HP OmniBook 2000/5700 Corporate Evaluator’s Guide...
Page 2
Notice This manual and any examples contained herein are provided “as is” and are subject to change without notice. Hewlett-Packard Company makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard Co.
Page 3
Agreement. Product Recovery CD -ROM. If your computer was shipped with a product recovery CD-ROM: (i) The product recovery CD-ROM and/or support utility software may only be used for restoring the hard disk drive of the HP computer with which...
Page 4
the product recovery CD-ROM was originally provided. (ii) The use of any operating system software by Microsoft contained in any such product recovery CD-ROM shall be governed by the Microsoft End User License Agreement (EULA). Transfer of Rights in Software. Customer may transfer rights in the software to a third party only as part of the transfer of all rights and only if Customer obtains the prior agreement of the third party to be bound by the terms of this License...
Contents 1. Introduction ... 1-1 Taking Inventory ... 1-4 Included in the OmniBook 2000/5700 box ... 1-4 Models and configurations ... 1-5 Power Management ... 1-7 To start the OmniBook ... 1-7 To stop the OmniBook ... 1-8 Effects of stopping the OmniBook ... 1-9 Power states after stopping the OmniBook ...
Page 6
To increase performance ... 2-14 To use DriveSpace compression ... 2-14 To resolve infrared printing problems ... 2-15 To synchronize an external display or projector ... 2-16 3. Using Windows 95 ... 3-1 Installing Windows 95 ... 3-3 To prepare for software installation ... 3-3 To install Windows 95 ...
Page 7
To install the Xircom Ethernet IIps PC card ... 4-8 To install a 3Com 3C562 EtherLink III LAN+33.6 Modem PC card . 4-10 To install an Intel EtherExpress PRO/100B PCI LAN adapter ... 4-11 Working with Windows NT 3.51 ... 4-13 To understand power management limitations ...
Page 8
Technical Specifications ... 8-9 Getting Assistance and Support ... 8-15 To look up technical information ... 8-16 To get HP OmniBook assistance ... 8-20 To find electronic support services ... 8-21 To contact Customer Support ... 8-23 To get repair assistance ... 8-24 Hewlett-Packard Limited Warranty Summary ...
Page 10
PC CardBus. 64-bit graphics accelerator with 2 MB EDO video memory. These features illustrate the uncompromising performance of HP's most powerful notebook PCs ever, laptops fully capable of replacing a desktop computer. Optional docking systems allow single-action connection to multiple peripherals, and the PC CardBus-enabled 32-bit PC card slots allow 100-Mbps networking and other high- bandwidth applications.
Page 11
A three-year worldwide limited warranty affirms the OmniBook 2000/5700's unmatched quality and reliability. HP's unlimited customer service has earned top ratings for notebook service and support and is available for the price of the phone...
Introduction Taking Inventory Taking Inventory This section describes: What’s included in the OmniBook 2000/5700 box. OmniBook 2000/5700 models. Included in the OmniBook 2000/5700 box OmniBook 2000/5700. Installation and Setup guide. Microsoft Windows 95 Manual and Certificate of Authenticity. Support and Service booklet.
166-MHz HP OmniBook 5700 CT 5 /150 Model Product Number Pentium Processor with MMX technology 2000 F1352A 150-MHz HP OmniBook 2000 CS 5 /133 Model Product Number Pentium Processor 1440 F1371A 133-MHz HP OmniBook 2000 CT 5 /33 Model Product Number...
Introduction Power Management Power Management The OmniBook offers several power states to accommodate various user situations. The blue On/Suspend button is the typical method for starting and stopping your OmniBook; however, additional options allow you to manage power efficiently. This section describes the following: Starting the OmniBook.
To stop the OmniBook Two of the four stop options feature “Instant On” which allows you to quickly resume where you left off. The preferred stopping method depends on how you intend to use the OmniBook next. To stop with “Instant-On”: Press the blue On/Suspend button while ac power is connected.
Introduction Power Management Effects of stopping the OmniBook When you press this: The OmniBook does this: On/Suspend button Turns off the display. (with ac adapter) Maintains current session. Maintains network connections. Maintains SCSI devices. Charges the battery. Restarts quickly (“Instant-On”). On/Suspend button Turns off the display.
Power states after stopping the OmniBook Method of Stopping Power State On/Suspend button Display Off (with ac adapter) On/Suspend button Suspend (no ac adapter) Fn+F12 key Hibernate (no ac adapter) Off button For Windows 95, the Start button provides two commands that stop the OmniBook. Suspend changes the OmniBook to the Suspend state.
Introduction Power Management To set up a hibernation partition If you have added memory beyond 64 MB, or have replaced or repartitioned the hard disk drive, the hibernation partition may be incorrect. You can use the following steps to correctly configure a hibernation partition. C A U T I O N This process deletes all files on the hard disk drive.
The maximum size of a DOS partition is 2GB. If you have a 3GB hard disk drive, partition the remainder of the hard disk drive as D:\. Power status The icons on the small LCD indicate power conditions—ac adapter use, battery status, charging status.
Introduction Recovering Files, Drivers, and Applications Recovering Files, Drivers, and Applications This section describes how to recover lost OmniBook files, drivers, and HP applications, as well as information about recovering a damaged hard disk drive or lost Recovery CD. In this section you’ll find information about the following: Using the OmniBook Recovery CD.
Windows for Workgroups system shipped with the OmniBook. HPUTILS For Windows for Workgroups and Windows 95: Use this to pick and install optional HP OmniBook applications, including Appointment Book, Phone Book, Calculator, the online User’s Guide, Tools, Diagnostics. DRIVERS...
