9. Installing the LED Luminaire Module

WARNING:
by turning off the circuit breaker or removing the fuse at fuse box.
NOTE: If you do not plan to install the luminaire module with your
fan at this time, skip to step 5.
1. Remove 3 screws from the outer perimeter of the adapter plate and
keep for future use.
2. Raise and hold the LED luminaire module close to the mounting plate
and proceed to secure the wire connections. Connect the white wire
connectors from the luminaire module to the white wire of the fan.
Connect the blue wire from the fan to the blue wire from the LED
module (Fig. 9A).
3. Tuck connections neatly into mounting plate. Place the luminaire
module against the adapter plate and secure with the 3 screws
previously removed (Fig. 9B).
4. Raise glass shade up against the luminaire module, and secure it
to fan by turning glass shade clockwise until snug. Do not
overtighten (Fig. 9C).
5. If installing the optional metal light cover, make sure it is
securely tightened (Fig. 9).
NOTE: Add metal light cover if you do not need lighting function or
prefer a different aesthetic (Fig. 9C).
NOTE: Do not connect the LED connector wires if you are using the
metal light cover.
24 Zephyr Instructions
Before starting installation, disconnect the power
FR-W2006
