1. Determine and mark center line on wall and cabinet bottom with a pencil.
2. If the cabinet bottom is recessed, wood blocking must be installed to ensure proper
within cabinet bottom.
3. Follow the dimensions in Fig.1 and cut-out the bottom of your cabinet to create an opening
cabinet door. For framed cabinet measure 1-15/16" from front of cabinet bottom.
7"
7
3/4
7"
*6-
3/16"
19-
7/8"
C/L
* Dimension used for rear ducting option
9
Fig.1
"
Fig.2
front edge
glass handle
