SPACEMAKER RGB86ONEU Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
HX01a
727640319
Storage Area: 43 Sq. Ft.
4,0 m
2
BUILDING DIMENSIONS
*Approx.
Foundation
Size
8' x 6'
97 1/2" x 68 3/4"
2,4m x 1,8m
247,7cm x 174,6cm
Model No. RGB86ONEU
271 Cu. Ft.
7,7 m
3
* Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Size
Width
99 3/4"
253,4cm
Depth
Height
Width
71 1/4"
79 1/8"
94 3/4"
181,0cm
201,0cm
240,7cm 167,6cm 197,8cm
RGB86FGEU
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
66"
77 7/8"
Door
Opening
Width
Height
43 1/2"
69 1/4"
110,5cm
175,9cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the RGB86ONEU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SPACEMAKER RGB86ONEU

Summary of Contents for SPACEMAKER RGB86ONEU

  • Page 1 Owner's Manual & Assembly Instructions HX01a Model No. RGB86ONEU RGB86FGEU 727640319 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 43 Sq. Ft. 271 Cu. Ft. MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES 4,0 m 7,7 m TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 3 BEFORE YOU BEGIN..HS02a Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..XA05 Finish: For long lasting fi nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 Base FZ07 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber 5/8"...
  • Page 8 Anchoring XA07 Anchoring Down The Building It is important that the entire fl oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
  • Page 9 Hardware GW09 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 Black Screw (8) 65103 #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) (Packed with Screws) #8-32 Hex Nut (105) Bolt (105) Screw (290) 65109 66646 #8-32 Acorn Nut (6)

  • Page 10: Parts List

    Parts List GW10 Assembly Part Part Quantity Check Key No. Number Description in Carton List 6615 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 6658 Gable Brace 7875 Roof Panel 11148 Right Gable 80139 Left Gable 8461 Ridge Cap 8466 Right Roof Panel...
  • Page 11 Assembly by Key No. GW11...
  • Page 12 8941 Ramp (1) Parts Needed For Step 1 9379 Front Floor Frame (2) Floor Frame Assemblies 9377 Rear Floor Frame (2) B14 ctr 9379 The front fl oor frame is made up of 8941 three pieces. The rear fl oor frame is made up of two pieces.

  • Page 13: Frame Assemblies

    Parts Needed For 6615 Rear Wall Angle (2) Step 2 9924 Rear Wall Channel (2) Frame Assemblies 8397 Corner Brace (2) GW13 Rear Wall Channel 94 5/8" 240,3 cm 9924 9924 The main frame pieces reinforce the walls. These pieces will later be STEP installed in the center and at the top edge of the rear wall.
  • Page 14 Parts Needed For Step 3 8474 Roof Beam (1) 8476 Side Wall Angle (1) Roof Beam Assembly B16 ctr (10) The roof beams join the two gables and support the roof panels. The main roof beam is made up of two pieces fastened together.
  • Page 15 Parts Needed For Step 4 6617 Door Track Splice (1) 9378 Door Track (2) Door Track Assembly B17 ctr NOTE: Door Track Splice (painted part) The door track assembly supports the 6617 sliding doors and reinforces the front wall. It is made up of three pieces. Using the door track splice, (painted), join the door track 66769...
  • Page 16 Front Floor Assembly (1) Parts Needed For Step 5 8946 Side Floor Frame (2) Rear Floor Assembly (1) Floor Frame 8397 Corner Brace (4) GW16 RIGHT REAR 8946 (24) STEP 8946 Assemble the four corners of the 9377 fl oor frame using two screws at each corner as shown.
  • Page 17 Parts Needed For Step 6 9383 Front Corner Panel (2) 9387 Rear Corner Panel (2) Corners GW17 Wide Side (14) 9387 NOTE Narrow Side The remainder of the building assembly requires many hours and more than one STEP person. Do not continue beyond this REAR point if you do not have enough time to 9387...
  • Page 18 Door Track Assembly (1) Rear Wall Angle Assembly (1) Parts Needed For Step 7 8476 Side Wall Angle (2) Rear Wall Channel Assembly (1) Frames 9920 Side Wall Channel (2) GW18 6481 Gusset (2) 6615 (24) Wall Angles The main frame pieces give rigidity to Must Face the side walls and provide a surface Inside...
  • Page 19 Parts Needed For Step 8 6521 Wall Panel (4) 6155 Wall Panel (2) Wall Panels GW19 STEP 6155 6155 (11) (82) The wall panels come in two widths. 6521 Each wall panel has a crimped rib on 6521 STEP one side. The crimped rib should go under the rib of the panel that follows it.
  • Page 20 Parts Needed For Step 9 9371 Door Jamb (2) Door Jamb GW20 INSIDE OF BUILDING TOP VIEW (3) bolts Door Track Acorn Nut 9371 Bolt The door jambs reinforce the door Cross-Section Top View opening and provide an attractive Plug TOP VIEW trim.
  • Page 21 Parts Needed For 11148 Right Gable (2) Step 10 80139 Left Gable (2) Gable Assemblies 7916 Roof Beam Bracket (4) GW21 The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
  • Page 22 Left Gable Assembly (2) Parts Needed For Step 11 Right Gable Assembly (2) Gables/Braces 6658 Gable Brace (2) GW22 (24) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
  • Page 23 Parts Needed For Step 12 Main Roof Beam (1) 8474 Roof Beam (2) Roof Beams GW23 (12) Fasten the main roof beam to the STEP gable brace of the front gable. Fasten the other end of the main 8474 Roof Beam roof beam to the gable brace of the rear gable.
  • Page 24 Parts Needed For Step 13 8466 Right Roof Panel (1) Right Roof Panel GW24 STEP 8466 8467 Installing the roof panels is best done with a step ladder. Begin installing roof panels at the back right corner 7875 7875 of the building. Each screw and bolt in the roof requires a washer.

  • Page 25: Roof Assembly

    8467 Left Roof Panel (2) Parts Needed For Step 14 7875 Roof Panel (4) Roof Assembly 8466 Right Roof Panel (1) GW25 STEP STEP 8467 Left Roof Panel Weather Stripping Tape Roll (23) (38) 8466 Right Roof Panel Install a left roof panel at the left rear and right front corner of the roof.
  • Page 26 Parts Needed For Step 15 8461 Ridge Cap (1) Ridge Cap GW26 (20) Install the ridge cap on the completed roof section using bolts and nuts. Do not fasten the ends of the ridge cap at this time. STEP Fasten the lower end of the panels 8461 to the side wall angles using screws and washers.
  • Page 27 Parts Needed For Step 16 8482 Side Roof Trim (2) 66847 Vent Gable (4) Roof Trim GW27 (12) Attach the side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.

  • Page 28: Door Assembly

    10484 Right and Left Doors (2) Parts Needed For Step 17 10498 Horizontal Door Brace (4) Door Assembly 6301 Vertical Door Brace (2) BA30 ctr (12) The steps on this page tell how to assemble the right door. You will perform exactly the same procedures for the left door.
  • Page 29 Parts Needed For Step 18 Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) P31 ctr Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
  • Page 30 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
  • Page 32 RGB86ONEU RGB86FGEU HX32a Anchoring Anchoring Anchor your building at this time. 727640319...
