Specifications

  Input Specs: ...... 100mV/g
  ICP ®
Sensor Excitation: ...... 24Vdc/4mA, ±1Vdc/±1mA
  A/D Converter: ...... 14 bit single slope
  Accuracy: ...... ±2.0% of Scale Factor + 2 counts
  Frequency Response: 3Hz to 10Khz (Standard)
Acceleration: -3dB at 3Hz ±0.5Hz, -3dB at 10kHz ±0.5kHz
Velocity: -3dB at 3.5Hz ±0.5Hz, -3dB at 10kHz ±0.5kHz
Displacement: -3dB at 3.5Hz ±0.5Hz, 1000Hz max.
  Temp. Coeff.: ...... 100 ppm/°C (Typical)
  Warm up time: ...... 2 minutes
  Conversion Rate: ...... 5 conversions per second (Typical)
  Display: ...... 4 digit 0.56" Red LED display, Range –1999 to 9999 counts.
  Polarity: ...... Assumed positive. Displays – negative
  Decimal Selection: ...... Front panel button selectable, X•X•X•X•
  Positive Overrange: ...... Top segments of digital display flash
  Negative Overrange: ...... Bottom segment of digital display flash
  Relay Output: ...... Two 5 A Form A (SPST) relays 230VAC/30VDC standard.
Additionally two 5 Amp Form A (SPST) or 10 Amp Form C (SPDT) relays.
  Optional Analog Output: ...... Isolated 16 bit user scalable 4-20mA retransmit @ 0 to 500 ohms max
loop resistance.
  Power Supply: ...... Auto sensing wide range supply 85-265 VAC / 95-370 VDC @ 2.5W max 3.5W
  Operating Temp.: ...... 0 to 60 °C
  Storage Temp: ...... –20 °C to 70 °C.
  Relative Humidity: ...... <95% (non condensing)
  Case Dimensions: ...... 1/8 DIN, Bezel: 96x48 mm (3.78"x1.89")
Depth behind bezel 117 mm (4.61")
Plus 11.8 mm (0.47") for Right-angled connectors, or plus 20 mm (0.79") for Straight-thru connectors.
  Weight: ...... 6.5 oz., 8.5 oz when packed
