- Page 1 ASSEMBLY INSTRUCTIONS Description : CANYON SERVER Item No. : SV - 37 ITEM NO. : SV-37 Printed in Vietnam REVISED JUL 20, 2016 THIS ITEM IS PACKED IN TWO CARTONS - 1 -...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. - Page 3 PART LIST SV – 37A When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts. Description Sketch PART LIST SV – 37B When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts.
-
Page 4: Hardware List
HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Bolt Lock washer (M6 x 35mm) (6.5 x11mm) Flat washer Long screw (6.5 x19mm) (M4 x 30mm) - Page 5 STEP 1 Attach side panels (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (9). STEP 2 Attach bottom panel (C) to side panels (B) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (9).
- Page 6 STEP 3 WINE RACK ASSEMBLY. Attach side panels (D) to the bottom panel (F) and top panel (E) with screws (4) as shown below. Tighten with a screwdriver. ITEM NO. : SV-37 Printed in Vietnam REVISED JUL 20, 2016 THIS ITEM IS PACKED IN TWO CARTONS - 6 -...
- Page 7 STEP 4 WINE RACK ASSEMBLY GROUP 1 : Insert center panels (G) into the center panel (H). GROUP 2 : Attach panels (K) to the panels (G) with screws (4) as shown below. Tighten with a screwdriver. GROUP 3 : Attach panels (L) to the group 2 with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.
- Page 8 STEP 5 WINE RACK ASSEMBLY. Insert group 3 into the unit (from step 3) as shown below. STEP 6 Attach knobs (8) to front of drawers with pan head screws (7). Tighten with a screwdriver. Insert the wine rack into the unit as shown below. Attach steel bands (6) to the unit with screws (5) and attach the steel bands to the wall with screws (4) as shown below (to secure the product and prevent tipping).
