BT8370-2X2
UNIVERSAL VIDEO WALL STAND
FOR 2x2 VIDEO WALLS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Stand
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes....................................................................................................... . ..............2
Parts List.............................................................................................................................................4
Installation Notes................................................................................................................................6
Installation Instructions....................................................................................................... . ................7
Optional Accessories......................................................................................................... . ...............18
Product Dimensions............................................................................................................ . .............19
B-Tech Contact Details........................................................................................................... . ..........20
INSTALLATION TOOLS REQUIRED
B-TECH AUDIO VIDEO MOUNTS
CONTENTS
Crosshead
screwdriver
www.btechavmounts.com
FEATURES
• Designed to mount 4 screens in a 2x2
video wall formation
• Universal stand suitable for video wall screens
from 46" - 60" (117cm - 152cm)
• Max weight per screen: 50kg
• Designed for screens with VESA & non-VESA
mounting patterns: 200 x 200 up to 600 x 400mm
• Suitable for landscape or portrait screen mounting
• Tool-less micro-adjustments at 8 points for seamless
screen alignment
• Stand Dimensions:
W. 2005mm D. 950mm H.1898mm up to 2094mm
• Collar compatible accessories such as shelves
can be fitted directly to the extrusion
• Integrated cable management
• All mounting hardware included
Level
50kg
PER SCREEN
Knife
TM
