Internal Assembly Parts List

No. Description
3HP, 1PH, 208-240V, 60Hz, TEFC Motor
5HP, 1PH, 208-240V, 60Hz, TEFC Motor
5HP, 3PH, 208-240V, 60Hz, TEFC Motor
5HP, 3PH, 480V, 60Hz, TEFC Motor
7.5HP, 3PH, 208-240V, 60Hz, TEFC Motor
7.5HP, 3PH, 480V, 60Hz, TEFC Motor
1
5HP, 3PH, 600V, 60Hz, TEFC Motor (Canada only)
7.5HP, 3PH, 600V, 60Hz, TEFC Motor (Canada only)
3HP, 1PH, 240V, 50Hz, TEFC Motor (Australia only)
5.5HP, 3PH, 415V, 50Hz, TEFC Motor (Australia only)
5HP, 3PH, 380V, 60Hz, TEFC Motor (Korea only)
5HP, 3PH, 200V, 50-60Hz, TEFC Motor (Japan only)
5HP, 3PH, 380V, 50Hz TEFC Motor (China only)
2 M12x1.75x110 Hex Head Bolt
3 M12x1.75x105 Motor Positioning Bolt
Motor Pulley
4
Motor Pulley (50 Hz motors only)
5 M5x5x30 Key
6 M6x1.0x8 Set Screw
7 Tilt Lock Knob
8 Front Trunnion Bracket
9 Table Alignment Pin (8mm x 20 mm)
10 M10x1.5x55 Hex Head Limit Bolt
11 M10x1.5 Hex Nut
12 Front Trunnion
13 Rear Trunnion Bracket
14 M10x1.5x45 Hex Head Bolt
15 M10 Lock Washer
16 M10x25x3 Washer
17 Rear Trunnion
18 Trunnion Brace
19 M10x1.5x40 Socket Head Cap Screw
21 M6x1.0x16 Socket Head Cap Screw
22 Riving Knife
23 Dust Shroud Door
24 Pivot Pin
25 10 mm E-Style Retaining Ring
26 Thumb Screw
27 Dust Hose Coupling
28 M6x1.0x15 Pan Head Phillips Screw
29 M6x13x2 Washer
30 Trunnion Brace Bumper
Part No. Qty.
CB104 069
CB104 071
CB104 072
CB104 073
CB105 015
CB105 016
CB107 054
CB107 055
CB107 056
CB107 057
CB107 058
CB105 026
CB113 002
CB104 074
CB104 075
CB104 076
CB106 033
CB104 077
CB104 078
CB104 079
CB104 080
CB104 081
CB104 082
CB104 083
CB104 084
CB104 085
CB104 086
CB104 087
CB104 088
CB104 089
CB104 090
CB104 091
CB104 093
CB110 004
CB104 095
CB104 096
CB104 097
CB104 098
CB104 099
CB104 100
CB104 101
CB104 102
SawStop 10" Industrial Cabinet Saw
®
1
1
1
1
1
2
1
1
6
3
4
1
1
4
13
6
1
1
9
2
1
1
1
2
1
1
4
4
1