If you need to recover an operating system, OmniBook drivers, or any other program on the Recovery CD, but do not have access to a CD-ROM drive, HP Service can recover these files for you. The cost is a standard charge equal to one-half the hourly labor rate.
Recovery CD or your custom build process. To update the BIOS Hewlett-Packard may update the BIOS to enhance the capabilities of the OmniBook 2000/5700. Updates will be available from HP Electronic Support Services. Refer to the OmniBook Support chapter (page 8-23) for more information. Important Because a BIOS update replaces the previous version, it is essential that you follow these instructions exactly.
Introduction Using OmniBook Security Using OmniBook Security Your OmniBook provides several ways for you to identify and protect your computer including the following: Setting up drive lock security and password protection. Attaching a security cable. To use password security You can protect your OmniBook against unauthorized use by activating password security.
Verify New Password fields. If you do not, your hard disk drive will be unprotected. HP can remove forgotten passwords (see page 8-28 for information). C A U T I O N Store a copy of your password in a safe place. Without the password, you will be unable to retrieve your data.
Introduction Using OmniBook Security To disable drive lock Drive lock is enabled by default, but can be disabled. 1. Press Fn+F2 to start the System Configuration Utility. 2. Select Password, then select Password Options. 3. Select Disable Hard Drive Lock, then press the space bar. 4.
Identifying System Resources These default values offer maximum utility for most users; however, alternate configurations exist in the System Configuration Utility, which lists port and audio device configurations in the Input/Output menu. The tables in this section show initial resource usage. Plug-and-play operating systems, drivers, and the SCU may change some entries.
Page 28
Introduction Identifying System Resources System Input/Output Addresses (100-3FF) 15C-15D Super I/O 170-177 Secondary HDD controller (internal CD-ROM) 1F0-1F7 Internal hard disk drive 200-207 Joystick 220-22F Crystal sound 2F8-2FF COM2 (infrared port) 330-331 MPU 401 (MIDI) Secondary HDD controller (internal CD-ROM) 378-37F LPT1 (printer port) 388-38B...
To free COM2 by disabling infrared The OmniBook automatically assigns PC card modems to COM3. If infrared functionality is not required, you can free COM 2 for your modem. 1. Restart the OmniBook. 2. Press F2 when prompted to enter the System Configuration Utility (SCU). 3.
Page 32
Note If you chose Windows for Workgroups 3.11 during the initial setup of the OmniBook 2000/5700, you can make copies of the MS-DOS and Windows for Workgroups Disks from the Hard Drive. When Windows starts for the first time, it asks you to make these disks, or you can click the Make OmniBook Installation Disks icon in the OmniBook group.
Installing Windows 3.x This section describes how to set up the operating system and drivers including the following: Reformatting the hard drive. Installing MS-DOS. Installing Windows 3.1 or Windows for Workgroups 3.11. Installing Windows 3.x device drivers. To reformat the hard drive 1.
If you are installing Windows for Workgroups, do not install networking at this time. Follow the instructions in the application note for the network card you are using. Application notes are available on the HP website at: http://www.hp.com/go/omnibook. To install Windows 3.x device drivers This procedure edits your AUTOEXEC.BAT, CONFIG.SYS, CONTROL.INI,...
Page 35
OmniBook Support Utility Disk is required if you install from CD-ROM. 1. Insert the CD-ROM drive and attach the floppy disk drive to the parallel port. 2. Insert the OmniBook Support Utility Disk in the floppy disk drive. 3. Turn on the OmniBook or exit Windows and press Ctrl+Alt+Del to reboot. 4.
Intel EtherExpress PRO/100B PCI LAN adapter. To install a Xircom Ethernet IIps PC card Requirements OmniBook 2000/5700 with Windows for Workgroups 3.11 installed. Xircom Ethernet IIps PC card. Xircom Network Driver Disk 2 (Version 2.30 7/25/96). This procedure assumes that Card and Socket Services are being utilized.
You must allocate 32KB of memory for PC card support. Follow the steps to maximize memory on page 2-12. Working With Windows for Workgroups. Requirements OmniBook 2000/5700 with Windows for Workgroups 3.11 installed. 3Com 3C562 EtherLink III LAN+33.6 Modem PC card. 3Com driver: ELPC3X.DOS (4/30/95). Configuration Interrupt: 3.
Page 38
Using Windows 3.x Installing Cards 1. Start Windows for Workgroups. 2. Insert the PC card. 3. From Program Manager, double-click Network group, then Network Setup. 4. If the Drivers button is grayed, click the Networks button, then select Install Microsoft Windows Network, then click OK. 5.
To install an Intel EtherExpress PRO/100B PCI LAN adapter Requirements OmniBook 2000/5700 with Windows for Workgroups 3.11 installed. Intel EtherExpress (TM) PRO/100B PCI adapter (8465B). Intel drivers: E100B.DOS DOS NDIS 2.01 driver version 1.34 03/13/96. E100B.386 Windows for Workgroups version 1.70 05/01/96.
Using Windows 3.x Working with Windows for Workgroups Working with Windows for Workgroups This section describes how to customize the OmniBook for use with Windows for Workgroups including the following: Maximizing memory. Increasing performance. Using DriveSpace compression. Resolving infrared printing problems. Synchronizing an external display or projector.
To maximize memory Certain situations require a large segment of conventional memory. For instance, an application may require SCSI drivers as well as network drivers, and still have sufficient conventional memory. In Windows 3.1 and Windows for Workgroups 3.11, conventional memory is freed by optimizing upper memory and loading specified device drivers high.
