MCLS
Multiple Channel Laser Source
Operating Manual
MULTICHANNEL LASER SOURCE
O
|
AC ON
THORLABS, Inc.
435 Route 206N
Newton, NJ 07860 USA
6374-D02 Rev.D 8/15/05
MCLS4
CONTROL
LASERS
POWER ADJUST
MASTER
ENABLE
ON
1
2
LASER APERTURE
LASER APERTURE
ENABLE
ENABLE
Ph: (973) 579-7227
Fax: (973) 383-8406
www.thorlabs.com
3
4
LASER APERTURE
LASER APERTURE
ENABLE
ENABLE
Advertisement
Table of Contents
Related Manuals for THORLABS MCLS Series
Summary of Contents for THORLABS MCLS Series
- Page 1 MCLS4 CONTROL LASER APERTURE LASER APERTURE LASER APERTURE LASER APERTURE AC ON LASERS POWER ADJUST MASTER ENABLE ENABLE ENABLE ENABLE ENABLE THORLABS, Inc. Ph: (973) 579-7227 435 Route 206N Fax: (973) 383-8406 Newton, NJ 07860 USA www.thorlabs.com 6374-D02 Rev.D 8/15/05...
-
Page 2: Table Of Contents
Table of Contents: ....................................1 Attention – Please consult this User’s Manual whenever this symbol is encountered on your MCLS Laser Source.Overview ................................. 1 Overview....................................2 Performance Specifications..............................3 Table 1 - Optical Specifications MCLS1550 ........................3 Table 2 - Optical Specifications MCLS635 ........................3 Table 3 –... -
Page 3: Overview
Figure 2 - Rear Panel Features The MCLS Series of multiple channel laser sources provides four individual fiber coupled laser light outputs in one convenient enclosure. Each channel operates in a constant power control loop to maintain consistent output power against changes in operating temperature. -
Page 4: Performance Specifications
Performance Specifications Table 1 - Optical Specifications MCLS1550 Parameter Typical Unit Operation Wavelength 1530 1550 1570 Output Power per Channel 1.50 1.80 2.50 Stability – Short term (<15min) +/- 0.05 Stability – Long term +/- 0.1 Fiber Type SMF28 Modulation Bandwidth CDRH Classification Class 1 Table 2 - Optical Specifications MCLS635... -
Page 5: Setting The Ac Line Voltage And Installing Fuses
Setting the AC Line Voltage and Installing Fuses Your MCLS unit has been shipped from Thorlabs, Inc. configured for 115VAC operation. If you are planning to operate your unit using a 230VAC input, or need to replace an open fuse, you must perform all or part of the following procedure: Setting the AC Line Voltage If it is attached, remove the AC line cord from the AC Input connector on the rear panel of the unit. -
Page 6: Operation
Operation Normal Operation and Use 1) Locate unit on a solid, dry working surface, or mount in a 19” equipment rack. 2) Select the operating voltage range (115VAC or 230VAC) by setting the Line Select Switch, located on the rear panel, to the appropriate setting. -
Page 7: Disabling The Outputs
Do not attempt to open the MCLS to clean the internal connections. If you suspect that the internal ferrule is dirty contact Thorlabs, Inc. and arrange to have the unit serviced. 6374-D02 Rev. D 8/15/05... -
Page 8: Making The Safety Interlock Connections
Making the Safety Interlock Connections The MCLS series Laser Sources are equipped with a Remote Interlock connector located on the rear panel (Refer to Figure 2). All units have this feature regardless of their FDA and IEC classifications. In order to enable the laser source, a short circuit must be applied across the terminals of the Remote Interlock connector. - Page 9 CAUTION- use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Class 1 Laser Product 1550nm <10mW Laser Radiation Avoid Exposure to Beam Class 3B Laser Product 635nm <20mW This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated May 27, 2001.
-
Page 10: Weee (Waste Electrical And Electronic Equipment Directive)
Waste treatment on your own responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site.
