PCB Piezotronics IMI SENSORS 683A1 Installation And Operating Manual page 19

Typical Wiring Diagram (CE Power Supply Option)
ICP SENSOR/
SIMULATOR
-
DMM
RV OUTPUT
-
To Maintain Conformance I/O Shields must be connected to Pin 3 on the Panel Meter
and all Supplied Accessories must be wired as shown (Power Supply Option 2).
1 2 3 4 5
+
SHIELD
+
METALLIC
ENCLOSURE
14 15
8 9 10 11
N/C N/C N/C N/C
-
+
CORCOM
3EB1LB
EMI FILTER
-
+
AC AC GND
NEUTRAL LINE
PAGE 14