Using Windows 3.x Working with Windows for Workgroups To increase performance In Windows for Workgroups, you can get your OmniBook to work even faster by optimizing the amount of memory reserved for reading and writing files. 1. From Control Panel, double-click Enhanced. 2.
Try removing the PC card before printing. You may have problems with infrared printing (on LPT3) after installing an HP DeskJet 340 printer. The DeskJet 340 drivers may also affect infrared printing (on LPT3) for other types of infrared printers. If this occurs, do one of the...
OmniBook Tools does not function in Windows 3.1; however, all of the functions of OmniBook Tools are present in the System Configuration Utility. Infrared does not function on the OmniBook 2000/5700. There are no infrared drivers for Windows 3.1 2-14...
OmniBook 2000/5700. Windows 95 Installation CD. The OmniBook 2000/5700 Support Utility Disk. OmniBook 2000/5700 Internal CD-ROM, an attached SCSI CD-ROM drive, or access to a networked CD-ROM drive. Blank floppy disk (Windows 95 creates a Setup Boot Disk during install).
Installing power management support. Installing video support. To prepare for software installation 1. Insert the OmniBook 2000/5700 Support Utility Disk in the A drive. 2. Restart the OmniBook 2000/5700. 3. Choose Exit to MS-DOS from the MS-DOS menu. The Support Utility Disk will load the Internal and SCSI CD-ROM drivers.
Using Windows 95 Installing Windows 95 To install Windows 95 1. Insert the Windows 95 installation CD. 2. Type D:\SETUP, then press Enter. 3. After the Windows 95 setup program performs a routine check on your system, press Enter to continue. The Windows 95 Setup program loads a series of files.
23. Click Close at the Windows 95 Welcome Screen. To install power management support Requirements OmniBook 2000/5700 with Windows 95 installed. OmniBook 2000/5700 driver for power management support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\HPUTILS. 1. Create a directory on the C:\ drive named \OMNIBOOK.
5. Enter the directory of the video drivers, then click OK. 6. Click OK to select Chips and Tech. 65554 PCI. 7. Under Monitor Type, click Change. 8. If you have the OmniBook 2000/5700CT, choose Laptop Display Panel (800x600), then click OK. –or–...
To install sound support Requirements OmniBook 2000/5700 with Windows 95 installed. OmniBook 2000/5700 driver for sound support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\WIN95\SOUND. 1. From Control Panel, double-click Systems. 2. Click Device Manager. 3. Remove all devices under Other Devices, then click Close.
Using Windows 95 Installing Windows 95 To install PC card support Requirements OmniBook 2000/5700 with Windows 95 installed. HP OmniBook PC card drivers. Location: OmniBook hard drive or on Recovery CD in \DRIVERS\WIN95\950AONLY. 1. From Control Panel, double-click System. 2. Click Device Manager.
These procedures are necessary only for OmniBooks that have been loaded with a retail version of Windows 95A. Requirements OmniBook 2000/5700 with Windows 95 installed. OmniBook 2000/5700 driver for SCSI support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\WIN95\950AONLY.
Using Windows 95 Installing IDE and SCSI Support To install SCSI drivers for the docking system 1. Copy the file AMSINT.MPD from C:\OMNIBOOK\DRIVERS\WIN95\950AONLY to C:\WINDOWS\SYSTEM\IOSUBSYS. 2. If prompted to overwrite the old file, click Yes to overwrite. 3. Shut down and restart Windows 95. 3-10...
Installing Infrared Support Requirements OmniBook 2000/5700 with Windows 95 installed. HP OmniBook driver for infrared support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\WIN95\IRDA. Before You Start The first step in setting up infrared support for Windows 95 is to remove any previously installed versions of the infrared communications drivers.
17. Close the MS-DOS windows when completed. 18. To enable Infrared, double-click Infrared from the Control Panel. The infrared hardware is disabled when the OmniBook 2000/5700 is docked. You may need to use the Device Manager to uncheck the docked check box under Device Usage for the infrared devices: Infrared/National Semiconductor Infrared Driver Ports/Generic Ir Serial Port (COM2).
For Windows for Workgroups, you may have problems with infrared printing (on LPT3) after installing an HP DeskJet 340 printer. The DeskJet 340 drivers may also affect infrared printing (on LPT3) for other types of infrared printers. If this occurs, do one of the following: Use Control Panel Printers to change the printer's port to COM4 (instead of LPT3) for the DeskJet 340 and other infrared printers.
SETUP.EXE. The OmniBook Application Software Setup menu appears. 2. Click Next at the Welcome screen. 3. Select the HP applications to install, then click Install Now. 4. When prompted, click Restart. To install DMI support 1. From the \OMNIBOOK\DRIVERS\WIN95\DMI directory on the Recovery CD, double-click SETUP.EXE.
3Com 3C562 EtherLink III LAN+33.6 Modem PC card. Intel EtherExpress PRO/100B PCI LAN adapter. To install a Xircom Ethernet IIps PC card Requirements OmniBook 2000/5700 with Windows 95 installed. Xircom Ethernet IIPS PC card. Xircom driver: XPSNDIS (12/4/95) (Xircom Disk 2, Network Drivers Disk, Version 2.3.
6. When prompted to restart the computer, remove the disk, then click Yes. To install a 3Com EtherLink III LAN+33.6 Modem PC card Requirements OmniBook 2000/5700 with Windows 95 installed. 3Com 3C562 EtherLink III LAN + 33.6 Modem PC card. 3Com drivers disk.
Page 61
Windows 95B OEM Service Release 2 1. While Windows 95 is running, insert the PC card. The New Hardware Found window displays 3C562C/3C563C - DEVO. 2. When prompted, insert the 3Com driver disk, then click Next. 3. Click Finish to install the drivers. 4.
