ITS Telecom Master Unit EKOAX IPC-M User Manual page 21

www.Ekselans.com
Item
Allowed VLAN
COS
UpLink Max Speed
DownLink Max Speed
Pane 4: Current Configuration
Port
Link status
Loop
Enable Port
Adaptive
Master Unit EKOAX IPC-M
IPCOAX IPC-M User Manual
This is the column in the internal ports table where you can
configure the allowed VLANs for a trunk port.
This is the column in the internal ports table where you can
configure the Class Of Service (COS) of the port traffic.
Possible value available in the related combo box are:
• 0 — Traffic type is background.
• 1 — Traffic type is best effort.
• 2 — Traffic type is excellent effort.
• 3 — Traffic type is critical applications.
• 4 — Traffic type is video <100ms jitter and latency.
Latency is the short period of delay between the
entrance of an audio signal and when it emerges
from a system. Jitter is the deviation from a true
period of
telecommunications.
• 5 — Traffic type is voice < 10ms jitter and latency.
• 6 — Traffic type is internetwork control.
• 7 — Traffic type is network control. This has the
highest level of priority.
This is the column in the internal ports table where you can
configure the maximum speed allowed for the slave uplink.
The value set must be between 0 and 102400 Kbps. 0 value
means not set.
This is the column in the internal ports table where you can
configure the maximum speed allowed for the slave
downlink. The value set must be between 0 and 102400
Kbps. 0 value means not set.
The column where you can see the port number of the
available internal ports. The slave internal ports are
mapped with the slave external ports depending on the
slave type, see Port Number item in Table for more details.
The column where the link status of each internal port is
shown: connected or disconnected
The column to see the result of the loop detection check
for each internal port.
The column to check which internal ports are enabled and
which one are disabled.
This column shows Enable value for all the internal ports
which have the Speed&Duplex mode set to auto. For the
Confiential
Description
an assumed period
V001
signal in
21 of 61
