Enware Touch Free Sensor Tap

Installation, Operating & Maintenance Instructions

Active Sense System

Wave On - Wave Off System

I00271_APR2017

www.enware.com.au

Enware Australia Pty Limited

9 Endeavour Rd Caringbah NSW 2229 Australia

Ph: +61 2 8556 4000 Fax: +61 2 8556 4055

ENM620/ENM621

Table of Contents

Need help?

Do you have a question about the ENM620 and is the answer not in the manual?

Questions and answers

Summary of Contents for enware ENM620

Page 1 Enware Touch Free Sensor Tap ENM620/ENM621 Installation, Operating & Maintenance Instructions Active Sense System Wave On - Wave Off System I00271_APR2017 www.enware.com.au Enware Australia Pty Limited 9 Endeavour Rd Caringbah NSW 2229 Australia Ph: +61 2 8556 4000 Fax: +61 2 8556 4055...
Page 2: Product Components Front Of Wall
ENMWMC1L6 - 4.5Lpm ACTIVE SENSE Sensor below outlet Active Sense Front of Wall Component Only with 200mm Fixed Spout with Laminar Flow - Mains Powered ENMAMC1L3 - 8Lpm ENMAMC1L5 - 6Lpm MAINS ENMAMC1L6 - 4.5Lpm Page 2 Call 1300 369 273 www.enware.com.au...
Page 3: Product Components In-Wall
ENMWBC2L5 - 6 Lpm ENMWBC2L6 - 4.5 Lpm BATTERY ACTIVE SENSE: BATTERY OPERATED ENMABC2L3 - 8 Lpm ENM620 - 6V Battery Op ENMABC2L5 - 6 Lpm In-Wall Component ENMABC2L6 - 4.5 Lpm NOTE: When placing an order, “In Wall” (back of wall) component is ordered separately to “Front of Wall”...
Page 4: Table Of Contents
Enware Touch Free Sensor Tap CONTENTS PRODUCT COMPONENTS FRONT OF WALL PAGE 2 PRODUCT COMPONENTS IN-WALL PAGE 3 TECHNICAL INFORMATION PAGE 5 INSTALLATION COMPLIANCE PAGE 7 INSTALLATION PROCEDURE - IN-WALL PAGE 8 INSTALLATION PROCEDURE - FRONT OF WALL PAGE 11...
Page 5: Technical Information
Wave on wave off In-Wall Components 190 - (FLANGE DIMENSION) 6 THRU TYP G1/2" (BSP) G1/2" (BSP) INLET OUTLET DENOTES 310 X 190 FACE PLATE POSITION 15 MM IN WALL ADJUSTMENT TRIM DOWN TO SUIT AFTER INSTALLATION Call 1300 369 273 www.enware.com.au...
Page 6 8, 15, 30, 45, 60, 90, 120 or 180 seconds settings available * In accordance with AS/NZ3500. Enware products must be installed in accordance with the Plumbing Code of Australia (PCA), AS/NZS3500 and the manufacturer’s instructions. Installations not complying with PCA, AS/NZS 3500 and the manufacturer’s instructions may void the product and performance warranty provisions.
Page 7: Installation Compliance
INSTALLATION COMPLIANCE Installation This ENWARE product should be installed using the appropriate Standard, Code of Practice and legislation applicable to each state and following the details outlined in this section. They must be installed by a licensed plumber. To ensure that the valve operates correctly, it is necessary that the pipework is thoroughly flushed with clean water before it is installed as per AS/NZS 3500.1.
Page 8 STEP 1. Determine the desired location for the box with relation to the spout height off the basin. AUSHFG specifies the spout should be 1120mm off finished floor level.* * Recommended height of spout (point of water discharge) for Type A and Type B Clinical Hand Washing Bay is 1120mm off finished floor level when combined with basin at a height of 865mm, according to AUSHFG (Australasian Health Facility Guidelines).
Page 9 STEP 2. If installing within a frame wall, fit mounting timber in the desired location for Box support. Enware recommends 13mm ply wood fixed between two vertical in-wall studs. Important: The depth of Box from finished wall to the back of the Box must be between 85mm-100mm.
Page 10 Ensure at least 50mm of cable is available in the Box to connect to the sensor. If the cable is not long enough, use an extended transformer (4.5m - ENMS230 - available from Enware). Use a conduit to run the transformer cable between the power point and the box, to allow for easy component replacement in future.
Page 11 STEP 1. Once the finished wall is complete, the protruding section of the Box front cover needs to be trimmed so it finishes flush with finished wall face. Discard cover. Check that no part of the Box protrudes past the finished wall except the 1/2" BSP thread for the spout, and deburr trimmed edges of the Box.