To install an Intel EtherExpress PRO/100B PCI LAN adapter Requirements OmniBook 2000/5700 with Windows 95 installed. Intel EtherExpress PRO/100B PCI LAN adapter. Intel driver: e100b.sys (05/08/96). The first step in installing the network is to create a docking hardware profile before installing the network card.
Page 63
The file 82557ndi.dll on Windows 95 CD-ROM could not be found 8. Type A:\ as the path to find the driver, then press Enter. 9. Enter a Workgroup if applicable. 10. Remove the disk from the A drive, then click OK to restart the OmniBook. 11.
Using Windows 95 Working with Windows 95 Working with Windows 95 This section describes how to customize the OmniBook for use with Windows 95 including the following: Using a CD-ROM drive with ATA-type PC cards. Automatically detecting a CD. Running an MS-DOS program outside Windows 95. Using an external display with MS-DOS.
To automatically detect a CD You can set up your system to automatically detect and respond when you insert a CD. However, this setup prevents the OmniBook from automatically turning off after a period of inactivity if the CD-ROM drive is present. 1.
Using Windows 95 Working with Windows 95 To enable Zoomed Video support Zoomed Video is only supported in Windows 95B OEM Service Release 2. The ObZoomV utility is used to enable and disable Zoomed Video Sound. You must have a Zoomed Video PC card installed in the lower PC card slot. If you add a Zoomed Video PC card in the lower PC card slot, its sound capability will not work until you enable Zoomed Video sound.
\OMNIBOOK directory on the Recovery CD to the hard disk drive. Before You Start This installation assumes you are installing Windows NT on a standard HP Windows for Workgroups or Windows 95 build. If you have repartitioned the hard disk drive, please follow the instructions for setting up a hibernation...
Installing Windows NT 3.51 This section describes how to set up the operating system and drivers including the following: Disabling the infrared port. Installing Windows NT 3.51. Installing video support. Installing sound support. To disable infrared Windows NT 3.51 does not support infrared communications. Disable the infrared port on the OmniBook to free COM2 for your modem.
Page 70
Using Windows NT 3.51 Installing Windows NT 3.51 8. Press Enter to choose Express Setup. 9. When prompted, insert Disk 3 in the floppy disk drive, then press Enter. 10. Press Enter to accept the IDE CD-ROM mass storage device. 11.
1. From Control Panel, double-click Display, then click Change Display Type. 2. Under Adapter Type, click Change. 3. Click Other. 4. Enter the correct directory of the Windows NT 3.51 OmniBook 2000/5700 video drivers, then click OK. 5. Select the Chips Video Accelerator(64300,64310,65545,65548,65550), then click Install.
1. From Control Panel, click Drivers, Add. 2. Click Unlisted Or Updated Driver, then click OK. 3. Enter the directory of the Windows NT 3.51 OmniBook 2000/5700 sound drivers, then click OK. 4. Select the CrystalWare Audio Driver, then click OK.
C:\ <current WinNT dir>\system32\driver. 2. Rename the file to PCMCIA.OLD. 3. Copy the HP provided PCMCIA.SYS file from the directory of the PC card driver to C:\<current WinNT dir>\system32\driver. 4. Shut down and restart Windows NT to activate the PC card driver.
3Com 3C562 EtherLink III LAN+33.6 Modem PC card. Intel EtherExpress PRO/100B PCI LAN adapter. To install the Xircom Ethernet IIps PC card Requirements OmniBook 2000/5700 with Windows NT 3.51 installed. Xircom Ethernet IIps PC card. Windows NT 3.51 CD-ROM. Xircom Drivers Disk v2.30.
Page 75
5. Click Yes to begin the Windows NT Network Installation. 6. Enter the directory of the Windows NT 3.51 installation files (D:\i386 if installing from CD-ROM). 7. Select Do Not Detect in the Network Adapter Card Detection window. 8. Click Continue. 9.
To install a 3Com 3C562 EtherLink III LAN+33.6 Modem PC card Requirements OmniBook 2000/5700 with Windows NT 3.51 installed. Windows NT 3.51 CD-ROM. 3Com 3C562 EtherLink III LAN+33.6 Modem PC card. 3Com 3C562 EtherLink III LAN+33.6 Modem PC card drivers disk.
23. When prompted, click Restart Computer. To install an Intel EtherExpress PRO/100B PCI LAN adapter Requirements OmniBook 2000/5700 with Windows NT 3.51 installed. Intel EtherExpress PRO/100B PCI LAN Adapter. Windows NT 3.51 CD-ROM. Intel Drivers Disk. This procedure assumes that Windows NT Networking has not been installed.
Page 78
Using Windows NT 3.51 Installing Cards 1. Insert the PCI Card into the OmniBook Docking System Refer to the OmniBook Docking System User’s Guide for more information. 2. Turn off and dock the OmniBook. 3. If you are accessing the Windows NT installation files from the CD-ROM, make sure the CD-ROM drive is installed and the floppy disk drive is connected to the parallel port.
Working with Windows NT 3.51 This section describes how to customize the OmniBook for use with Windows NT 3.51 including: Power management and Plug and Play with Windows NT 3.51. Desktop mode. Instant On/Off mode. To understand power management limitations Windows NT 3.51 is not Advanced Power Management (APM) aware or Plug and Play compatible.
Using Windows NT 3.51 Working with Windows NT 3.51 To understand usage modes There are two modes of use for the OmniBook: Desktop mode. Instant On/Off mode. Desktop Mode In the Desktop mode, you use your portable like a desktop that you can pick up and take with you.
