Package Contents
1. Blade Set of 3
RPL-F2006-**-BD-**
2. Hanger Assembly
Mounting Bracket
Downrod Assembly
RPL-HGR-ASM-**
(optional for closer to
ceiling mount applications)
3. Canopy w/Canopy Ring
RPL-CAN-OCT-**
4. Coupling Cover
5. Motor Assembly
6. Blade Collector Ring
** denotes finish code of fan
Hardware Bag
RPL-F2006-PARTS
• Part A
• Part B
• Part C
• Part D
• Part E
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
8 Zephyr Instructions
7. Adapter Plate
8. LED Module
F4IN-120V-R1-30
9. Control Receiver
w/Hardware
F-R3-2006-***
10. Glass Shade
RPL-F2006-GLA
11. Luminaire Cover
RPL-F2006-COVER-**
12. Remote Control
F-RCBT-WT
*** denotes blade sweep of fan
Hardware Bag
RPL-ZEPHYR-PARTS
#10 x 38mm Pan Head Phillip Screws (2)
5 x 14 x 1mm Flat Washer (2)
3/16" Star Washer (2)
1/4" x16mm+S Phil/Slotted Screws
Screws (7)
6.6 x 13 x 0.8mm Flat Washers (7)
5 x 13 x 1.5mm Rubber Washers (7)
#8x10mm Phillips Truss Head Screw (7)
6.5x19x2mm Flat Washer (1)
3/16"( 5.2x8.4x1.0mm) Spring Washer (1)
#10x76mm Pan Head Phillip Wood Screws (1)
(8)
(included with receiver)
FR-W2006
