SPACEMAKER RPT84ONEU Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
IY01
728850119
Storage Area: 28 Sq. Ft.
2,6 m
2
BUILDING DIMENSIONS
*Approx.
Size
8' x 4'
97 1/2" x 45 1/4"
2,4 m x 1,2 m
247,7 cm x 114,9 cm
Model No.
172 Cu. Ft.
4,9 m
3
* Size rounded o to the nearest foot
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
100"
254,0 cm
Depth
Height
Width
47"
77"
94 3/4"
119,4 cm 195,6 cm
240,7 cm 108,0 cm
RPT84ONEU
RPT84FGEU
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
42 1/2"
75 13/16"
192,6 cm
Door
Opening
Width
Height
43 1/2"
69 1/4"
110,5 cm 175,9 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the RPT84ONEU and is the answer not in the manual?

Questions and answers

Related Manuals for SPACEMAKER RPT84ONEU

Summary of Contents for SPACEMAKER RPT84ONEU

  • Page 1 Owner's Manual & Assembly Instructions IY01 Model No. RPT84ONEU RPT84FGEU 728850119 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 28 Sq. Ft. 172 Cu. Ft. MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES 2,6 m 4,9 m TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 BEFORE YOU BEGIN..HS02a Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 3: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 5 CARE & MAINTENANCE..XA05 Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 6 Base IY06 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber 5/8"...
  • Page 7 Anchoring XA07 Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
  • Page 8 Hardware IY08 Remove from bag of screws and save for the last step 65900A 65923 #10Bx1/2" (13 mm) 65004 #8-32x3/8" (10 mm) 65103 Black Screw (8) #8Ax5/16" (8 mm) #8-32 Hex Nut (62) Bolt (62) (Packed with Screws) Screw (262) 66646 66775 65109...

  • Page 9: Parts List

    Parts List IY09 Assembly Part Part Quantity Check Key No. Number Description in Carton List 10566 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 10573 Front Header 10557 Roof Panel 11198 Right Gable 80155 Left Gable 9316 Right Roof Trim 10560 Right Roof Panel...
  • Page 10 Assembly by Key No. IY10...
  • Page 11 Step 1 8941 Ramp (1) Parts Needed For 9379 Front Floor Frame (2) Floor Frame Assemblies 9377 Rear Floor Frame (2) B14 ctr 9379 The front oor frame is made up of 8941 three pieces. The rear oor frame is made up of two pieces.

  • Page 12: Frame Assemblies

    Step 2 Parts Needed For 10566 Rear Wall Angle (2) Frame Assemblies 9924 Rear Wall Channel (2) ABX15 Rear Wall Channel 94 5/8" 240,3 cm 9924 The main frame pieces reinforce 9924 the walls. These pieces will later be installed in the center and at the top edge of the rear wall.
  • Page 13 Step 3 Parts Needed For 10570 Roof Beam (2) Roof Beam Assemblies ABX16 The roof beams support the roof 10570 panels. The roof beam is made up of two pieces overlapped at the center. 10570 Hint: These pieces are force-fitted, 96 3/8"...
  • Page 14 Parts Needed For Step 4 6617 Door Track Splice (1) Door Track / Header 9378 Door Track (2) ABX17 10573 Header (2) Assembly NOTE: Door Track Splice (painted part) (16) The door track/header assembly 6617 supports the sliding doors and rein- forces the front wall.
  • Page 15 Step 5 Front Floor Assembly (1) Parts Needed For 10544 Side Floor Frame (2) Floor Frame Rear Floor Assembly (1) 8397 Corner Brace (4) IY15 RIGHT REAR 10544 (24) Assemble the four corners of the STEP 10544 oor frame using two screws at each 9377 corner as shown.
  • Page 16 Step 6 Parts Needed For 9383 Front Corner Panel (2) Corners 9387 Rear Corner Panel (2) IY16 Wide Side (14) 9387 Narrow Side NOTE STEP The remainder of the building assembly REAR requires many hours and more than one 9387 person.
  • Page 17 Rear Wall Angle Assembly (1) Step 7 Parts Needed For Rear Wall Channel Assembly (1) 10545 Side Wall Channel (2) Frames 10564 Side Wall Angle (2) Door Track/Header Assembly (1) IY17 6481 Gusset (2) 11241 Gusset Strap (2) 67521 Edge Trim (1) (24) (10) 11241...
  • Page 18 Step 8 Parts Needed For 6155 Wall Panel (2) Wall Panels 10836 Wall Panel (4) IY18 Fasten the wall panels at the top and bottom with screws. (84) Fasten the center of each panel to the wall channel with screws. The wall panels come in two widths.
  • Page 19 Step 9 Parts Needed For 9371 Door Jamb (2) Door Jamb IY19 STEP (3) bolts TOP VIEW Door Track Hex Nut Acorn Nut Plug The door jambs reinforce the door 9371 opening and provide an attractive Bolt trim. Follow these steps for both door jambs.
  • Page 20 Step 10 Parts Needed For Roof Beam Assembly (1) Roof Beam ABX23 The dimension stated below measures from the end of the angle towards the front of the building. Fasten the roof beam assembly, small holes on top, to the side wall angle with a bolt and nut.
