Introduction
The 4-Port USB 3.0 PCIe adds four USB 3.0 ports
to your PCIe-enabled desktop PC, enhancing
existing systems with the latest USB 3.0
technology.
Key Features and Benefits
•
Compliant with Universal Serial Bus 3.0
Specification
•
Compliant with PCI Express Base
Specification, Revision 2.0
•
Supports data rate up to 5Gb/s and
backward compatible with USB 2.0/1.1
devices
Package Contents
•
4-Port USB 3.0 PCIe
•
Driver CD
•
Installation guide
04-0801B
4-Port USB 3.0 PCIe
Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG JU-P40412-S1
Summary of Contents for SIIG JU-P40412-S1
- Page 1 4-Port USB 3.0 PCIe Installation Guide Introduction The 4-Port USB 3.0 PCIe adds four USB 3.0 ports to your PCIe-enabled desktop PC, enhancing existing systems with the latest USB 3.0 technology. Key Features and Benefits • Compliant with Universal Serial Bus 3.0 Specification •...
- Page 2 System Requirements • Desktop PC with an available PCIe slot • Windows 8 (32-/64-bit) / 7 (32-/64-bit) / ® Vista (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / Server 2008 R2 Layout SATA power connector (optional)* USB 3.0 ports Figure 1: Layout *Note: The host adapter will work with or without the power connected.
- Page 3 Hardware Installation Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer’s case for a few seconds.
- Page 4 Connect the system power supply to the cards's SATA power connector. This connection is optional. Please see Layout on page 2 for more information. Replace the computer cover and reconnect the power cord. Driver Installation Note: For Windows 8, the driver is already embedded in the operating system.
- Page 5 For Windows Vista: At the CD Autoplay window, double click Setup. Click Yes or Continue at the User Account Control. For 2008 R2, skip this step. At Welcome to InstallShield wizard..., click Next. Select I accept the terms of the license agreement, click Next.
- Page 6 At Ready to Install the Program, click Install. Click Finish, then restart the computer. To Verify Successful Installation Go to Device Manager to verify installation. For Windows 8 / Windows 7/ Windows XP / Server 2008 R2 / Server 2003: Right click Computer or My Computer, click Manage, then click Device Manager.
- Page 7 Go to www.siig.com, click Support, then Request A Product Replacement to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
- Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 4-Port USB 3.0 PCIe is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
