Multi-location wiring
Individually pair each of the wall controls with the fan
receiver using the pairing instruction. See page 25.
Wallcontroller 1
Wall Control 1
Line/Hot
Red
Green (Green or Bare)
Neutral/White
FR- W 1 80 9
2
3
4
Wallcontroller 2
Wall Control 2
1.
Wall Outlet
2. Wall Control
3. Wall Mounting Plate
4. Mounting Plate Screws
5. Wallplate
5
If Applicable
Wallcontroller 3
Wall Control 3
FAN
