- Page 1 ASSEMBLY INSTRUCTIONS Description : 36 IN MISSION TV STAND RTA Item No. : TV-36 ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 2 -... -
Page 3: Part List
Bottom Side frame shelf (L-R) Drawer Bottom bottom support rail panel Drawer Back panel front (L-R) Drawer side Drawer panel back panel (L-R) Drawer - support bar ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 3 -... -
Page 4: Hardware List
Cambolt Pan head screw Wooden knob *Metal knob: (M4x22mm) *Wooden knob: (M4x25mm) Steel band Warning label METAL KNOB (30x30mm) Allen key GOES WITH (M4x80mm) FINISHED ITEM ONLY. ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 4 -... - Page 5 Attach the Cambolt (7) to the side frames (D) as shown below. Tighten with a screwdriver. STEP 2 Attach the support rail (F) to the side frames (D) with the camlock (8). Tighten with Allen key (13). ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016...
- Page 6 Attach the bottom self (C) to the side frames (D) with bolts (1), and washers (2) and (3). Tighten with Allen key (13). Attach the support rail (F) to the side frames (D) with the camlock (8). Tighten with Allen key (13). ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016...
- Page 7 Insert shelf support pins (6) into the side frames (D). Place the shelf (B) on the shelf support pin and attach with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016...
- Page 8 Attach drawer sides (J) to the drawer front (H) with screws (4) as shown below. Tighten with a screwdriver. STEP 8 Slide the drawer bottom panel (E) into the grooves as shown below. ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 8 -...
- Page 9 Attach the drawer back panel (I) to the drawer (from step 8) with screws (4) as shown below. Tighten with a screwdriver. STEP 10 Attach the drawer support bar (K) underneath the drawer with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: TV-36 Printed in Vietnam REVISED JAN 13, 2016 - 9 -...
- Page 10 Attach steel bands (11) to the unit with screws (5). Then attach the steel band to a wall with screw (4) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO.: TV-36 Printed in Vietnam...
