Chassis Front - Supermicro SuperServer SYS-2029U-T Series User Manual

Status
Solid blue
Blinking blue

Chassis Front

The illustration below shows the features included on the front of the chassis. Externally
accessible hard drive carriers display status lights.
1 3
Item Features
1 Control Panel
2 Storage Drives
Service/Asset
3
Tag
Figure 1-3. Location of the BMC Password Label
Information LED
Description
UID has been activated locally to locate the
server in a rack environment.
UID has been activated using IPMI to locate the
server in a rack environment.
2
Figure 1-2. Front View
Chassis Front Features
Description
Power buttons and status indicators
Twenty-four 2.5" drive bays; see the "Storage Drive" section in Section 3.4 for
details
Pull-out identifier (with BMC ADMIN default password sticker)
11
Chapter 1: Introduction
BMC Password Sticker
