HARDWARE LIST...
Key Part
Part
No.
No.
Description
1
65923
Bolt (#8-32 x 3/8) (10 mm)
2
65103
Hex Nut (#8-32)
3
65004
Screw (#8AB x 5/16) (8 mm)
4
66646
Washer Sheet
5
66715
Door Handle
6
66718
Hinge
7
66720
Padlock Eyelet
8
60H
Corner Cap
9
66870
Plastic Trim
10
66871
Plastic Corner Trim
11
66808
Latch Spring
12
66721
U-Nut (Door Clip)
13
66866
Door Closure Clip
14 11137
Mounting Plate
The fasteners used in each step are shown
actual size at the top of each page. If you
are unsure which fastener to use, hold it up
to the picture and use the one that matches.
Hardware Views by Key No.
1
Qty.
List
3
63
63
266
3
1
5
4
2
4
2
3
7
1
8
4
2
9
11
13
6
06FX
2
4
6
8
10
12
14
