SPACEMAKER RGB1012ONEU Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
JE01
728400319
Storage Area: 115 Sq. Ft. 734 Cu. Ft.
10,7 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Base
Size
10' x 12'
121" X 143 1/4"
3,0 m x 3,7 m
307,3 cm x 363,9 cm
20,8 m
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Size
Width
123 1/4" 145 3/4"
313,1 cm
Model No. RGB1012ONEU
Depth
Height
Width
82 1/8"
118 1/4" 140 1/2"
370,2 cm
208,6 cm
300,4 cm
RGB1012FGEU
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Depth
Height
80 7/8"
356,9 cm 205,4 cm
Door
Opening
Width
Height
55 1/2"
69 1/4"
141,0 cm 175,9 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the RGB1012ONEU and is the answer not in the manual?

Questions and answers

Related Manuals for SPACEMAKER RGB1012ONEU

Summary of Contents for SPACEMAKER RGB1012ONEU

  • Page 1 Owner's Manual & Assembly Instructions JE01 Model No. RGB1012ONEU RGB1012FGEU 728400319 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 115 Sq. Ft. 734 Cu. Ft. MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ...
  • Page 3 BEFORE YOU BEGIN..HS02a Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Assembly Instructions: Instructions are supplied in this manual and contain all appropriate information for your building model.

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 CARE & MAINTENANCE..XA05 Finish: For long lasting nish, periodically clean and wax the exterior surface. Touch-up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 7 Base DL07 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber 5/8"...
  • Page 8 Anchoring XA07 Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
  • Page 9 Hardware JE09 Remove from bag of screws and save for the last step 65900A #10Bx1/2" (13 mm) 65923 65004 65103 Black Screw (8) #8-32x3/8" (10 mm) #8Ax5/16" (8 mm) #8-32 Hex Nut (179) (Packed with Screws) Bolt (179) Screw (430) 65109 66646 #8-32 Acorn Nut (4)

  • Page 10: Parts List

    Parts List JE10 Assembly Part Part Quantity Check Key No. Number Description in Carton List 11236 Right Gable 80173 Left Gable 10497 Horizontal Door Brace 6529 Roof Panel 6640 Right Roof Panel 6641 Left Roof Panel 10472 Right and Left Doors 9371 Door Jamb 9375...
  • Page 11 Assembly by Key No. JE11...
  • Page 12 8934 Ramp (1) Step 1 Parts Needed For 9367 Front Floor Frame (2) Floor Frame Assemblies 8936 Rear Floor Frame (2) SV14 10392 Side Floor Frame (4) The front oor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.

