Pane: Auto Upgrading Enable
PIB
NVM
Commit
Take effects to all authorized slaves
Auto Upgrading File Management
PIB
NVM
Download
Upload
Delete
Refresh
Pane 3: Auto Upgrading Status
ID
MAC
Status
PIB & NVM version
Auto Update Enable
42 of 61
IPCOAX IPC-M User Manual
Item
Confidential
Description
Parameter Information Block. Check this box if
you want to upgrade this in the slave during the
auto-upgrading process.
Non-volatile Memory. Check this box if you want
to upgrade this in the slave during the auto-
upgrading process.
Click this button to save the auto-upgrading
options in all the online slaves.
Click this button to auto-upgrade all the online
authorized slaves.
The file to upgrade the Parameter Information
Block.
The file to upgrade the Non-volatile Memory.
Click this button to download the related file.
Click this button to upload the related file.
Click this button to delete the related file.
Click this button to update all the information
shown in this pane.
Slave identifier.
MAC address of the related slave unit
Slave status.
PIB and NVM file version currently installed on
the related slave.
it shows if the related slave unit has its Auto
Update option enabled.
