B-Tech BT8330 Installation Manual

B-Tech BT8330 Installation Manual

Universal menu board mounting system

Advertisement

Quick Links

BT8330
UNIVERSAL
MENU BOARD MOUNTING SYSTEM
INSTALLATION GUIDE
SPECIFICATIONS
• Recommended screen size: 32"- 70"
• Max weight per screen: 50kg (110lbs)
• Suitable for landscape or portrait mounting
• Sections can be joined together to increase menu board width
• Safety screws help prevent unauthorised removal of screens
• All mounting hardware included
Note: This assembly manual covers di erent installations. Some
parts or procedures shown may not be required for installation.
Please refer to page 5
for VESA® xings
www.btechavmounts.com
TM
PER SCREEN

Advertisement

loading

Summary of Contents for B-Tech BT8330

  • Page 1 BT8330 UNIVERSAL MENU BOARD MOUNTING SYSTEM INSTALLATION GUIDE SPECIFICATIONS • Recommended screen size: 32”- 70" • Max weight per screen: 50kg (110lbs) • Suitable for landscape or portrait mounting • Sections can be joined together to increase menu board width •...
  • Page 2 It is recommended that periodic inspections of the product and its xing points are made as frequently as possible (no more than 6 months apart) to ensure that safety is maintained. B-Tech AV Mounts recommends that a suitably quali ed person is used for the removal of this product.
  • Page 4 BT8330 PARTS LIST Due to the multiple installations available the quantity for each option below is dependent on the mount ordered. All these components can be moved or carried by manpower. Please be careful to avoid injury when PLEASE KEEP THIS FOR FUTURE REFERENCE handling these components before &...
  • Page 5 OPTIONAL MOUNTING RAIL EXTENSION KIT BT8390-EXT PART NAME ITEM PER PACK JOINING BAR M6 x 8mm GRUB SCREW 3AF HEX KEY Screen Interface Arms INTERFACE KIT BT8390-VESA200F BT8390-VESA200T BT8390-VESA400MAF VESA 200mm VESA 200mm VESA 400mm ITEM PART NAME PER PACK SCREEN INTERFACE ARM - LEFT BT8390-VESA400T BT8390-VESA400F...
  • Page 6: Typical Installations

    TYPICAL INSTALLATIONS 2x1 Menu Board Installation with VESA 400 Fixed Arms INSTALLATION TOOLS REQUIRED Drill Pencil 10mm (7/16”) masonry bit or 4mm (5/32”) wood bit 2 Screen Installation with VESA 400 Tilt Arms Crosshead Stud Finder screwdriver (Optional) Level (Optional) BT8390-VESA400T BT8390-WFK2 5 Screen Installation with VESA 200 Fixed Arms...
  • Page 7 OPTIONAL EXTENDING THE mounting rail COMBINING MOUNTING RAILS i. On one side of item B1, insert 4x item C1 half-way into each channel. ii a. Using BT8390-WFK1. On the back side of item B1, insert 1x item C1 in the second channel and 1 x item C1 in the third channel - See Fig.
  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS INSERT M8 SLIDING NUTS INTO MOUNTING RAIL a i. BT8390-WFK1 assembly - For each item A1 used, insert 2x item A4 into item B1. 1 in the top channel and 1 in the bottom channel. b i. BT8390-WFK2 assembly - For each item A1 used, insert 4x item A4 into the item B1. 2 in the second from top channel and 2 in the bottom channel.
  • Page 9 BT8390-WFK1 ATTACH WALL FIXING KIT TO MOUNTING RAIL a ii. Attach item A1 to item B1 by fastening item A5 into item A4. BT8390-WFK1 Required quantity of Rail Fixing Brackets (item A1) 2pcs for 0 - 2000mm (0 - 79") 3pcs for 2100mm - 3500mm (80"...
  • Page 10 BT8390-WFK2 ATTACH WALL FIXING KIT TO MOUNTING RAIL b i. Insert 2x item A4 into the second channel from the top of item B1 and 2x item A4 into the bottom channel. ii. Attach item A1 to item B1 by fastening item A5 to the inserted item A4.
  • Page 11 FIX MOUNTING RAIL TO THE WALL a. BT8390-WFK1 - KEYHOLE MOUNTING b. BT8390-WFK2 - WALL MOUNTING i. Mark and drill two xing holes for each wall plate assembled. ii. Insert item A2 into the top hole, do not fully tighten - allow a gap (approx.10mm) to hook on item A1.
  • Page 12 ATTACH INTERFACE ARMS TO SCREEN Fix items D1 & D2 to the rear of the screen using items A-M. Note: Ensure the arms are A. FIXED ARMS facing the correct way round and the same holes are used on both arms. SCREEN FIXING KIT SCREEN...
  • Page 13 C. MICRO-ADJUSTMENT ARMS Fix items D1 & D2 to the rear of the screen using items D-N. Note: Ensure the arms are facing the correct way SCREEN FIXING KIT round and the same holes are used on both arms. Use spacers for screens with recessed xings SCREEN SCREEN OPTIONAL ADAPTOR ARMS...
  • Page 14 HOOK SCREEN ONTO RAIL i. Hook the rst screen centrally onto item B1. ii. Once rst screen is in position, mount the C. BT8390-VESA400MAF remaining screens onto the rail. WALL WALL Lateral Adjustment SECURE SCREENS (FIXED AND TILT ARMS*) HEIGHT ADJUSTMENT WALL i.
  • Page 15 OPERATING INSTRUCTIONS SCREEN ALIGNMENT USING MICRO-ADJUSTMENT Z AXIS KNOB (Only available with BT8390-VESA400MAF) Y AXIS i. Use the Y & Z micro-adjustment knobs on KNOB items D1 & D2 to align screens. Y AXIS KNOB Use Lateral Adjustment Use Depth Adjustment* Use Height Adjustment* (X axis) to align sides of screens (Y axis knobs) to align front of screens...
  • Page 16 Fixed VESA 400mm Interface Arms VESA 400mm Interface Arms with Tilt 20° 45.2mm 75mm 15° 10° 28mm 40mm THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
  • Page 17 2 x Ø 8.4mm 24mm 24mm 4 x Ø 9.3mm FRONT VIEW REAR VIEW SIDE VIEW FRONT VIEW SIDE VIEW THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
  • Page 18: Mounting Rails

    500mm 705mm 505mm BT8390-150 1500mm 1505mm BT8390-175 1750mm 1755mm BT8390-200 2000mm 2005mm 30mm 30mm 8.2mm 30mm 30mm THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
  • Page 19 Distance from wall 86.1mm Distance from wall 99.1mm (Tolerance 1mm) (Tolerance 1mm) +/-10mm Depth Adjustment +/-10mm Depth Adjustment THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
  • Page 20 ©2021 B-Tech International Design and Manufacturing Ltd. All rights reserved. B-Tech AV Mounts is a division of B-Tech International Design and Manufacturing Ltd. B-Tech AV Mounts and the B-Tech logo are registered trade marks. All other brands and product names are trademarks of their respective owners.