  • Page 13: Frame Assemblies

    5986 Rear Wall Angle (2) Step 2 Parts Needed For 10389 Rear Wall Channel (2) Frame Assemblies 10390 Side Wall Channel (4) SV15 10393 Side Wall Angle (4) The main frame pieces reinforce the walls. These pieces will later be Rear Wall Channel 10389 installed in the center and at the top...
  • Page 14 Step 3 Parts Needed For 10397 Roof Beam (8) Roof Beam Assemblies SV16 The roof beams join the two gables and support the roof panels. The 10397 main roof beam is made up of four pieces overlapped back to back at the center.
  • Page 15 Step 4 Parts Needed For 6403 Door Track Splice (1) Door Track Assembly 9366 Door Track (2) A17 ctr NOTE: Door Track Splice (painted part) 6403 The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. Using the door track splice, (painted), join the door track (galvanized) pieces end-to-end as...
  • Page 16 Step 5 Front Floor Assembly (1) Parts Needed For Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) 8397 Corner Brace (4) JE16 RIGHT REAR 10392 (24) Assemble the four corners of the oor frame using two screws at STEP 8936 each corner as shown.
  • Page 17 Step 6 Parts Needed For 6521 Wall Panel (2) 9375 Front Wall Panel (2) Corners 6520 Corner Panel (4) JE17 NOTE Narrow The remainder of the building assembly Side requires many hours and more than one 6520 person. Do not continue beyond this Wide Side point if you do not have enough time to complete the assembly today.
  • Page 18 Step 7 Parts Needed For Rear Wall Channel Assembly (1) Mid Frames Side Wall Channel Assembly (2) JE18 The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.
  • Page 19 Step 8 Door Track Assembly (1) Parts Needed For Rear Wall Angle Assembly (1) Top Frames Side Wall Angle Assembly (2) SQ21 The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
  • Page 20 Step 9 6521 Wall Panel (8) Parts Needed For 11241 Gusset Strap (2) Wall Panels 67521 Edge Trim (1) JE20 STEP Each wall panel has a crimped rib Crimped Rib STEP Underneath on one side. The crimped rib should go under the rib of the panel that 6521 follows it.
  • Page 21 Step 10 Parts Needed For 9371 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) JE21 The door jambs reinforce the door opening and provide an attractive 9365 trim. Follow these steps for both door jambs. Fasten the front wall channels STEP in their positions between the end of the side wall channel and the corner...
  • Page 22 Step 11 Parts Needed For 11236 Right Gable (2) 80173 Left Gable (2) Gable Assemblies 5971 Roof Beam Bracket (4) JE22 The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
  • Page 23 Step 12 Parts Needed For Left Gable Assemblies (2) Right Gable Assemblies (2) Gables/Braces 6635 Gable Brace (2) JE23 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws. Hint: On the front gable, leave out 2 screws closest to center gable leg.
  • Page 24 Step 13 Parts Needed For Main Roof Beam Assembly (1) Roof Beams Single Roof Beam Assemblies (2) JE24 Spread the two halves of the double roof beam and fasten to the gable brace of the front gable. STEP Fasten the other end of the double roof beam to the gable brace of the rear gable.
  • Page 25 Step 14 Parts Needed For 6640 Right Roof Panel (1) Right Roof Panel JE25 Installing the roof panels is best done with a step ladder. Begin Installing roof panels at the back right corner of the building. Each screw and bolt in the roof requires a washer.

  • Page 26: Roof Assembly

    Step 15 Parts Needed For 6641 Left Roof Panel (1) 6529 Roof Panel (2) Roof Assembly 6869 Ridge Cap (1) JE26 Install a left roof panel at the left Screws To rear corner of the roof. Roof Beam Install two roof panels in the sequence shown on previous page.
  • Page 27 Step 16 Parts Needed For 6529 Roof Panel (2) Roof Assembly 6868 Ridge Cap (1) JE27 Install two roof panels as you unroll the weather stripping tape, and press it down, install the second ridge cap 6868 overlapping the rst ridge cap.
  • Page 28 6529 Roof Panel (2) Step 17 Parts Needed For 6641 Left Roof Panel (1) Roof Assembly 6869 Ridge Cap (1) 6640 Right Roof Panel (1) JE28 Install two roof panels, left roof panel, ridge cap 6869 and right roof panel on the front of the roof as before.
  • Page 29 Step 18 6015 Side Roof Trim (4) Parts Needed For 6014 Side Roof Trim (2) Roof Trim 66847 Vent Gable (4) JE29 Attach the side roof trim pieces to the lower end of the roof panels on each side of the building using screws at each panel overlap.

  • Page 30: Door Assembly

    3719 Door Handle Brace (2) Step 19 Parts Needed For 10472 Right and Left Doors (2) Door Assembly 10497 Horizontal Door Brace (4) 6301 Vertical Door Brace (2) JE30 The steps on this page tell how to assemble the right door. You will per- form exactly the same procedures for the left door.
  • Page 31 Step 20 Parts Needed For Right Door Assembly (1) Door Installation & Adjustment Left Door Assembly (1) SQ33 Horizontal Door Brace Gable From inside the building, put the Door Track bottom of the right door assembly Door Slide (on your left when you are inside the building) behind door jamb into the front frame track.
  • Page 32 RGB1012FGEU RGB1012ONEU JE32 Anchoring Anchoring Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, inside Rusting is a natural oxidizing process that occurs when and out. bare metal is exposed to moisture. Problem areas in- clude screw holes, un nished edges, or where scrapes 2.