Page 12 STEP 4. Adjust the spout support nut so it sits hard against the back of the support bracket. STEP 5. Cut back the 1/2 inch outlet thread so you are left with 15mm protruding past the support bracket. STEP 6. Apply thread sealant or sealing tape to outlet thread and screw on the spout retainer using 3/8”...
Page 13 STEP 8. Activate the sensor by placing hand in front of sensor. Test solenoid operation by listening for the solenoid to click open and close. (Water is still off.) While solenoid is in off position, turn water supply on via the isolation valve. (Valve slot in vertical position).
Page 14 STEP 13. Fit the grub screw on the underside of the spout, and tighten using the 2.5mm Allen key to secure it in place. Ensure the grub screw fits into the groove of the spout retainer, and is fitted all the way into the spout.
Page 15 To turn ON: To turn OFF: Place hand in front of sensor for 1 Place hand in front of sensor for 1 second, at a distance of 10 cm. second, at a distance of 10 cm. Water starts to flow. Water flow stops.
Page 16 To turn ON: Place hand under spout, in front of sensor. Water starts to flow. To turn OFF: Simply move hand away from sensor. Water flow stops.  After turning ON, the tap runs for at least 2 seconds. (Intelligent Afterflow Function) During this time the tap cannot be turned off.
Page 17 The ENWARE Touch Free Sensor Tap will only require minimal preventative maintenance work to ensure it operates at its optimum level of performance. Every few years or as required, spout aerator and strainer check valve assembly should be checked for debris, and cleaned if required.
Page 18 CLR), checked for physical damage and then thoroughly rinsed with clean water. Replace with a new strainer/ check valve assembly if required. (Enware Part ATMS693) STEP 3. When service is complete, re-fit check valve/strainer assembly and hand tighten with the Allen key.
Page 19 Check internal sealing membrane for debris or damage, by taking off the lower cap. If damaged, replace with a new solenoid membrane (Enware Part - ENMS212). The membrane and lower cap should be cleaned, checked for physical damage and then thoroughly rinsed with clean water.
Page 20 Remove the battery from within the box by pulling the battery casing vertically upward, and then disconnect it from sensor cable. STEP 3. Open the casing cover and change the battery. Use only 6V Lithium 2CR5 battery (Enware Part ENMS204). Fit the battery casing cap back on. STEP 4.
Page 21: Service And Maintenance
Cleaning Enware Product should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive. Use of unsuitable cleaning agents may damage the surface. Any damage caused in this way will not be covered by warranty.
Page 22 When required for disinfection purposes, the internal components can be flushed with full hot water temperature (maximum 70 °C) by using the following procedure. 1. To access the internal components, first turn water off to the sensor tap, then remove the spout, dress flange and the face plate. 2.
Page 23: Changing The Sensor Program
Refer to program charts. Once the program is chosen, wait for 5 seconds. The LED will blink back to confirm the program number it is set to. The sensor is now set. Page 23 www.enware.com.au Call 1300 369 273...
Page 24 – – – * Sensitivity level: 1 - most sensitive, 2 - less sensitive for difficult light conditions or interference, 3 - the least sensitive for the most difficult light conditions or interference. Page 24 Call 1300 369 273 www.enware.com.au...
Page 25 - 15 second lock out time after off Nurse mode A - 10 sec ON 30 sec OFF 20 sec 20-100mm Automatic Flow OFF – – – – – Automatic Flow 12h ON – – – – – Page 25 www.enware.com.au Call 1300 369 273...
Page 26: Troubleshooting
Servicing instructions and replace if battery/power supply needed. c) Power supply is turned off c) Turn on power supply d) Sensor is constantly activated d) Remove interfering object by an object in front of sensor Call 1300 369 273 www.enware.com.au...
Page 27: Product Warranty
* 3 Years: 2 years Oras parts and labour warranty from the date of purchase. After 2 years an additional 1 year Enware replacement part warranty is applicable to the electronics and sensor only. This extended parts only warranty is applicable to Oras Electronics products purchased within Australia.
Page 28 Page 28...
