Owner's Manual
Original Instructions
Wired Controller XE70-13/E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XE70-13/E and is the answer not in the manual?

Questions and answers

Related Manuals for Gree XE70-13/E

Summary of Contents for Gree XE70-13/E

  • Page 1 Owner's Manual Original Instructions Wired Controller XE70-13/E...
  • Page 3 To Users Thank you for selecting Gree’s product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve...
  • Page 4 (5) The final right to interpret for this instruction manual belongs to Gree Electric Appliances Inc. of Zhuhai.

  • Page 5: Table Of Contents

    Contents 1 Safety Notices (Please be sure to abide ) ......1 2 Installation ................2 2.1 Dimension and Component of Wired Controller ....2 2.2 Installing Position and Requirements of Wired Controller . 4 2.3 Installation of Wired Controller ..........5 2.4 Disassembly of Wired Controller ...........
  • Page 6 6 Operation Instructions ............18 6.1 On/Off ..................18 6.2 Mode Setting ................20 6.3 Temperature Setting .............. 20 6.4 Fan Setting ................21 6.5 Zone Control ................22 6.6 Zone Setting ................24 6.7 Function Setting ..............29 6.8 View ..................31 6.9 System ..................

  • Page 7: Safety Notices (Please Be Sure To Abide )

    Wired Controller XE70-13/E 1 Safety Notices (Please be sure to abide ) WARNING: If not abide strictly, it may cause severe damage to the unit or the people. NOTE: If not abide strictly, it may cause slight or medium damage to the unit or the people.

  • Page 8: Installation

    Wired Controller XE70-13/E 2 Installation 2.1 Dimension and Component of Wired Controller Figure 2-1 Dimension of Wired Controller (Unit：mm)
  • Page 9 Wired Controller XE70-13/E Figure 2-2 Components of Wired Controller Table 2.1.1 Introduction of Components ① ② ③ ④ installing box wired junction box for Name screw M4×25 of wired controller installing inside the wall controller Quantity 1(prepared by user)

  • Page 10: Installing Position And Requirements Of Wired Controller

    Wired Controller XE70-13/E 2.2 Installing Position and Requirements of Wired Controller （1） Please do not install the wired controller in the position where is wet or is likely to be splashed with water; （2） Please do not install the wired controller near high-temperature objects or under direct sunlight;...

  • Page 11: Installation Of Wired Controller

    Wired Controller XE70-13/E temperature range is 0° C~50° C. 2.3 Installation of Wired Controller For installation steps of wired controller please refer to the following sketch map, brief instructions are as below: （1） Before installation, please cut off the power supply of indoor unit, live working during installation is not allowed;...
  • Page 12 Wired Controller XE70-13/E...

  • Page 13: Disassembly Of Wired Controller

    Wired Controller XE70-13/E Figure 2-3 Sketch Map for Installation of Wired Controller 2.4 Disassembly of Wired Controller Disassembly for wired controller is as below: Figure 2-4 Sketch Map for Disassembly of Wired Controller 3 Display 3.1 Appearance of Wired Controller...

  • Page 14: Home Page Display And Buttons

    Wired Controller XE70-13/E Fig 3-1 Appearance of Wired Controller 3.2 Home Page Display and Buttons...
  • Page 15 Wired Controller XE70-13/E Fig 3-2 LCD Display of Wired Controller Table 3.2.1 Home Page Display and Buttons Name Instructions (1)It shows the name of the current zone. The set Name of the temperature displayed on the home page is the current zone temperature of the current zone.

  • Page 16: Other Icons And Buttons

    Wired Controller XE70-13/E (2)Press this button for 5s to reset the screen. (1) It shows the current time. Time (2) Press to enter the page of time menu to view or set the date and time. Tap to increase the set temperature of the current zone.

  • Page 17: Functions Description

    Wired Controller XE70-13/E It is shown on the home page, indicating the WiFi WiFi status. （1）Tap to turn on or off the timer function. On/Off （2）Tap to turn on or off the fan valve of a zone. Tap to enable or disable each timer setting.

  • Page 18: Functions Introduction

    Wired Controller XE70-13/E Fig 4-1 Menu Structure 4.2 Functions Introduction...
  • Page 19 Wired Controller XE70-13/E Table 4.2.1 Functions Introduction Function Introduction 8 timings can be set independently for each zone. The timer includes set temperature and zone on/off. It will work every day Daily timer after setting. Week timer can be set independently for each zone and 8 timings can be set for each day.
  • Page 20 Wired Controller XE70-13/E Function Introduction When the unit is on, the fan valve of this zone will be open at all Setting of always times and cannot be controlled. Temperature setting for this open zone zone is invalid. This zone must be set.
  • Page 21 Wired Controller XE70-13/E Function Introduction By setting the lower limit of set temperature for cool and dry modes and the upper limit of set temperature for heat mode, the Save function air conditioner will run in a smaller temperature range, so as to save energy.
  • Page 22 Wired Controller XE70-13/E Function Introduction The unit resumes the original on/off state when power is Memory function restored after power failure. The temperature can be set in Fahrenheit or Celsius. Temperature unit Reset the WiFi module for network connection. (Effective only Reset WiFi after cloud control is equipped.)

