SPACEMAKER VERSA-SHED EVRS63 Owner's Manual & Assembly Manual

6’ x 3’ nominal size
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
722591217
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Size
6' x 3'
12 Sq. Ft. 47 Cu. Ft.
1,8 m x 0,9 m
1,1 m
* See Inside for Detailed Safety Information.
or
†
Size rounded off to the nearest foot
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
72"
2
1,3 m 3
182,9 cm
Model No. EVRS63
Depth
Height
Width
29 5/8"
50 1/4"
67 5/8"
75,2 cm
127,6 cm
171,8 cm
www.spacemakersheds.com
EVRS63EU
VERSA-SHED
Base
70.38" x 28.25"
Size
178,8 cm x 71,8 cm
For proper base construction see page 10
Interior Dimensions
(Wall to Wall)
Depth
Height
25 1/2"
48 1/4"
64,8 cm
122,6 cm
01CEa
TM
6' x 3'
Nominal Size
Door
Opening
Width
Height
57 1/2"
42.5"
146,1 cm
108,0 cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERSA-SHED EVRS63 and is the answer not in the manual?

Questions and answers

Related Manuals for SPACEMAKER VERSA-SHED EVRS63

Summary of Contents for SPACEMAKER VERSA-SHED EVRS63

  • Page 1 01CEa 722591217 Owner’s Manual & Assembly Guide www.spacemakersheds.com Model No. EVRS63 EVRS63EU VERSA-SHED Gloves must be worn 6’ x 3’ at all times to reduce risk of injury! Nominal Size Customer Service: 1-800-851-1085 Base 70.38” x 28.25” assist@arrowsheds.com Size 178,8 cm x 71,8 cm For proper base construction see page 10 BUILDING DIMENSIONS †...
  • Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
  • Page 3 SAFETY PRECAUTIONS... 02BZ Safety precautions MUST be followed at all times throughout the construction of your building! Care must be taken when handling various Practice caution with the tools being used in pieces of your building since many contain the assembly of this building. Be especially sharp edges.

  • Page 4: What You Need

    ASSEMBLY TIPS & TOOLS 03BZ FREQUENTLY ASKED QUESTIONS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.

  • Page 5: Frequently Asked Questions

    04BZ FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 6 05BZ How do I control condensation and prevent water from leaking in? To minimize condensation, install a continuous, unbroken plastic vapor barrier with a thickness of 6 mil. between exposed ground surface and the building’s base. Make sure that all weather stripping and washers are used throughout the assembly process.
  • Page 7 HARDWARE LIST... 06CEa Hardware Views by Key No. Part Part Qty. Description List 65103 Hex Nut (#8-32) 65923 Small Bolt (Black) (#8-32 x 3/8) (10 mm) 65004 Small Screw (Black) (#8AB x 5/16) (8 mm) 65958 Long Bolt (#8-32 x 7/8) (22 mm) 65988 Flat Head Bolt (#6-32 x 5/16) (8 mm) 65941...
  • Page 8 PARTS LIST... 07CEa Selected End Views by Key No. Key Part Part Qty. Description List 10954 Corner Post 11072 Rear Wall Brace 10967 Channel Wall Rear 10960 Door Jamb 10963 Brace Door Vertical 10964 Channel Side Wall 11104 Frame Floor Front-Rear 10971 Channel Lid Rear 10970...
  • Page 9 ASSEMBLY BY KEY NO. 08CEa...

  • Page 10: Assembly Overview

    ASSEMBLY OVERVIEW 09CEa Build the Floor Frame Install Posts and Wall Panels Install Side Channel, Rear Install Lid Channel, & Lintel Install Doors...
  • Page 11 CONSTRUCTING A BASE... 10CEa No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).

  • Page 12: Step 1: Frame Assembly

    Step 1: Frame Assembly 11CEa You will need for this page: Do NOT fasten your Floor Frames to your Base at this 65004 11104 10984 11007 time. You will anchor your building after it is erected. (QTY: 12) Frame Floor Frame Floor Ramp Front-Rear...
  • Page 13 Step 1: Frame Assembly 12CEa You will need for this page: 8397 65004 (QTY: 16) Corner Brace 8397 FRONT...
  • Page 14 13CEa Step 2: Rear Channel Lid Assembly You will need for this page: 10971 66609 65988 65941 Channel Lid Hinge (QTY: 12) (QTY: 12) Rear 66609 10971 66609 66609 66609 10971 Correct 66609...
  • Page 15 Step 3: Lid Brace Assembly 14CEa You will need for this page: 10983 66862 10961 11042 65923 65958 65103 Mounting Plate Mounting Plate Slam Bolt (“Slam Bolt”) Lid Brace (QTY: 4) (QTY: 28) (QTY: 16) 10961 10983 Side View 11042 11042 66862 66862...
  • Page 16 15CEa Step 4: Rear Wall Brace Assembly You will need for this page: 11072 10967 66785 65923 65103 66646 Channel Wall Rear Wall Lid Stay Brace Rear (QTY: 12) (QTY: 12) (QTY: 6) 66785 11072 10967 11072 11072 10967 11072...