Page 82
OmniBook 2000/5700 internal CD-ROM drive. Blank floppy disk. 16 MB of RAM (32 MB recommended). Windows NT 4.0 CD-ROM and 3 boot disks. OmniBook 2000/5700 drivers Windows NT 4.0. Location: OmniBook hard drive and on the Recovery CD in \OMNIBOOK\DRIVERS\NT.
To install Windows NT 4.0 This installation assumes an internal CD-ROM and a previously completed standard HP Windows 95 or Windows for Workgroups installation. 1. Press the Off button on the left side of the OmniBook. 2. Insert the CD-ROM drive.
Page 84
Using Windows NT 4.0 Installing Windows NT 4.0 5. Press the blue On/Suspend button. 6. When prompted, insert Disk 2. 7. Insert the Windows NT 4.0 Installation CD. 8. At the Welcome Screen, press Enter to begin. 9. Press Enter to continue, and let Setup auto-detect mass storage devices. 10.
“OmniBook Windows NT 4.0 Emergency Repair Disk” 33. Press Enter to reboot. To install video support Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. OmniBook 2000/5700 driver for video support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\NT\VIDEO.40. 1. From Control Panel, double-click Display, then click Settings.
15. Click OK. To install sound support Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. OmniBook 2000/5700 driver for sound support. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\NT\SOUND. 1. From Control Panel, double-click Multimedia, then click Devices.
C:\ <current WinNT dir>\system32\driver. 5. Rename the file to PCMCIA.OLD. 6. Copy the HP provided PCMCIA.SYS from the directory of the PC card driver to C:\<current WinNT dir>\system32\driver directory. 7. Shut down and restart Windows NT to activate the PC card driver.
Plug and Play for PC cards. The following applications: SystemSoft CardWizard for Windows NT 4.0. SystemSoft PowerProfiler for Windows NT 4.0. Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. Windows NT 4.0 OmniBook Mobile Enhancements. Location: OmniBook hard drive or Recovery CD in \OMNIBOOK\DRIVERS\NT\PNP_APM.40. Important Please read the online documentation for CardWizard and PowerProfiler before installing the software.
SETUP. 2. Click Next. 3. Click Next at the Welcome Screen. 4. Confirm that there are no PC cards installed in the OmniBook 2000/5700, then click Yes. 5. Click Next to accept the default directory. 6. If prompted, click Yes to overwrite the PCMCIA.SYS file.
Using Windows NT 4.0 Installing Windows NT 4.0 To install SystemSoft PowerProfiler PowerProfiler adds the following capabilities to the OmniBook: Improved battery life under Windows NT 4.0. PC card power management. Convenient user control and monitoring of power settings and status. 1.
Page 91
Using Windows NT 4.0 Installing Windows NT 4.0 The PowerProfiler "Display Power Down" feature is not implemented on the OmniBook 2000/5700. The Display Power Down feature should be left disabled in order for the PowerProfiler to work. 5-11...
3Com 3C562 EtherLink III LAN+33.6 Modem PC card. Intel EtherExpress PRO/100B PCI LAN adapter. To install a Xircom Ethernet IIps PC card Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. Xircom Ethernet IIps PC card. Windows NT 4.0 CD-ROM. Configuration I/O Port: 0x300.
17. Click Finish, then click Yes to restart your computer. To install a 3Com EtherLink III LAN+33.6 Modem PC card Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. Windows NT CD-ROM. 3Com EtherLink III LAN+33.6 Modem PC card. 3Com 3C562 driver disk v5.2 or higher.
Page 94
Using Windows NT 4.0 Installing Cards LANOnly Mode: Disabled. Com Port: COM2. This procedure assumes Windows NT networking has not been installed. 1. Insert the PC card and restart Windows NT 4.0. 2. Open My Computer, Control Panel, then Network. 3.
To install an Intel EtherExpress PRO/100B PCI LAN adapter Requirements OmniBook 2000/5700 with Windows NT 4.0 installed. Intel EtherExpress PRO/100B PCI LAN adapter. Windows NT 4.0 CD-ROM. This procedure assumes that Windows NT Networking has not been installed. 1. Insert the PCI card into the OmniBook’s Docking System.
Page 96
Using Windows NT 4.0 Installing Cards 16. Click Next to start the network. 17. Select whether you are connecting to a workgroup or a domain, and enter the appropriate name for your network. 18. Click Finish then Yes to restart your computer. 5-16...
Play (PnP) compatible. If you are not using the Windows NT 4.0 OmniBook Mobile Enhancements, the following will occur: PC cards (PCMCIA) cannot be hot swapped into any laptop with Windows NT. Windows NT 4.0 does not support dynamic allocation of resources. PC cards must be inserted into the unit before booting.
Using Windows NT 4.0 Working with Windows NT 4.0 To adjust the PC speaker The Windows NT 4.0 audio driver mutes the PC speaker by default. This means that system sounds are not audible. The PC speaker can be enabled with the following procedure: 1.
Page 100
You may have to make room on the OS/2 Disk 1. You can safely remove AHA152X.ADD which is the driver for the ADAPTEC 1510,1520 and 1522 SCSI cards. HP OmniBook drivers for video and sound. If you will be using an OmniBook Docking Station, you will also need the drivers for SCSI.
You must install OS/2 drivers from the floppy disk drive. To create OS/2 OmniBook 2000/5700 driver disks do the following: 1. Copy the contents of \OMNIBOOK\DRIVERS\OS2\VIDEO to a blank floppy disk. 2. Type LABEL A: CTDISP 1. Label the Disk OS/2 OmniBook 2000/5700 Video Driver Disk. Using OS/2 Warp 4.0...
