User name and password
LAN IP address and subnet mask of the IPC-M
LAN IP address and subnet mask of the PC used
for management
Procedure:
Step 1: Use a network cable to connect the MGMT Ethernet port of the IPC-M unit to a PC.
Step 2: Ensure that your web browser does not use a proxy server.
Step 3: Set the IP address and subnet mask of the PC. For details, see Table Table Table
Table
Step 4: Login to the web interface:
1. Enter http://192.168.1.2 in the address bar of the web browser (192.168.1.2 is the
default IP address of the MGMT Ethernet interface of the IPC-M unit) and press
Enter to display the login interface, as shown in Picture
Master Unit EKOAX IPC-M
Item
IPCOAX IPC-M User Manual
Default settings: Administrator:
- User name: admin
- Password: admin
Default settings:
IP address: 192.168.1.2 (Out-band Network – this
is the network available using the MGMT
Ethernet port of the unit)
IP address: 192.168.2,2 (In-band Network- this is
the network
10/100/1000Mbps Ethernet port of the unit
Subnet mask: 255.255.255.0
Configure the IP address of the PC to be in the
same subnet as the LAN IP address of the IPC-M
unit. For example:
IP address: 192.168.1.100 (from Out-band)
IP address: 192.168.2.100 (from In-band)
Subnet mask: 255.255.255.0
2
Table
Confiential
Description
available using
