- Page 1 ASSEMBLY INSTRUCTIONS Description : 44X44X64 BUTTERFLY SEASIDE TABLE Item No. : T-4464XB ITEM NO.: T-4464XB Printed in Vietnam ISSUED APR 17, 2019 - 1 -...
- Page 2 Description Sketch Description Sketch Bolt Lock Washer (M8 x 50mm) (8.5 x13mm) Flat Washer Allen Key (2 x 8.5 x19mm) (M4 x 30mm x 110mm) ITEM NO.: T-4464XB Printed in Vietnam ISSUED APR 17, 2019 - 2 -...
- Page 3 Unlock the table top (A) from both sides underneath the top and pull the two parts of the table top apart. Attach legs (B) to the top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (4). ITEM NO.: T-4464XB Printed in Vietnam...
- Page 4 STEP 2 Unlock the table top from both sides underneath the top as shown below. Pull the two parts of the table top apart. ITEM NO.: T-4464XB Printed in Vietnam ISSUED APR 17, 2019 - 4 -...
- Page 5 We use the flexible metal bar for this purpose, as a hardened metal would snap during transport or damage the under structure. STEP 3 ITEM NO.: T-4464XB Printed in Vietnam ISSUED APR 17, 2019 - 5 -...
- Page 6 STEP 4 Push the table top closed. Lock the mechanism underneath two sides of the table top as shown below. STEP 3 ITEM NO.: T-4464XB Printed in Vietnam ISSUED APR 17, 2019 - 6 -...
