Step 1: Floor Assembly
You will need for this page:
65923
65103
(QTY: 8)
(QTY: 8)
11113
11113
11114
11113
FRONT
11113
Front Corner
11114
11113
The Floor Frame must be BOTH square AND
level or the holes will not line up properly.
11113
65004
Front-Rear
(QTY: 8)
Floor Frame
11113
73 7/16" 186,6 cm
11113
Back Corner
11114
11114
4
Side
Floor Frame
11113
Finished Length
11113
11114
When
are equal, the Frame is square.
12
2
11113
diagonal
measurements
12FXa
