- Page 1 ASSEMBLY INSTRUCTIONS Description : 32 X 12 X 84 HIGH BOOK CASE RTA Item No. : SH-3228A ITEM NO. : SH-3228A Printed in Vietnam REVISED MAY 17, 2016 - 1 -...
- Page 2 Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO. : SH-3228A Printed in Vietnam REVISED MAY 17, 2016 - 2 -...
- Page 3 Description Sketch Description Sketch Side panel (L-R) Bottom panel Shelf panel Adjustable Back shelf upper Back center Back lower Connecter ITEM NO. : SH-3228A Printed in Vietnam REVISED MAY 17, 2016 - 3 -...
- Page 4 Attach side panels (B) to the top (A), and shelf panels (D) and bottom panel (C) with bolts (1), and washers (3) and (2) as shown below. Tighten with Allen key (4). ITEM NO. : SH-3228A Printed in Vietnam REVISED MAY 17, 2016...
- Page 5 Remove the paper strip and attach sticky side of connecters (I) to back of the unit. Then attach connecter (I) to the top (A), and bottom panel (C) and shelf panels (D) with pan head screws (9). Tighten with a screwdriver. ITEM NO. : SH-3228A Printed in Vietnam REVISED MAY 17, 2016...
- Page 6 Attach steel band (8) to the unit with screws (6) and attach steel band (8) to a wall with screws (7) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO. : SH-3228A Printed in Vietnam...