  • Page 17: Step 5: Lid Assembly

    Step 5: Lid Assembly 16CEa You will need for this page: Assembly from Step 2: 10981 66848 65004 66646 • Rear Channel Lid Assembly Channel Lid Lid Corner (QTY: 4) (QTY: 2) 10981 10981 Side View Rear Channel Lid Assembly 10981 66848 66848...
  • Page 18 Step 5: Lid Assembly 17CEa You will need for this page: Assembly from Step 3: 66855 66853 65004 66646 • Lid Brace Assemblies Outer Lid Center Lid (QTY: 6) (QTY: 6) Foam Board Foam Board Lid Brace Assemblies Rear Channel Lid Assembly Place Foam “Foil Side”...
  • Page 19 Step 5: Lid Assembly 18CEa You will need for this page: 10969 10970 66848 66646 65004 Channel Lid Lid Corner (QTY: 8) (QTY: 10) Panel Lid Front 10969 66855 66853 66853 66855 Rear Channel 10969 Lide Assembly Panel Lid Hinge 10970 10970 Side View...
  • Page 20 19CEa Step 6: Door Assembly (Left) You will need for this page: 66646 80103 10959 10968 65004 65988 65941 Horizontal (QTY: 6) (QTY: 6) (QTY: 4) (QTY: 8) Door Stop Door Left Door Brace 66854 66609 Door Foam Board Hinge Place Foam “Foil Side”...

  • Page 21: Step 6: Door Assembly (Right)

    20CEa Step 6: Door Assembly (Right) You will need for this page: 66646 10972 10959 10968 65004 65988 65941 Horizontal (QTY: 2) (QTY: 6) (QTY: 6) (QTY: 4) Door Stop Door Right Door Brace 66854 66609 Door Foam Hinge Board Place Foam “Foil Side”...

  • Page 22: Step 7: Door Lock Assembly

    21CEa Step 7: Door Lock Assembly You will need for this page: 10968 10963 66646 65004 Horizontal Brace Door (QTY: 6) (QTY: 6) Vertical Door Brace 10963 Horizontal Door Brace Door 10968 Side View...
  • Page 23 Step 7: Door Lock Assembly 22CEa You will need for this page: 66054 66658 66850 66809 65004 65958 Bar Locking Bracket-Camrod (QTY: 2) (QTY: 2) Latch Locking Handle Assembly 66850 66809 66054 66809 66054 66658...

  • Page 24: Step 8: Side Walls

    Step 8: Side Walls 23BZa You will need for this page: Assembly from Step 1: 80097 8827 10958 10954 10960 • Frame Assembly 69835 6481 Panel Gable Panel Gable Side Siding Corner Post Door Jamb Left Right 65004 66646 65923 65103 Edge Trim Gusset...
  • Page 25 Step 9: Back Wall 24CEa You will need for this page: 11074 65004 66646 (QTY: 5) (QTY: 1) Rear Panel 11074 Rear Panel Frame Floor Side...
  • Page 26 Step 9: Back Wall 25CEa You will need for this page: 11074 65004 Rear Panel (QTY: 4) 11074 Rear Panel Frame Floor Side...
  • Page 27 Step 10: Rear Wall Channel 26CEa You will need for this page: Assembly from Step 4: 65923 65103 65004 66646 • Rear Wall Brace Assembly (QTY: 2) (QTY: 6) (QTY: 2) (QTY: 2) Channel Post Panel Bolt Washer 65004...
  • Page 28 Step 11: Lintel 27CEa You will need for this page: 10973 6481 65923 65103 66646 Lintel Gusset (QTY: 6) (QTY: 6) (QTY: 4) 6481 10973 6481...
  • Page 29 Step 12: Top Frames 28CEa You will need for this page: 66849L 66849R 66861L 66861R 10964 65004 Right Rear Left Door Right Door Left Rear Channel Corner Cap (QTY: 8) Corner Cap Jamb Cap Jamb Cap Side Wall 66861L 66861R 10964 10964 66849L...
  • Page 30 Step 13: Lid Install 29CEa You will need for this page: Assembly from Step 5: 65988 65941 66611 • Lid Assembly (QTY: 12) (QTY: 12) #10 x 1/2 (QTY: 6) 65988 65941 66611 Lid Assembly 65988 66785 Rear Wall Channel Side View...
  • Page 31 Step 14: Door Install 30CEa You will need for this page: 65988 65941 Assemblies from Step 6 and 7: • Right and Left Door Assemblies 11029 (QTY: 12) (QTY: 12) (QTY: 3) Left Door Assembly Right Door Assembly Adhesive Pads Right Door Left Door 11029...
  • Page 32 ANCHORING OPTIONS... 32BZ IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
  • Page 33 CARE & MAINTENANCE... 33BZ Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.

  • Page 34: Assembly Notes

    ASSEMBLY NOTES...
  • Page 35 ASSEMBLY NOTES...