13. After the OS/2 Warp base operating system is installed, you will be prompted to remove the disk from drive A, then press Enter. After the OmniBook 2000/5700 restarts, the System Configuration window is displayed. 14. Select Primary Display and then Video Graphics Array (VGA). Click OK. (You...
Page 103
15. Click on Multimedia Device Support and Remove any listed sound device, then click OK. 16. Click Printer. The Select System Default Printer window is displayed. 17. Use the arrow keys to highlight the name of your printer and the port to which your printer is connected, then click OK.
\OMNIBOOK\DRIVERS\NT\VIDEO. 1. Open an OS/2 full screen or windowed session. 2. Place the HP OmniBook OS/2 Drivers disk in drive A. 3. Type A: <ENTER>. 4. Type SETUP A: C: <ENTER> where A: is the floppy disk drive and C: is the hard disk partition containing \OS2.
Page 105
16. Open the OS/2 System folder, then System Setup, then double-click on System. 17. From the list of available screen resolutions, select one of the following resolution. OmniBook 2000/5700CT 800x600 65,536 Colors OmniBook 5700CTX 1024x768 65,535 Colors 18. Close System, Shut Down , then reboot.
Installing OS/2 Warp 4.0 To install sound support Although OS/2 Warp 4 includes sound support for the HP OmniBook, it does not support sound in Windows sessions. Sound in Windows sessions requires the installation of the sound drivers that shipped with the OmniBook.
This section explains how to install PC card support if you did not do so during the OS/2 Warp installation. Requirements OmniBook 2000/5700 with OS/2 Warp 4.0 installed. OS/2 Warp installation CD-ROM. An internal CD-ROM, attached SCSI CD-ROM drive, or networked CD-ROM is necessary if you are using the Installation CD.
SCSI support. This procedure is not necessary if you installed OS/2 Warp from a SCSI CD-ROM drive because the SCSI drivers are already installed. Requirements OmniBook 2000/5700 with OS/2 Warp 4.0 Installed. HP OmniBook drivers for SCSI support. Location: OmniBook hard disk drive or Recovery CD in\OMNIBOOK\DRIVERS\OS2\SCSI.
3Com 3C562 EtherLink III LAN+33.6 Modem PC card. Intel EtherExpress PRO/100B PCI LAN adapter. To install a Xircom Ethernet IIps PC card Requirements OmniBook 2000/5700 with OS/2 Warp 4.0 installed. Xircom Ethernet IIps PC card. Xircom Drivers Disk v2.30. OS/2 Warp 4.0 Installation CD-ROM.
Page 110
Using OS/2 Warp 4.0 Installing Cards 1. Insert the PC card in the top slot. 2. Insert the CD-ROM drive, connect the floppy drive to the parallel port, and restart the OmniBook. 3. Open OS/2 System, then System Setup. 4. Open the Install/Remove folder. 5.
To install a 3Com 3C562 EtherLink III LAN + 33.6 Modem PC card Requirements OmniBook 2000/5700 with OS/2 Warp 4.0 installed. 3Com 3C562 EtherLink III LAN + 33.6 Modem PC card. OS/2 Warp 4.0 CD-ROM. 3Com driver disk. Configuration IO Port Address: 300.
19. Click OK to shut down OS/2. 20. Press Ctrl+Alt+Del to reboot. To install an Intel EtherExpress PRO/100B PCI LAN adapter Requirements OmniBook 2000/5700 with OS/2 Warp 4.0 installed. Intel EtherExpress PRO/100B PCI LAN adapter. OS/2 Warp 4.0 CD-ROM. Intel drivers disk. Live LAN connection.
Page 113
8. Click on Advanced Installation, then click Next. (Advanced installation allows you to select the networking support you wish to install.) 9. Check Desired Network Services, then click Next. (This installation assumes you are installing the File and Print service and the TCP/IP service.) 10.
Using OS/2 Warp 4.0 Working with OS/2 Warp 4.0 Working with OS/2 Warp 4.0 This section describes how to customize the OmniBook for use with OS/2 Warp 4.0 including the following: Networking with OS/2 Warp 4.0. Configuring the OmniBook with OS/2 Warp 4.0. Using the CD-ROM drive with OS/2 Warp 4.0.
when connecting to a network to reactivate your network connection. To totally power off the system when connecting or disconnecting from the network, do the following: 1. Click the right mouse button on the OS/2 Desktop, then choose Shut Down. 2.
Using the OmniBook Docking System The docking system for the HP OmniBook provides simple and convenient connectivity to your desktop peripherals. Plugging your OmniBook into the docking system allows multiple connections: Printer. Modem or other serial device. External SCSI peripherals, such as a CD-ROM drive or disk drive.
Frequently Asked Questions This section answers some frequently asked questions about docking. This section is divided into the following categories: General Questions. Questions for Windows 95. Questions for Windows 3.x. Questions for Windows NT and OS/2 Warp . General Questions What methods of docking does the OmniBook support? Type State of OmniBook...
Page 120
Which ac adapter do I use with the docking system? If you use your OmniBook with a docking system, be sure to use the docking system's ac adapter (HP model F1140A) to power the docking system. The OmniBook's ac adapter isn't designed for this use.
Questions for Windows 95 Why does Windows 95 create a new docked configuration each time I insert my OmniBook into a new docking system? Each OmniBook Docking System has a unique hardware ID. Windows 95 automatically sets up a configuration for each docking system you use. This allows you to access different hardware in each docking system and even to set different video resolutions.
Why do I get a network error when docking for the first time? If you have installed Windows 95A on the OmniBook 2000/5700 it is possible to see a network error if a new docked configuration is created at the same time a new network card is installed.
