Related Manuals for Avalue Technology SID-10W9
Summary of Contents for Avalue Technology SID-10W9
- Page 1 SID-10W9 Intel Atom Z3735F 10.1" Semi Industrial Ultra Slim Panel PC Quick Reference Guide Ed –15 March 2017 Copyright Notice Copyright 2017 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017S090A0R...
- Page 2 (2) Use only shielded cables to connect I/O devices to this equipment. (3) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 2 SID-10W9 Quick Reference Guide...
- Page 3 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 4 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
-
Page 5: Table Of Contents
Safety Precautions ....................6 Packing List ......................6 System Specifications ................... 7 System Overview ....................9 1.4.1 Front View ............................ 9 1.4.2 Bottom View ..........................9 System Dimensions ..................... 10 1.5.1 Front and Rear side ........................10 SID-10W9 Quick Reference Guide... -
Page 6: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x SID-10W9 Panel PC 1 x AC/DC Power adapter 19V/3.42A ... -
Page 7: System Specifications
802.11g: USA and Canada : 1 ~ 11 Most European Countries : 1 ~ 13 802.11n: USA and Canada : 1 ~ 11 Most European Countries : 1 ~ 13 WLAN: DSSS, OFDM, BPSK(9/6Mbps), QPSK(18/12Mbps), Modulation DBPSK(1Mbps), DQPSK(2Mbps), CCK(11/5.5Mbps), 16-QAM(36/24Mbps), 64-QAM (72.2/54/48Mbps) Power Requirement SID-10W9 Quick Reference Guide... - Page 8 Reliability EMI Test CE/ FCC class B Dust and Rain Test Front Panel IP65 Vibration Test IEC 60068-2-64, Random, 5~500Hz, 1HR/axis Shock Test 50Grms, IEC 60068-2-27, Half-Sine, Note: Specifications are subject to change without notice. 8 SID-10W9 Quick Reference Guide...
-
Page 9: System Overview
Label Function Note Line out Audio line-out connector Head phone jack HDMI HDMI connector HDMI type A USB2.0 2 x USB 2.0 connector USB type A DCIN DC power-in connector DC jack 10/100 Fast Ethernet RJ-45 SID-10W9 Quick Reference Guide... -
Page 10: System Dimensions
SID-10W9 1.5 System Dimensions 1.5.1 Front and Rear side (Unit: mm) 10 SID-10W9 Quick Reference Guide...