  • Page 23: Installation And Debugging

    Wired Controller XE70-13/E Function Introduction Indoor ambient temperature of each zone (only the zone Ambient temperature of zone equipped with RF remote controller) can be viewed. NOTE! Because this zone control system will be matched with different units, some functions are not displayed if they are not available on the units.

  • Page 24: Operation Instructions

    Wired Controller XE70-13/E Press the icon to enter the page of details, where you can see what contents need to be set. Then press “Confirm” button according to the prompt to enter the page of the relevant setting. The above contents can also be set in the menu of zone setting. For specific methods, please refer to the related operating instructions in the following chapters.
  • Page 25 Wired Controller XE70-13/E Fig 6-1 Page of On Fig 6-2 Page of Off...

  • Page 26: Mode Setting

    Wired Controller XE70-13/E 6.2 Mode Setting When the unit is turned on, press “Mode” button on the home page each time, and the mode will be switched in the following order. Cool Heat Auto Fig 6-3 Mode Setting NOTES! ① When energy-saving function is enabled, Auto mode is not available.

  • Page 27: Fan Setting

    Wired Controller XE70-13/E Under Auto mode, there are two control patterns. In one pattern, temperature can be set, and the setting range is 16° C ~30° C (61° F ~86° F). In the other pattern, temperature cannot be set. As to which pattern the unit will have, it depends on the model of the unit.

  • Page 28: Zone Control

    Wired Controller XE70-13/E adjusted. ②Under Fan and Auto modes, turbo fan speed cannot be set. ③If holiday and I-Demand functions are enabled, the unit runs in auto fan speed and the fan speed cannot be adjusted. 6.5 Zone Control There are two ways to enter the page of zone control.
  • Page 29 Wired Controller XE70-13/E Fig 6-5 Zone Control After entering the page of zone control, set according to the following instruction. （1）Press the name of each zone to enter the page of name setting. Press the “ ” and “ ” buttons to set the name and number of a specific zone.

  • Page 30: Zone Setting

    Wired Controller XE70-13/E 6.6 Zone Setting 6.6.1Setting of daily timer （1）Press “Menu” button on the home page to enter the page of main menu. Then press “Zone” to enter the page of zone setting. （2）Press “Daily timer” to enter the page for zone selection. You may select one or several zones.
  • Page 31 Wired Controller XE70-13/E （2）Press “Week timer” to enter the page for zone selection. You may select one or several zones. Then press “Set” to enter the page of 7 days selection. You may also press the “on/off” button to turn on or off the timer function.
  • Page 32 Wired Controller XE70-13/E （3）After entering the page for zone selection, select one or several zones. Then press “Set” to enter the page of week selection. You may also press “on/off” button to turn on or off the timer function. （4）After entering the page of week selection, you may select the week that needs to be set and then enter the page of 7 days selection automatically.
  • Page 33 Wired Controller XE70-13/E page. NOTE! Only the zone that is in use and equipped with a temperature controller can be chosen as the main zone. 6.6.5 Setting of always open zone （1）Press “Menu” button on the home page to enter the page of main menu.
  • Page 34 Wired Controller XE70-13/E zone is equipped with a temperature controller. NOTE! Do not change the setting of zone parameters arbitrarily; otherwise, the system will not be able to work normally. 6.6.7 Enable pairing of zone controller and temperature controller （1）Press “Menu” button on the home page to enter the page of main menu.

  • Page 35: Function Setting

    Wired Controller XE70-13/E 6.7 Function Setting Following is the instruction on function setting. （1）Press “Menu” button on the home page to enter the page of main menu. Then press “Function” to enter the page of function setting. （2）Press the function option you want to set and you will enter the page of the corresponding function setting.
  • Page 36 Wired Controller XE70-13/E Table 6.7.2 Fresh Air Modes Fresh air Description mode The unit is turned on continuously for 60 minutes and the fresh air valve is open for 6 minutes. The unit is turned on continuously for 60 minutes and the fresh air valve is open for 12 minutes.

  • Page 37: View

    Wired Controller XE70-13/E cleaning icon will not be displayed. If the adjusted timer is less than the current cumulative time, the cleaning icon continues to display. If the cleaning function is turned off, then the accumulated time for filter cleaning indication will be cleared and the cleaning icon will not be displayed.

  • Page 38: System

    Wired Controller XE70-13/E Then press “View” to enter the page of View. （2）Press “Ambient temperature of zone” and you can view the ambient temperature of the effective zone. 6.9 System 6.9.1 Date and time （1）Press “Menu” button on the home page to enter the page of main menu.

  • Page 39: View Malfunction

    Wired Controller XE70-13/E Then press “System” to enter the page of System. （2）Select “Lightness” to enter the page of lightness setting. （3）Press the “ ” or “ ” button to adjust the lightness. Then press “Confirm” to save the setting and return.
