SuperServer SYS-2029U-T Series User's Manual

1.1 Overview

This chapter provides a brief outline of the functions and features of the SYS-2029U-T Series
server. It is based on the X11DPU motherboard and the SC219U2AC4-R1K02-T chassis.
System
2029U-TR25M
2029U-TR4
2029U-TR4T
2029U-TRT
2029U-TRTP
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Description
Power supply modules
Backplane
Fans
Air Shrouds
Heatsinks
Riser cards
Rack mount rails
PWS air shroud

1.2 Unpacking the System

Inspect the box the system was shipped in and note if it was damaged in any way. If any
equipment appears damaged, please file a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic fields are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix B.
Chapter 1
Introduction
SYS-2029U-T Series Models
LAN Ports Ultra Riser Card
Two 25 GbE AOC-2UR68-M2TS
Four GbE AOC-2UR68-I4G
Four 10GBase-T AOC-2UR66-I4XTF
Two 10GBase-T AOC-2UR68-I2XT
Two 10G SFP+ AOC-2UR68-I2XS
Main Parts List
8
Part Number Quantity
PWS-1K02A-1R 2
BPN-SAS3-216A-N4 1
FAN-0118L4 4
MCP-310-82921-0N,
1 each
MCP-310-82922-0N
SNK-P0068PS 2
RSC-R1UW-E8R
1 each
RSC-R2UW-4E8
MCP-290-00057-0N 1 set
MCP-310-81905-0B 1
