ID
Slave Class
Slave Type
Template Correlation
User HFID
OUI
Port Number
Port
Mapping Port
Operating
The New Type button allows to create new slave types. The Picture shows the page
displayed to create a new slave type.
54 of 61
IPCOAX IPC-M User Manual
Item
Table
Confidential
Description
It is a number to identify uniquely the slave type.
It is the class of the slave type. The following
classes are available:
• SW: only Ethernet interface.
• WIFI: only WiFi interface.
• SW + WIFI: Ethernet and WiFi interfaces
available.
It is the name to identify the slave type.
It is the default template identifier associated to
the related slave type.
User High Friendly ID
Organizationally unique identifier
The number of internal ports available
The port number.
The actual port id assigned.
The operations you can do with the related
slave type:
• Modify: to change the parameters of the
slave type.
• Delete: to remove the slave type.
14