2. Add DEVICE=DOCKBOOT.EXE /n to the beginning of the CONFIG.SYS (where n = the number of the docked configuration). Whenever you dock the OmniBook and reboot, the docking configuration is chosen automatically. This driver is NOT necessary to dock the OmniBook. It is used only with a multi-boot (booting options) configuration.
Features and Specifications Your OmniBook is designed to provide trouble-free operation. The following suggestions can help you maintain its dependability: Observe the temperature limits and other specifications listed in the next section. Peruse the tips about ergonomics and work habits. If you have problems, see the problem-solving suggestions in chapter 5 of this manual.
Page 128
Mouse port: 6-pin mini-DIN keyboard/mouse. IrDA-2 and Fast IR port (4 Mbps). Stereo-in, stereo-out, microphone-in ports. MIDI/joystick port. OmniBook 2000/5700 Docking System connector. Power AC adapter. Optional enhanced lithium-ion battery inserted in accessory bay adds extra 2.5 to 3.75 hours of battery life (150% capacity of standard lithium- ion battery).
Page 129
12.1-inch diagonal 1024 x 768 x 65,536 colors XGA TFT display. 12.1-inch diagonal 800 x 600 x 65,536 colors SVGA TFT display. OmniBook 2000 12.1-inch diagonal 800 x 600 x 65,536 colors SVGA DSTN display. 12.1-inch diagonal 800 x 600 x 65,536 colors SVGA TFT display.
Page 130
SystemSoft CardWizard and PowerProfiler for Plug and Play for PC cards and Advanced Power Management under Windows NT 4.0. HP Personal Information Manager, including Appointment Book with wake-up alarms, Phone Book, and HP Financial Calculator. Setup, configuration, backup, restore, and self-test utilities.
Optional user-defined password to undock. Power AC adapter port provides power to the docking system. Docking system comes bundled with 60-watt AC adapter that automatically charges the OmniBook 2000/5700’s internal batteries (F1140A). Monitor stand Integrated; supports up 65 lb. or 35 kg.
Ergo Ultra VGA 1280 17-inch monitor (up to 1024 x 768 at 75 Hz) (D2818A). Keyboard and HP keyboard (101-key) (C3756A). mouse HP mouse with mini-DIN interface (C3751A). Cables (F1181A) Keyboard/Mouse Y-adapter (allows user to connect external keyboard and mouse at the same time).
Technical Specifications System Unit Dimensions Weight Traveling Weight (including power adapter and cable) Temperature Operating: Storage: Maximum Humidity Operating: Storage: Shock Vibration Operating Storage: Maximum Altitude Operating Storage: Audio System Record sample rate Playback sample rate Maximum distortion 12.1 inch Color SVGA DSTN Display Dimensions Diagonal Size Pixel Resolution...
Page 134
Features and Support Services Technical Specifications 12.1 inch Color TFT SVGA Display Dimensions Diagonal Size Pixel Resolution Pitch Format Configuration Number of Colors Refresh Rate Character display Total Power Consumption Display Inverter Board Input Voltage Output Voltage Maximum Input Voltage Maximum Output Voltage 12.1 inch Color TFT XGA Display Dimensions...
Page 135
Flexible Disk Drive (F1195B) Dimensions Weight Diskette Size Bytes per sector Sectors per track High density (1.44 or 1.2 MB) Low density (720 K) Tracks per side High density (1.44 or 1.2 MB) Low density (720 K) Read/Write heads Access Times Track-to-track (high/low) Average (high/low) Settling time...
Page 136
Features and Support Services Technical Specifications Data Transfer Rates Sustained Asynchronous Startup Time Seconds Standard Lithium-Ion Battery (F1193B) Weight Energy Voltage Capacity Battery Life Charge Time Temperature Charging Discharging and Storage Enhanced Lithium-Ion Battery (F1194B) Weight Energy Voltage Capacity Battery Life Charge Time Temperature Charging...
Page 137
Storage: Humidity Operating: Storage: Shock Vibration Operating Storage Maximum Altitude Operating Storage Hard Disk Drives Capacity Per Drive HP Part Number Drive Height Transfer Rate Media Inner Outer Interface Seek Times Track-to-Track Average Maximum Average Latency Start Time Features and Support Services...
Page 138
Features and Support Services Technical Specifications Disk Rotational Speed (rev/m) Configuration Cylinders Heads Sectors per track Bytes per sector Disk Platters Buffer Size (read and write segmented) Reliability Mean time between failure power-on hours Unrecoverable errors (bits transferred) 8-14 4,200 4,852 5160 5020...
Getting Assistance and Support This section includes information about: Looking up technical information. Getting HP OmniBook assistance— from electronic services and from Customer Support centers. Getting repair assistance. Hewlett-Packard limited warranty. Features and Support Services Getting Assistance and Support 8-15...
In Box, HP’s website online User’s Guide Online, HP’s website OmniBook Notes Online, HP’s website OmniBook Support and In Box, Online, HP’s website Service Docking Quick Start Sheet Dock Box, HP’s website Docking System User’s Guide Dock Box, HP’s website...
Page 141
Quick Start Sheet Location: In box (printed document) and HP’s website Audience: End user Content: Setting up the OmniBook, using power management options, selecting a factory-installed operating system, getting support (telephone and electronic). Installation and Setup Guide Location: In Box (printed document) and HP’s website...
Page 142
Content: Setting up the Docking System, installing ISA and PCI cards, support information. Docking System User’s Guide Location: Docking System Box (printed document) and HP’s website. Audience: End User, Corporate IT. Content: Setting up the Docking System, using and connecting devices to the Docking System, installing ISA and PCI cards, troubleshooting, support information.
