ASSEMBLY INSTRUCTIONS
WARNING!
Serious or fatal injuries can occur from furniture tip over. Use tip over restraint
(steel band included) to secure this product to the wall.
Description
Item No.
ITEM NO.: BD-2038
REVISED OCT 09, 2018
: 8 DRAWER 1 DOOR COTTAGE DRESSER
: BD-2038
- 1 -
Printed in Vietnam
Advertisement
Table of Contents
Related Manuals for Unfinished Furniture of Wilmington BD-2038
Summary of Contents for Unfinished Furniture of Wilmington BD-2038
- Page 1 Serious or fatal injuries can occur from furniture tip over. Use tip over restraint (steel band included) to secure this product to the wall. Description : 8 DRAWER 1 DOOR COTTAGE DRESSER Item No. : BD-2038 ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 1 -...
- Page 2 Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 2 -...
- Page 3 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch 8 DRAWER 1 DOOR DRESSER CENTER LEG SHELF ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 3 -...
- Page 4 Steel band *Wooden knob: (M4x25mm) Allen key Pan head screw *Metal knob: (M4x22mm) (M4 x 30mm x 110mm) Long screw (M4 x 35mm) NOTE: WARNING LABEL (INCLUDED) ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 4 -...
- Page 5 STEP 1 Use the Allen key (7) to loosen the bolts and washers, and then remove three pieces of wood from bottom of the dresser (A), as shown below. ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 5 -...
- Page 6 Lift the dresser (A) to attach legs (B) and (C) by screwing them into dresser (A), as shown below. STEP 3 Attach brackets (5) to the unit as shown below. Place shelf (D) on the brackets and attach with screws (4). Tighten with a screwdriver. ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018 - 6 -...
- Page 7 Drill 1/8-inch (3mm) diameter hole(s) into the wood stud(s) located in the wall, where you marked with the pencil. Properly attach steel bands to the wall with screws (3) and tighten screw(s) firmly into the wall. ITEM NO.: BD-2038 Printed in Vietnam REVISED OCT 09, 2018...
