Configuring the 683A1

®
ICP Interface PC Board Diagram
®
The ICP Interface Board Diagram
shows the location of the internal
DIP switch. This DIP switch is
used to configure the indicator for
various sensor and vibration
ranges. The PC Board is
accessible through the back of the
indicator by removing the Screw
Terminal Plugs and back panel.
The back panel is released by
disengaging the tabs on the TOP
and BOTTOM of the meter with a
screwdriver. Once removed, the
®
ICP Interface Board can be slid
out for configuration.
Internal DIP Switch Setting
The Internal DIP Switch of the Model 683A1 must be configured for the Full Scale Output of the ICP
connected to it. This is accomplished by removing the back cover and sliding the ICP
the Panel Meter/Controller. Once removed, the DIP switch should be configured per one of the conditions in the
following table.
Range Setting
5g RMS
5g Peak
10g RMS
10g Peak
20g RMS
20g Peak
0.5 in/sec RMS
0.5 in/sec Peak
1.0 in/sec RMS
1.0 in/sec Peak
2.0 in/sec RMS
2.0 in/sec Peak
25 mils p-p
50 mils p-p
100 mils p-p
1
2
3
4
5
S1 S2 S3
ON OFF OFF
ON OFF OFF
ON OFF OFF
ON OFF OFF
ON OFF OFF
ON OFF OFF
OFF ON OFF
OFF ON OFF
OFF ON OFF
OFF ON OFF
OFF ON OFF
OFF ON OFF
OFF OFF ON
OFF OFF ON
OFF OFF ON
Note: Factory Default Setting is 1.0in/sec Peak
Selector
Switch
OFF ON
S1
S2
S3
S4
S5
S6
S7
S8
S4 S5 S6
ON OFF OFF
OFF ON OFF
ON OFF OFF
OFF ON OFF
ON OFF ON
OFF ON ON
ON OFF OFF
OFF ON OFF
ON OFF OFF
OFF ON OFF
ON OFF ON
OFF ON ON
OFF OFF OFF
OFF OFF OFF
OFF OFF ON
®
Sensor
®
Interface PC Board out of
S7 S8
OFF ON
OFF ON
ON OFF
ON OFF
OFF OFF
OFF OFF
OFF ON
OFF ON
ON OFF
ON OFF
OFF OFF
OFF OFF
OFF ON
ON OFF
OFF OFF
PAGE 17