Page 143
Content: OmniBook system resources (including memory maps, interrupt settings, I/O addresses), instructions for using the recovery CD-ROM to rebuild the OmniBook 2000/5700, retrieve key operating-system drivers, and access the electronic manuals, troubleshooting, installing the major operating systems including, Windows 3.1, Windows for Workgroups 3.11, Windows 95, Windows NT, and OS/2 Warp 4.0.
Features and Support Services Getting Assistance and Support To get HP OmniBook assistance If you need assistance with your HP OmniBook or HP OmniBook accessory, use any of the following support services: Provider Type Type of Assistance HP Electronic Support...
To find electronic support services World Wide Web HP OmniBook web site: http://www.hp.com/go/omnibook HP Audio Tips 800-333-1917 (North America) HP Bulletin Board Services (BBS) North America Austria/Germany Belgium/Dutch and French Belgium/French Denmark/Danish Finland/Finnish France/French Germany Italy Netherlands Norway Sweden Switzerland/French...
Page 146
CompuServe ("GO HP") America Online (HP Forum) America Online/Bertlesmann (HP Forum) (Europe) Optional Support Assistant CD-ROM (for information: http://www.hp.com/cposupport/hpsa.html) HP First Post-Sales Fax Retrieval System: Austria / German Belgium / Dutch Belgium / French Denmark / Danish Finland / Finnish...
To contact Customer Support The HP Customer Support Centers will assist you free of charge during the term of the product warranty. (You are responsible for the telephone charges.) During the warranty period, HP can help you with the following:...
Mexico To get repair assistance Under Warranty : Contact one of the support providers or an HP Service Center to receive warranty service. The support provider will help qualify your unit for warranty repair based on the warranty applicable to your unit and original purchase date, and will provide you with repair processes in your area.
Hewlett-Packard Limited Warranty Summary The following table summarizes Hewlett-Packard’s limited warranty. The OmniBook Support and Service booklet contains complete warranty information. Product HP OmniBook Computers (not listed below) HP OmniBook Computers (VL Models) HP OmniBook Computers (AS/AR Models) HP OmniBook Accessories, Batteries...
This serial number offers OmniBooks key competitive advantages. To ensure serial number security To support electronic serial numbers, HP will check for the serial number at configuration of the Motherboard, in manufacturing, and through support services. OmniBook motherboard Configuration...
2. If the user answers no, it will give the user a pass number. The user must call HP customer support and give the pass number. 3. The HP customer support representative will give the user a password that will remove the current serial number.
There is a master password that will unlock each OmniBook. You must call Technical Support and provide acceptable proof-of-ownership of your OmniBook. The fact that the OmniBook is in the hands of an HP representative is not evidence of ownership. In addition, HP will not remove a password from an OmniBook for anyone other than the owner, even if the request involves law enforcement agencies.
Page 153
If the passwords do not match, repeat the previous sequence repeated until the correct master password is entered. The password removal program for the HP OmniBook PCs is protected as HP Company Confidential information. This program may not be copied, backed-up, printed or distributed.
Page 154
Phone: +81-3-3335-8333 Fax: +31-3-3335-8338 Hours of Operation: 9:00 - 12:00, 13:00 - 17:00 Days of Operation: Monday - Friday Australia For Password Removals in Australia, please contact the authorized Hewlett-Packard dealer or reseller where you purchased your HP OmniBook. 8-30...
Page 155
Windows NT 3.51, 4-10 Windows NT 4.0, 5-13 accessories types, 8-8 warranty, 8-25 APM. See power management application notes, 8-18 applications installing HP, 1-14 Appointment Book, 1-14 audio. See sound autodetecting CDs, 3-21 battery status indicators, 1-11 BIOS serial number, 8-27...
Page 156
Windows 3.x support, 2-4 Windows 95 support, 3-11 Windows NT support, 4-3 installation disks Windows 3.x, 2-2 installing HP applications, 1-14 MS-DOS, 2-3 online User's Guide, 1-14 OS/2, 6-2 Windows 3.x, 2-2, 2-4 Windows 95, 3-2 Windows NT 3.51, 4-2 Windows NT 4.0, 5-2...
Page 157
mobile enhancements (Windows NT 4.0), 5-8 models of OmniBooks, 1-5 modem cards 3Com, 2-7, 3-16, 4-10, 5-13, 6-13 COM port, 1-21 MS-DOS external display, 3-21 installing with Windows 3.x, 2-3 outside Windows 95, 3-21 network cards 3Com, 2-7, 3-16, 4-10, 5-13, 6-13 Intel, 2-9, 3-18, 4-11, 5-15, 6-14 Xircom, 2-6, 3-15, 4-8, 5-12, 6-11 networking...
Page 158
no Windows NT 4.0 support, 5-17 states, 1-9 status indicators, 1-11 Windows 95 support, 3-5 Power Profiler, 5-10 printing troubleshooting, 2-13 profile (docking), 3-18 programming service Recovery CD, 1-14 projector synchronizing, 2-14 protection security cable, 1-18 types, 1-16 Recovery CD contents, 1-13 programming service, 1-14 replacing, 1-14...
Page 159
video OS/2 support, 6-6 Windows 3.x support, 2-4 Windows 95 support, 3-6 Windows NT 4.0 support, 5-5 volume Windows NT 4.0, 5-18 warranty, 1-3, 8-6, 8-25 website, 2-4, 8-21 Windows 3.x external display, 2-14 increasing performance, 2-12 installing, 2-2, 2-4 installing drivers, 2-4 making installation disks, 2-2 memory, 2-11...
