    Tools Required for Installation: spanner, flat head screw driver, thread seal tape or equivalent. It is advised NOT TO position taps directly in front of a mirror where the sensor could reflect back causing false operation. Call 1300 369 273 www.enware.com.au...
  • Page 11: Mixer Modification

    4. Insert chromed plastic cover cap in place of temperature adjustment handle. IMAGE 1 COLD OR PRE-MIXED WATER 1. Repeat steps 1-4 as above in PRE-SET TEMPERATURE 2. Unscrew the hot water flexi hose* and screw in the plug in place of the inlet pipe. IMAGE 7 www.enware.com.au Call 1300 369 27...
  • Page 12: Basin Mount Instruction

    Flexi hose making sure the hot water is connected to the hot water hose. Note: It is the manufacturer’s recommendation that the Flexi (SPEX) hoses are connected directly to isolation valves Call 1300 369 273 www.enware.com.au...
  • Page 13 For Battery Models, secure the battery case to the flexi hose in an upside down position with the battery connector facing down (facing the connection upside down prevents water pooling near the connection) using the plastic ties and battery holder provided. IMAGE 19 IMAGE 19 www.enware.com.au Call 1300 369 27...
  • Page 14: Instructions

    See Installation Instructions on Page 13 IMAGES 17 & 18 WARNING: Failure to align the connections correctly will result in permanent damage to the sensor & void warranty Turn power and water supply on and test operation. IMAGE 35 Call 1300 369 273 www.enware.com.au...
  • Page 15: Changing The Battery

    3. Detach the sensor cable and open the battery casing. NOTE: cover is tightly fitted. 4. Change the battery^. 5. Replace battery casing cover and connect sensor lead. 6. Replace battery casing into base of tap body. IMAGE 37 7. Re-assemble the tap by following instructions Page 14. www.enware.com.au Call 1300 369 27...
  • Page 16: Servicing Changing The Sensor

    IMAGE 45. IMAGE 44 When re-connecting the ‘new’ sensor cables it is critical that the white lines on the connectors align prior to pressing together. 6. Re-assemble tap by following instructions on Page 14 IMAGE 45 Call 1300 369 273 www.enware.com.au...
  • Page 17: Changing The Solenoid

    White strips must align on transformer cable IMAGE 18 maintenance CLEANING THE FILTERS ON INLET HOSES Enware Product should be cleaned with a soft damp cloth using only mild liquid detergent or soap and 1. Ensure the water supply is turned off. water.
  • Page 18: Sensor Program

    Apple, the Apple logo, iPhone, iPad, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Google Play and the Google Play logo are trademarks of Google Inc. Call 1300 369 273 www.enware.com.au...
  • Page 19 HOW TO CHANGE THE SENSOR PROGRAM SETTINGS 1. To access the sensor function program, press the settings button 2. Enter the password. (Contact Enware for default password, or your selected password if already registered). 3. Change the settings as desired.
  • Page 20 Set the flow rate of the tap outlet to monitor water consumption. [Set from 0.1 up to 40 l/min.] Product Location: Enter the name of your choice to identify the location of the tap. Password: Set the password of your choice to limit access to the settings by others (e.g. for public places). Call 1300 369 273 www.enware.com.au...
  • Page 21: Troubleshooting

    Solenoid valve loose in body Ensure solenoid valve is secure in tap body – tighten if needed, however do not overtighten. Follow steps in Maintenance and Servicing instructions. www.enware.com.au Call 1300 369 27...
  • Page 22 Temperature ( Page 11) Inlet hose is kinked Re-install inlet hose without any sharp bends, replace hose if necessary For further assistance, contact the Enware Service Team on 1300 369 273. Call 1300 369 273 www.enware.com.au...
  • Page 23: Warranty

    All notifications and accompanying forms must be sent to us marked for the attention of the Enware Australia Pty Except as provided or referred to in this document, we Limited, 9 Endeavour Road, Caringbah NSW 2229. We...
  • Page 24 ADDRESS: 9 Endeavour Rd Caringbah NSW 2229 Australia POSTAL ADDRESS: P.O. Box 2545, Taren Point NSW 2229 Australia PHONE: +61 2 8556 4000 1300 369 273 (AUS) WWW.ENWARE.COM.AU INFO@ENWARE.COM.AU ABN 23 003 988 314...
