2 Getting Started

2.1 Ordering Codes and Accessories

Ordering code
BC106N-UV
BC106N-VIS
*Design range of Lumigen coating, sensitivity is given throughout 1100 nm but shows increased
non-uniformity and noise compared to uncoated BC106N-VIS.
The wavelength range of supplied UV ND filters starts at 220 nm.
For beam quality (M²) measurement, Thorlabs offers hardware extension sets and complete M²
Measurement Systems:
Hardware Extension Sets:
Item Number Description
M2MS M2 Measurement System Extension Set
M2MS-AL M2 Measurement System Extension Set, 250 - 600 nm (aluminum mirrors)
M² Measurement System with Camera Beam Profiler
The M2MS-BC106 comprises the M2MS Extension and a mounted BC106N beam profiler. The
following models are available:
Item Number
M2MS-BC106UV-AL
M2MS-BC106UV-AL/M
M2MS-BC106VIS
M2MS-BC106VIS/M
Please visit our homepage

2.2 Unpacking

Inspect the packaging for damage. If the shipping container seems to be damaged, keep it until
you have inspected the contents and you have inspected the instrument mechanically and
electrically.
Verify that you have received the following items:
· 1 BC106N Beam Profiler instrument with mounted filter wheel containing
o 6 Attenuation filters, see section Filter Wheel in the full manual
o 6 Filter caps in front of filters
· 1 USB 2.0 Cable A to Mini B, length 1.5 m
· This Quick Reference
4
Short description
CCD Camera Beam Profiler, 190 - 350 nm*
CCD Camera Beam Profiler, 350 - 1100 nm
Description
M2 Measurement System with BC106N-UV, 250 - 350 nm
M2 Measurement System with BC106N-UV, 250 - 350 nm, metric
M2 Measurement System with BC106N-VIS, 400 - 1100 nm
M2 Measurement System with BC106N-VIS, 400 - 1100 nm, metric
http://www.thorlabs.com for further information.
