Decimal Point and Brightness Selection
STEP A Enter the Decimal Point and Brightness Mode Through the Sub
Menu [CAL]{oFF]
2) Press the
Display toggles between [cAL] and [oFF].
3) Press the
STEP E Set the Decimal Point
1) Using the
point setting. (Factory Default is X.XXX)
2) Press the
[Br] setting.
STEP F Set the Display Brightness
1) Using the
brightness setting (4 is the brightest setting).
2) Press the
display toggles between [Anhi] and the previous [Anhi] setting.
Digital Span Selection for Analog Range Output
STEP G Setting the Digital Span Point for Analog High Output
Using the
1)
value which sets the point at which the selected analog high output
range will occur. (Factory Default is 1000)
2) Press the
previous [AnLo] setting.
STEP H Setting the Digital Span Point for Analog Low Output
1) Using the
value which sets the point at which the selected analog low output
range will occur. (Factory Default is 0)
2) Press the
returns to the operational display.
Note: Any two digital scale points from –1999 to 9999 can be selected. The digital
scale points for analog high and analog low can be reversed for a 20mA to 4mA
output. The span of the digital scale can be as small as two counts however small
spans cause the 16 bit D to A to increment in stair case steps.
and the buttons at the same time.
button. Display shows the previous [dp] selection.
and buttons, adjust the display to the desired decimal
button. Display toggles between [Br] and the previous
and buttons, adjust the display to the desired
button. Display brightness changes to new setting and
and buttons, adjust the display to the desired digital
button. Display toggles between [AnLo] and the
and buttons, adjust the display to the desired digital
button. The display exits the calibration mode and
