Owner's Manual & Assembly Instructions
IW01
728130319
Storage Area: 59 Sq. Ft. 369 Cu. Ft.
5,5 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Base
Size
Size
8' x 8'
97 1/2" x 92 3/4"
2,4m x 2,4m
247,7 cm x 235,6 cm
Model No.
10,5 m
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
99 3/4"
95 1/4"
253,4 cm
241,9 cm
RGB88ONEU
RGB88FGEU
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
79 1/8"
94 3/4"
201,0 cm
240,7 cm
Depth
Height
Width
90"
77 7/8"
43 1/2"
228,6 cm 197,8 cm
110,5 cm 175,9 cm
Door
Opening
Height
69 1/4"
Advertisement
Related Manuals for SPACEMAKER RGB88ONEU
Summary of Contents for SPACEMAKER RGB88ONEU
- Page 1 Owner's Manual & Assembly Instructions IW01 Model No. RGB88ONEU RGB88FGEU 728130319 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 59 Sq. Ft. 369 Cu. Ft. TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ...
- Page 2 BEFORE YOU BEGIN..HS02a Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.
- Page 3 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
- Page 4 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
- Page 5 CARE & MAINTENANCE..XA05 Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
- Page 6 Base IW07 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber 5/8"...
- Page 7 Anchoring XA07 Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
- Page 8 Hardware IW09 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 Black Screw (8) #8-32x3/8" (10 mm) 65103 #8Ax5/16" (8 mm) (Packed with Screws) #8-32 Hex Nut (175) Bolt (175) Screw (341) 65109 66646 #8-32 Acorn Nut (6)
- Page 9 Parts List IW10 Assembly Part Part Quantity Check Key No. Number Description in Carton List 6615 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 6658 Gable Brace 7875 Roof Panel 11148 Right Gable 80139 Left Gable 8486 Ridge Cap 8466 Right Roof Panel...
- Page 10 Assembly by Key No. IW11...
- Page 11 8941 Ramp (1) Step 1 Parts Needed For 9379 Front Floor Frame (2) Floor Frame Assemblies 9377 Rear Floor Frame (2) BY14 9989 Side Floor Frame (4) The front oor frame is made up of 3 pieces. The side oor frames and 9379 the rear oor frame are made up of 2 pieces.
- Page 12 6615 Rear Wall Angle (2) Step 2 Parts Needed For 9924 Rear Wall Channel (2) 9990 Side Wall Channel (4) Frame Assemblies 9991 Side Wall Angle (4) 8397 Corner Brace (2) IW13 9924 The main frame pieces reinforce 9924 Rear Wall Channel the walls.
- Page 13 Step 3 Parts Needed For 10470 Roof Beam (4) Roof Beam Assemblies 10471 Roof Beam (8) BY16 The roof beams join the 2 gables and support the roof panels. The roof assembly is made up of 4 pieces 2" 5,1 cm overlapped back to back at the center.
- Page 14 Step 4 Parts Needed For 6617 Door Track Splice (1) Door Track Assembly 9378 Door Track (2) NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6617 Using the door track splice, (painted), join the door track...
- Page 15 Step 5 Front Floor Assembly (1) Parts Needed For Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) 8397 Corner Brace (4) IW16 RIGHT REAR 9989 Assemble the four corners of the floor frame using two screws at each corner as shown. At the front STEP 9377 corners fasten bolts through from...
- Page 16 Step 6 Parts Needed For 9383 Front Corner Panel (2) Corners 9387 Rear Corner Panel (2) IW17 NOTE The remainder of the building assembly Wide Side requires many hours and more than one person. Do not continue beyond this 9387 point if you do not have enough time to Narrow Side complete the assembly today.
- Page 17 Door Track Assembly (1) Step 7 Rear Wall Angle Assembly (1) Parts Needed For Side Wall Angle Assemblies (2) Frames Rear Wall Channel Assembly (1) Side Wall Channel Assemblies (2) IW18 6481 Gusset (2) The main frame pieces give rigidity to 6615 the side walls and provide a surface for attaching the gables which sup-...
- Page 18 Step 8 Parts Needed For 6155 Wall Panel (2) Wall Panels 6521 Wall Panel (2) 5210 Wall Panel (4) IW19 The wall panels come in two widths. STEP Each wall panel has a crimped rib 6155 6155 on one side. The crimped rib should go under the rib of the panel that 5210 follows it.
- Page 19 Step 9 Parts Needed For 9371 Door Jamb (2) Door Jamb IW20 The door jambs reinforce the door opening and provide an attractive trim. Follow these steps for both STEP door jambs. (3) bolts TOP VIEW Door Track Fasten a door jamb to the front Hex Nut panel with three bolts, nuts and acorn nuts, as shown.
- Page 20 Step 10 Parts Needed For 11148 Right Gable (2) 80139 Left Gable (2) Gable Assemblies 7916 Roof Beam Bracket (4) IW21 The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
- Page 21 Step 11 Left Gable Assembly (2) Parts Needed For Right Gable Assembly (2) Gables/Braces 6658 Gable Brace (2) IW22 Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
- Page 22 Step 12 Parts Needed For Main Roof Beam (1) Roof Beams Outer Roof Beam (2) IW23 Fasten the main roof beam to the gable brace of the front gable. STEP Fasten the other end of the main 2" 5,1 cm roof beam to the gable brace of the Roof Beam Assembly rear gable.
- Page 23 Step 13 Parts Needed For 8466 Right Roof Panel (1) Right Roof Panel IW24 STEP Installing the roof panels is best done with a step ladder. Begin installing 8466 8467 roof panels at the back right corner of the building. Each screw and bolt in the roof requires a washer.
- Page 24 8466 Right Roof Panel (1) Step 14 Parts Needed For 8467 Left Roof Panel (2) Roof Assembly 7875 Roof Panel (2) 9978 Roof Panel (2) IW25 STEP Install a left roof panel at the left 8467 Left Roof Panel STEP rear and right front corner of the roof.
- Page 25 Step 15 8840 Ridge Cap (1) Parts Needed For 9978 Roof Panel (2) Ridge Caps & Panels 8486 Ridge Cap (1) IW26 Install the rst ridge cap on the completed roof section using bolts and nuts. Fasten roof panel over- 8840 laps not used for ridge cap.
- Page 26 Step 16 Parts Needed For 8485 Left Side Roof Trim (2) 8836 Right Side Roof Trim (2) Roof Trim 66847 Vent Gable (4) IW27 Attach the right and left side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.
- Page 27 Step 17 Parts Needed For 10484 Right and Left Doors (2) 10498 Horizontal Door Brace (4) Door Assembly 6301 Vertical Door Brace (2) BA30 ctr (12) The steps on this page tell how to assemble the right door. You will perform exactly the same procedures for the left door.
- Page 28 Step 18 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) P31 ctr Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
- Page 29 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
- Page 31 RGB88ONEU RGB88FGEU IW32 Anchoring Anchoring Anchor your building at this time. 728130319...
